Motherboards

MPN MBD-X11SPW-TF-O Form Factor Proprietary WIO CPU Intel Xeon Processor Scalable Family. Single Socket P (LGA 3647) supported, CPU TDP support 205W Cores / Cache Up to 28 cores Memory Capacity 6x 288-pin DDR4 DIMM slots Up to 768GB ECC 3DS LRDIMM Up to 384GB ECC LRDIMM Up to 192GB ECC RDIMM Memory Type 2666/2400/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit 288-pin RDIMM/LRDIMM DIMM Sizes RDIMM: 4GB, 8GB, 16GB, 32GB LRDIMM: 32GB, 64GB 3DS LRDIMM: 64GB, 128GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Chipset Intel C622 SATA Intel C622 controller for 10 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2500 Network Controllers Dual LAN with 10GBase-T with Intel X722 + X557 Graphics Aspeed AST2500 BMC USB 7 USB 2.0 ports (2 rear + 5 via header(s)), 5 USB 3.0 ports (2 rear + 2 via header(s) + 1 Type A) Video Output 1 VGA port(s) Serial Port / Header 2 COM Ports (1 rear, 1 header(s)) TPM TPM Header PCI-E 1 PCI-E 3.0 x8 (in x16 slot), M.2 Interface: PCIe 3.0 x4 and SATA Form Factor: 2280, 22110 BIOS Type AMI UEFI BIOS Features ACPI 6.0 RTC (Real Time Clock) Wakeup SMBIOS 3.0 or late Software Intel Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SPM, SUM, SuperDoctor 5, Watchdog Power Configurations ACPI Power Management Power-on mode for AC power recovery Voltage +1.8V, +12V, +3.3V, +5V, +5V standby, 3.3V standby, 7-fan status, Chassis intrusion header, HT, Monitors CPU voltages, Supports system management utility, VBAT FAN 7x 4-pin fan headers (up to 7 fans), Fan speed control, Overheat LED indication, PWM fan speed control, System level control Temperature CPU thermal trip support PECI LED CPU / System Overheat LED UID/Remote UID Suspend static indicator LED Other Features ACPI power management, Control of power-on for recovery from AC power loss, RoHS, UID, WOL Item Dimension (L inchxW inchxH inch) 14 x 11 x 3 Weight 3.00lb

MPN MBD-X11SPI-TF-O Form Factor E-ATX CPU Intel Xeon Scalable Processors. Dual Socket P (LGA 3647) supported, CPU TDP support 205W, 2 UPI up to 10.4 GT/s Memory Capacity Up to 2TB 3DS ECC RDIMM and DDR4-2666MHz, Up to 2TB 3DS ECC LRDIMM, in 16 DIMM slots Memory Type 2666/2400/2133MHz ECC DDR4 RDIMM, LRDIMM DIMM Sizes RDIMM: 64GB LRDIMM: 64GB 3DS LRDIMM: 128GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) Chipset Intel C621 SATA Intel C621 controller for 10 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2500 Network Controllers Dual LAN with GbE from C621 Audio 7.1 HD Audio Graphics Aspeed AST2500 BMC USB 4 USB 3.0 ports (4 rear via header(s)), 2 USB 3.1 ports (2 rear) Video Output 1 VGA port(s) Serial Port / Header 1 COM Port (1 header(s)) TPM 1 TPM Header Others Thunderbolt header for Thunderbolt 3.0 AOC support PCI-E 4 PCI-E 3.0 x16, 2 PCI-E 3.0 x8 M.2 Interface: PCIe 3.0 x4 Form Factor: M-Key 2260, 2280, 22110 BIOS Type UEFI 128M Software Intel Node Manager, IPMI2.0, SPM, SSM, SUM, SuperDoctor 5, Watchdog Voltage +1.8V, +12V, +3.3V, +5V, +5V standby FAN 8x 4-pin fan headers (up to 8 fans), 8x fans with tachometer monitoring , Fan speed control, Overheat LED indication, Pulse Width Modulated (PWM) fan connectors Temperature N/A LED N/A Other Features Chassis intrusion detection, CPU thermal trip support for processor protection, Node Manager Support, RoHS Item Dimension (L inchxW inchxH inch) 14 x 11 x 3 Weight 3.00lb

MPN X570 STEEL LEGEND Unique Feature ASRock USB 3.2 Gen2 - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s) - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s) ASRock Super Alloy - XXL Aluminum Alloy Heatsink - Premium 60A Power Choke - 50A Dr.MOS - Premium Memory Alloy Choke (Reduces 70% core loss compared to iron powder choke) - Combo Caps (Nichicon 12K Black Caps) - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) - I/O Armor - Matte Black PCB - High Density Glass Fabric PCB - 2oz Copper PCB ASRock Steel Slot Gen4 ASRock Full Coverage M.2 Heatsink ASRock Hyper M.2 (PCIe Gen4x4 SATA3) ASRock Ultra USB Power ASRock POST Status Checker (PSC) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update APP Shop CPU - Supports AMD AM4 socket Ryzen 2000 and 3000 series processors - Intersil Digital PWM - 10 Power Phase design Chipset - AMD X570 Memory - Dual Channel DDR4 Memory Technology - 4 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4666+(OC) / 4400(OC) / 4300(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200/2933/2667/2400/2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3600+(OC) / 3466(OC) / 3200(OC) / 2933/2667/2400/2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 non-ECC, un-buffered memory - Max. capacity of system memory: 128GB - 15 Gold Contact in DIMM Slots BIOS - 256Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP Voltage Multi-adjustment Graphics - Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. - Dual graphics output: support HDMI and DisplayPort 1.2 ports by independent display controllers - Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.0 - Supports HDCP 2.2 with HDMI 2.0 and DisplayPort 1.2 Ports - Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and DisplayPort 1.2 Ports - Supports Microsoft PlayReady Audio - 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec) - Premium Blu-ray Audio support - Supports Surge Protection - Supports Purity Sound 4 - Nichicon Fine Gold Series Audio Caps - NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets) - Pure Power-In - Direct Drive Technology - PCB isolate shielding - Impedance Sensing on Rear Out port - Individual PCB Layers for R/L Audio Channel - Gold Audio Jacks - 15 Gold Audio Connector LAN - Gigabit LAN 10/100/1000 Mb/s - GigaLAN Intel I211AT - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Slots AMD Ryzen series CPUs (Matisse) - 2 x PCI Express 4.0 x16 Slots (single at x16 (PCIE1) dual at x16 (PCIE1) / x4 (PCIE4)) AMD Ryzen series CPUs (Pinnacle Ridge) - 2 x PCI Express 3.0 x16 Slots (single at x16 (PCIE1) dual at x16 (PCIE1) / x4 (PCIE4)) AMD Ryzen series CPUs (Picasso) - 2 x PCI Express 3.0 x16 Slots (single at x8 (PCIE1) dual at x8 (PCIE1) / x4 (PCIE4)) - 3 x PCI Express 4.0 x1 Slots - Supports AMD Quad CrossFireX and CrossFireX - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module - 15 Gold Contact in VGA PCIe Slot (PCIE1) Storage - 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso) - 1 x Hyper M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) Connector - 1 x SPI TPM Header - 1 x Power LED and Speaker Header - 1 x AMD Fan LED Header - 1 x RGB LED Header - 1 x Addressable LED Header - 1 x CPU Fan Connector (4-pin) - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x 4 pin 12V Power Connector - 1 x Front Panel Audio Connector (15 Gold Audio Connector) - 1 x AMD LED Fan USB Header - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 3 AIC Card R2.0 only) - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) Rear Panel I/O - 2 x Antenna Ports (on I/O Panel Shield) - 1 x PS/2 Mouse/Keyboard Port - 1 x HDMI Port - 1 x DisplayPort 1.2 - 1 x Optical SPDIF Out Port - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection) - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection) - 6 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks) Ultra USB Power is supported on USB3_56 ports. ACPI wake-up function is not supported on USB3_56 ports. Software and UEFI Software - ASRock Polychrome SYNC - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash These utilities can be downloaded from ASRock Live Update APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD - 4 x SATA Data Cables - 3 x Screws for M.2 Sockets - 2 x Standoffs for M.2 Sockets Hardware Monitor - Temperature Sensing: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Tachometer: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, VPPM, PREM VDDCR_SOC, +1.8V, VDDP Form Factor - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm - 2oz Copper PCB OS - Microsoft Windows 10 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)

MPN X570 PHANTOM GAMING 4 Gaming Armor Memory - 15 Gold Contact in DIMM Slots VGA Card - 15 Gold Contact in VGA PCIe Slot (PCIE1) Internet - Intel LAN Cooling - XXL Aluminum Alloy Heatsink Unique Feature ASRock USB 3.2 Gen2 - ASRock USB 3.2 Gen2 Type-A Ports (10 Gb/s) ASRock Super Alloy - XXL Aluminum Alloy Heatsink - Premium 50A Power Choke - Sapphire Black PCB - High Density Glass Fabric PCB - 2oz Copper PCB ASRock Steel Slot Gen4 ASRock Hyper M.2 (PCIe Gen4x4 SATA3) ASRock POST Status Checker (PSC) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update APP Shop CPU - Supports AMD AM4 socket Ryzen 2000 and 3000 series processors - Digi Power design - 10 Power Phase design Chipset - AMD X570 Memory - Dual Channel DDR4 Memory Technology - 4 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4066+(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200/2933/2667/2400/2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 non-ECC, un-buffered memory - Max. capacity of system memory: 128GB - 15 Gold Contact in DIMM Slots BIOS - 256Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP, VDDG, CPU Load-Line Calibration, CPU VDDCR_SOC Load-Line Calibration Voltage Multi-adjustment Graphics - Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. - Dual graphics output: support HDMI and DisplayPort 1.2 ports by independent display controllers - Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) 60Hz - Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.0 - Supports HDCP 2.2 with HDMI 2.0 and DisplayPort 1.2 Ports - Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and DisplayPort 1.2 Ports - Supports Microsoft PlayReady Actual support may vary by CPU The Max shared memory 16GB requires 32GB system memory installed. Audio - 7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio Codec) - Premium Blu-ray Audio support - Supports Surge Protection - ELNA Audio Caps - PCB Isolate Shieldingv - Individual PCB Layers for R/L Audio Channel LAN - Gigabit LAN 10/100/1000 Mb/s - Giga PHY Intel I211AT - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Slots AMD Ryzen series CPUs (Matisse) - 2 x PCI Express 4.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1) dual at x16 (PCIE1) / x4 (PCIE3)) AMD Ryzen series CPUs (Pinnacle Ridge) - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1) dual at x16 (PCIE1) / x4 (PCIE3)) AMD Ryzen series CPUs (Picasso) - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x8 (PCIE1) dual at x8 (PCIE1) / x4 (PCIE3)) - 2 x PCI Express 4.0 x1 Slots - Supports AMD Quad CrossFireX and CrossFireX - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module - 15 Gold Contact in VGA PCIe Slot (PCIE1) Supports NVMe SSD as boot disks Storage - 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280/22110 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso) - 1 x Hyper M.2 Socket (M2_3), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso) Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x COM Port Header - 1 x SPI TPM Header - 1 x Power LED and Speaker Header - 2 x RGB LED Headers - 1 x Addressable LED Header - 1 x CPU Fan Connector (4-pin) - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x Front Panel Audio Connector - 1 x AMD LED Fan USB Header - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 3 AIC Card R2.0 only) - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection) Rear Panel I/O - 3 x Antenna Ports (on I/O Panel Shield) - 1 x PS/2 Mouse/Keyboard Port - 1 x HDMI Port - 1 x DisplayPort 1.2 - 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (Supports ESD Protection) - 6 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software - ASRock Polychrome SYNC - ASRock Key Master - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash These utilities can be downloaded from ASRock Live Update APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 3 x Screws for M.2 Sockets Hardware Monitor - Temperature Sensing: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Tachometer: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, PREM VDDCR_SOC, +1.8V, VDDP Form Factor - ATX Form Factor: 12.0-in x 9.0-in, 30.5 cm x 22.9 cm - Solid Capacitor design - 2oz Copper PCB OS - Microsoft Windows 10 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)

MPN X570 TAICHI Unique Feature ASRock USB 3.2 Gen2 - ASRock Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s) - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s) - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s) ASRock Super Alloy - XXL Aluminum Alloy Heatsink - Premium 60A Power Choke - 50A Dr.MOS - Premium Memory Alloy Choke (Reduces 70% core loss compared to iron powder choke) - Combo Caps (Nichicon 12K Black Caps) - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) - I/O Armor - Matte Black PCB - High Density Glass Fabric PCB - 2oz Copper PCB Intel 802.11ax WiFi ASRock Steel Slots ASRock Full Coverage M.2 Heatsink ASRock Hyper M.2 (PCIe Gen4x4 SATA3) ASRock Ultra USB Power ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update APP Shop CPU - Supports AMD AM4 socket Ryzen 2000 and 3000 series processors - Intersil Digital PWM - 14 Power Phase design - Capable of providing extra 300W for CPU - Supports ASRock Hyper BCLK Engine II Chipset - AMD Premium X570 Memory - Dual Channel DDR4 Memory Technology - 4 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4666+(OC) / 4400(OC) / 4300(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3600+(OC) / 3466(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 non-ECC, un-buffered memory - Max. capacity of system memory: 128GB - 15 Gold Contact in DIMM Slots BIOS - 256Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, VCORE_NB, DRAM, VPPM, PCH 1.05V, +1.8V, VDDP, Voltage Multi-adjustment Graphics - Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. - Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.0 - Supports HDCP 2.2 with HDMI 2.0 Port - Supports 4K Ultra HD (UHD) playback with HDMI 2.0 Port - Supports Microsoft PlayReady Actual support may vary by CPU The Max shared memory 16GB requires 32GB system memory installed. Audio - 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec) - Premium Blu-ray Audio support - Supports Surge Protection - Supports Purity Sound 4 - Nichicon Fine Gold Series Audio Caps - NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets) - Pure Power-In - Direct Drive Technology - PCB isolate shielding - Impedance Sensing on Rear Out port - Individual PCB Layers for R/L Audio Channel - Gold Audio Jacks - 15 Gold Audio Connector - Supports DTS Connect LAN - Gigabit LAN 10/100/1000 Mb/s - GigaLAN Intel I211AT - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Wireless LAN - Intel 802.11ax WiFi Module - Supports IEEE 802.11a/b/g/n/ax - Supports Dual-Band (2.4/5 GHz) - Supports high speed wireless connections up to 2.4Gbps - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology - Supports Bluetooth 5.0 + High speed class II - Supports MU-MIMO Slots AMD Ryzen series CPUs (Matisse) - 3 x PCI Express 4.0 x16 Slots (PCIE1/PCIE3/PCIE5: single at x16 (PCIE1) dual at x8 (PCIE1) / x8 (PCIE3) triple at x8 (PCIE1) / x8 (PCIE3) / x4 (PCIE5)) AMD Ryzen series CPUs (Pinnacle Ridge) - 3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE5: single at Gen3x16 (PCIE1) dual at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) / Gen4x4 (PCIE5)) AMD Ryzen series CPUs (Picasso) - 1 x PCI Express 3.0 x16 Slot (single at x8 (PCIE1)) - 1 x PCI Express 4.0 x16 Slot (single at x4 (PCIE5)) - 2 x PCI Express 4.0 x1 Slots - Supports AMD Quad CrossFireX, 3-Way CrossFireX and CrossFireX - Supports NVIDIA Quad SLI and SLI - Supports NVIDIA NVLink with dual NVIDIA GeForce RTX series graphics cards - 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ax module (on the rear I/O) - 15 Gold Contact in VGA PCIe Slot (PCIE1) Supports NVMe SSD as boot disks 3-Way CrossFireX is only supported with Ryzen Series CPUs (Matisse and Pinnacle Ridge). NVIDIA NVLink Bridge does not come with the package. Please purchase it from NVIDIA if necessary. This feature is only supported with Ryzen Series CPUs (Matisse and Pinnacle Ridge). Storage - 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso) - 1 x Hyper M.2 Socket (M2_2), supports M Key type 2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) - 1 x Hyper M.2 Socket (M2_3), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) If M2_3 is occupied, PCIE5 slot will be disabled Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x SPI TPM Header - 1 x Power LED and Speaker Header - 1 x AMD Fan LED Header - 1 x RGB LED Header - 1 x Addressable LED Header - 1 x CPU Fan Connector (4-pin) - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) - 1 x 4 pin 12V Power Connector (Hi-Density Power Connector) - 1 x Front Panel Audio Connector (15 Gold Audio Connector) - 1 x AMD LED Fan USB Header - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 3 AIC Card R2.0 only) - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) - 1 x Front Panel Type C USB 3.2 Gen2 Header (Supports ESD Protection) - 1 x Dr. Debug with LED - 1 x Power Button with LED - 1 x Reset Button with LED - 1 x Clear CMOS Button Rear Panel I/O - 2 x Antenna Ports - 1 x PS/2 Mouse/Keyboard Port - 1 x HDMI Port - 1 x Optical SPDIF Out Port - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection) - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection) - 6 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - 1 x Clear CMOS Button - 1 x BIOS Flashback Button - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks) Ultra USB Power is supported on USB3_5_6 ports. ACPI wake-up function is not supported on USB3_5_6 ports. Software and UEFI Software - ASRock Polychrome SYNC - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash These utilities can be downloaded from ASRock Live Update APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD - 4 x SATA Data Cables - 1 x ASRock SLI_HB_Bridge_2S Card - 1 x ASRock WiFi 2.4/5 GHz Antenna - 1 x ASRock Screwdriver - 3 x Screws for M.2 Sockets - 3 x Standoffs for M.2 Sockets Hardware Monitor - Temperature Sensing: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Tachometer: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, VCORE_NB, DRAM, PCH 1.05V, +1.8V, VDDP Form Factor - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm - 2oz Copper PCB OS - Microsoft Windows 10 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)

MPN X470D4U MB Physical Status Form Factor mATX Processor System CPU AMD AM4 Socket Ryzen Series CPUs (Raven Ridge and Pinnacle Ridge) and Ryzen 7nm CPUs Socket AM4 PGA 1331 Chipset AMD Promontory X470 System Memory Capacity 4 x 288-pin DDR4 DIMM slots - Support up to 64GB DDR4 ECC/UDIMM - One DIMM: 1R DIMM at 2667MT/s 2R/2DR DIMM at 2400MT/s - Two DIMMs: (1) 1R DIMM at 2133 MT/s (2) 2R/2DR DIMM at 1866MT/s 1R and 2R/2DR DIMM each at 1866MT/s Type Dual Channel DDR4 memory technology - Support DDR4 ECC/UDIMM DIMM Size Per DIMM ECC/UDIMM: 64GB, 32GB, 16GB, 8GB DIMM Frequency ECC/UDIMM: 2666/2400/2133 MHz Voltage 1.2V Expansion Slot PCIe 3.0 x 16 PCIE6: Gen3 x16 link (splittable in x4/4/4/4) auto switch to x8 link when PCIE4 is occupied. - SLOT4: Gen3 x8 link PCIe 3.0 x 8 SLOT5: Gen3 x4 link Storage SATA Controller 6 x SATA3 6.0 Gb/s (1x SATA DOM port) Additional Storage Controller Asmedia 1061: 2x SATA3 6.0Gb/s M.2 slot 2 (2242/2260/2280/22110, supports SATA3 6.0Gb/s or PCIe 3.0 x2(M.2_2) and supports PCIe 2.0 x4 only(M.2_1)) Ethernet Interface 1000 /100 /10 Mbps by Intel i210 LAN Controller 2 x RJ45 GLAN by Intel i210 1 x RJ45 Dedicated IPMI LAN port Supports Wake-On-LAN Supports Energy Efficient Ethernet 802.3az Supports Dual LAN with Teaming function Supports PXE LAN1 supports NCSI Management BMC Controller ASPEED AST2500 IPMI Dedicated GLAN 1 x Realtek RTL8211E for dedicated management GLAN Features Watch Dog Graphics Controller ASPEED AST2500 VRAM DDR4 256MB Rear Panel I/O VGA Port 1 x D-Sub USB 3.1 Gen1 Port 2 Lan Port 2 x RJ45 Gigabit Ethernet LAN ports 1 x RJ45 Dedicated IPMI LAN port LAN Ports with LED (ACT/LINK LED and SPEED LED) Serial Port 1 UID Button/UID LED 1 Internal Connector COM Header N/A SATA DOM 1 M.2 2(M2_1: 2242/2260/2280/22110, PCIE(X4) M2_2:2242/2260/2280/22110, SATA/PCIE(X2)) Auxiliary Panel Header 1 (include C_CASEOPENSYSTEM_FAULT_LEDLAN1 LAN2 LED, location button LED,BMC alert ) TPM Header 1 IPMB Header 1 Buzzer 1 Fan Header 6 Fans x 4-pin (FAN1(CPU)/FAN2FAN6(5Front)) ATX Power 1x (24-pin) + 1x (8-pin) USB 3.1 (Gen1) Header 1 (supports 2 USB 3.1 Gen1 ports) USB 2.0 Header N/A Speaker Header N/A BMC_SMB Header 1 ME/SPS Recovery N/A Clear CMOS 1 (short pad) PSU SMB Header 1 Onboard LED 80 Debug Port LED 1 Fan Fail LED 6 (only Fan Fail LED) System BIOS BIOS Type 16MB AMI UEFI Legal BIOS BIOS Features Plug and Play (PnP) ACPI 2.0 Compliance Wake Up Events SMBIOS 2.8.0 Support ASRock Rack Instant Flash Hardware Monitor Temperature CPU/DDR temperature sensing MB/Card side temperature sensing Fan Fan Tachometer Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) Fan Multi-Speed Control Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,1.05V_PCH, +BAT, 3VSB, 5VSB Support OS OS Microsoft Windows: Windows 10 (64 bit) Linux: UBuntu 16.04.4 (64 bit) RedHat Enterprise Linux Server 7.3 (64bit) / 7.4 (64bit) Please refer to our website for the latest OS support list. On Linux system doesnt support Raid mode Support UEFI BOOT only Environment Temperature Operation temperature: 10 o C - 35 o C / Non operation temperature: -40 o C - 70 o C

MPN ROMED8U-2T Form Factor Micro-ATX Processor System CPU Support AMD EPYC TM 7003 and 7002 Series Processors - A BIOS update is required to support AMD EPYC TM 7003 Series Processors. Socket Single Socket SP3 (LGA4094) Chipset System on Chip System Memory Supported DIMM Quantity 8 DIMM slots (1DPC) Supported Type Supports DDR4 288-pin RDIMM, LRDIMM, RDIMM/LRDIMM-3DS Max. Capacity per DIMM RDIMM: up to 64GB LRDIMM: up to 128GB RDIMM/LRDIMM-3DS: up to 256GB DIMM Frequency RDIMM/ LRDIMM: max. 3200MHz Voltage 1.2V PCIe Expansion Slots (SLOT7 close to CPU) PCIe x 16 SLOT6: PCIe4.0 x16 SLOT5: PCIe4.0 x16 SLOT4: PCIe4.0 x16 Other PCIe Expansion Connectors M.2 slot 1 M-key (PCIe4.0 x4 or SATA 6Gb/s), supports 2280 form factor SlimSAS 2 SlimSAS (PCIe4.0 x8) SATA/SAS Storage PCH Built-in Storage AMD EPYC 7003/7002 (11 SATA 6Gb/s): 2 Mini-SAS HD, 2 SATA 7-pin, 1 M.2 Ethernet Additional GbE Controller 1 Intel X710-AT2: 2 RJ45 (10GbE) Server Management BMC Controller ASPEED AST2500 IPMI Dedicated GLAN 1 x Realtek RTL8211E for dedicated management GLAN Graphics Controller ASPEED AST2500 Rear I/O UID Button/LED 1 VGA Port 1 DB15 USB 3.2 Gen1 Port 2 Type-A (USB3.2 Gen1) RJ45 2 RJ45 (10GbE) Dedicate LAN 1 RJ45 (Dedicated IPMI) Internal Connector/Headers Other Power Connectors 1 (6-pin) for HDD power Auxiliary Panel Header 1 (18-pin): chassis intrusion, system fault LED, locate, SMBus System Panel 1 (9-pin): power switch, reset switch, system power LED, HDD activity LED NMI Button 1 COM Header 1 Speaker Header 1 Fan Header 6 (6-pin) Thermal Sensor Header 1 TPM Header 1 (13-pin, SPI), 1 (17-pin, LPC) SGPIO Header 1 HSBP 1 SMBus header 1 PMB header 1 IPMB Header 1 Clear CMOS 1 (contact pads) USB 3.2 (Gen1) Header 1 (19-pin, 2 USB3.2 Gen1) Power Connector 2 (8-pin, ATX 12V), 1 (4-pin, ATX) LED Indicators Standby PWR LED 5vsb 1 Fan Fail LED 6 BMC heartbeat LED 1 System BIOS BIOS Type 32MB AMI UEFI Legal BIOS BIOS Features Plug and Play (PnP), ACPI 2.0 Compliance Wake Up Events, SMBIOS 2.8.0, ASRock Rack Instant Flash Hardware Monitor Temperature CPU, Memory, MB, Card side Temperature Sensing Fan CPU/Rear/Front Fan Tachometer CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) CPU/Rear/Front Fan Multi-Speed Control" Voltage Voltage Monitoring: Vsoc,Vcpu, VCCM, VPPM, 3v/5v/12v, +BAT, 3VSB, 5VSB Environment Temperature Operation temperature: 10 o C to 35 o C / Non operation temperature: -40 o C to 70 o C Humidity Non operation humidity: 20% to 90% ( Non condensing)

MPN MBD-X12SPL-LN4F-O Form Factor ATX Processor CPU 3rd Gen Intel Xeon Scalable processors Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP Core Up to 40 cores System Memory Memory Capacity 8 DIMM slots Up to 2TB Intel Optane TM Persistent Memory 200 Series Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz, Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz Memory Type 3200/2933/2666MHz ECC 3DS , DDR4 LRDIMM, RDIMM DIMM Sizes 8GB, 16GB, 32GB, 64GB, 128GB, 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors On-Board Devices Chipset Intel C621A SATA Intel C621A controller for 10 SATA3 (6 Gbps) ports, RAID 0,1,5,10 IPMI ASPEED AST2600 BMC Graphics ASPEED AST2600 BMC Network Controllers Quad LAN with Intel i210 Gigabit Ethernet Controller Input / Output SATA 10 SATA3 (6Gbps) port(s) LAN 4 RJ45 Gigabit Ethernet LAN ports USB 6 USB 2.0 port(s) (4 via header, 2 rear) 5 USB 3.2 Gen1 port(s) (2 via header, 2 rear, 1 type A) Video Output 1 VGA port(s) Serial Port 1 COM Port(s) (1 header) DOM 2 SATA DOM (Disk on Module) power connector support TPM 1 TPM Header Expansion Slots PCI-E 1 PCI-E 4.0 x16, 1 PCI-E 4.0 x8 (in x16 slot), 2 PCI-E 4.0 x8, 3 PCI-E 3.0 x8 M.2 M.2 Interface: 1 SATA/PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI BIOS Features ACPI 6.2 SMBIOS 3.0 or later UEFI 2.7 Management Software SuperDoctor 5, SUM, KVM with dedicated LAN, SPM, Intel Node Manager, SSM, IPMI2.0, Watchdog Power Configurations Power-on mode for AC power recovery, ACPI Power Management, CPU thermal trip support for processor protection PC Health Monitoring Voltage VBAT, System temperature, Monitors CPU voltages, HT, Chassis intrusion header, 3.3V standby, +5V standby, +5V, +3.3V, +12V, +1.8V, 7-fan status LED UID/Remote UID Suspend static indicator LED CPU / System Overheat LED Temperature CPU thermal trip support PECI FAN 7x 4-pin fan headers (up to 7 fans) System level control PWM fan speed control Fan speed control Overheat LED indication Other Features WOL UID RoHS Chassis intrusion header Chassis intrusion detection ATX Power connector ACPI power management RoT Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -40 o C - 70 o C (-40 o F - 158 o F) Operating Relative Humidity Range 10% - 85% (non-condensing) Non Operating Relative Humidity Range 10% - 95% (non-condensing)

MPN MBD-X12SAE-5-O Physical Stats Form Factor ATX Dimensions 12" x 9.6" (30.48cm x 24.38cm) Processor/Cache CPU 10th Generation Intel Core i9/Core i7/Core i5/Core i3/Pentium/Celeron Processor, 11th Generation Intel Core i5/i7/i9 Processors, Intel Xeon W-1200 Processors, Intel Xeon W-1300 Processors Single Socket LGA-1200 (Socket H5) supported, CPU TDP supports Up to 125W TDP Cores / Cache Up to 8 cores System Memory Memory Capacity 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-3200MHz, in 4 DIMM slots Memory Type 128GB ECC/Non-ECC 3200MHz UDIMM DIMM Sizes 2GB, 4GB, 8GB, 16GB, 32GB Memory Voltage 1.2V On-Board Devices Chipset Intel W580 SATA Intel W580 controller for 4 SATA3 (6 Gbps) ports RAID 0,1,5,10 Network Controllers Single LAN with Intel Ethernet i225V Single LAN with Intel PHY I219LM LAN controller for AMT/vPro Audio ALC 888S HD Audio Input / Output LAN 1 RJ45 2.5 Gigabit Ethernet LAN port 1 RJ45 Gigabit Ethernet LAN ports USB 2 USB 2.0 ports (2 via headers) 2 USB 3.2 Gen1 ports (2 via headers) 4 USB 3.2 Gen2 ports (4 Rear Type A 2 USB 3.2 Gen2x2 ports (1 Type C) Video Output 1 DP 1.4a port, 1 HDMI 2.0b port, 1 DVI - D port Serial Port / Header 1 COM Port (1 header) TPM 1 TPM Header Expansion Slots PCI-E 2 PCI-E 4.0 x16 slots (16/NA or 8/8)2 PCI-E 3.0 x1 1 - 5V PCI 32bit M.2 M.2 Interface: 1 PCI-E 4.0 x4 and 2 PCI-E 3.0 x4, RAID 0 and 1 Form Factor: 2280/22110 Key: M-Key RAID 5 only applied for INTEL Storage Device System BIOS BIOS Type 256Mb SPI Flash with AMI BIOS BIOS Features ACPI 6.0 Plug and Play (PnP) BIOS rescue hot keys Riser card auto-detection support SMBIOS 3.0 or later Management Software AMT, SSM, SUM, SuperDoctor 5, vPro, Watchdog System Management Software SuperDoctor 5 Power Configurations ACPI Power Management Power-on mode for AC power recovery Power button override mechanism Wake-on-LAN PC Health Monitoring Voltage +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT Temperature N/A LED Power LED, Catastrophic Error LED Other Features 8-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion detection, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -20 o C - 60 o C (-4 o F - 140 o F)

MPN MBD-X12SPL-F-B Physical Stats Form Factor ATX Dimensions 12.1" x 10" (30.73cm x 25.4cm) Processor/Cache CPU 3rd Gen Intel Xeon Scalable processors Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP Cores / Cache Up to 40 cores System Memory Memory Capacity Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz Up to 2TB Intel Optane Persistent Memory, in 8 DIMM slots Memory Type 3200/2933/2666MHz ECC DDR4 RDIMM, LRDIMM DIMM Sizes 8GB, 16GB, 32GB, 64GB, 128GB, 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors On-Board Devices Chipset Intel C621A SATA Intel C621A controller for 10 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2600 BMC Network Controllers Dual LAN with Intel i210 Gigabit Ethernet Controller Graphics ASPEED AST2600 BMC Input / Output SATA 10 SATA3 (6Gbps) ports LAN 2 RJ45 Gigabit Ethernet LAN ports USB 6 USB 2.0 ports (2 rear + 4 via headers) 5 USB 3.2 Gen1 ports (2 rear + 2 via headers + 1 Type A) Video Output 1 VGA port Serial Port / Header 1 COM Port (1 header) TPM TPM Header Expansion Slots PCI-E 2 PCI-E 4.0 x8, 1 PCI-E 4.0 x16, 1 PCI-E 4.0 x8 (in x16 slot)3 PCI-E 3.0 x8 M.2 M.2 Interface: 1 SATA/PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI BIOS Features ACPI 6.2 SMBIOS 3.0 or later UEFI 2.7 Management Software Intel Node Manager, IPMI2.0, KVM with dedicated LAN, SPM, SSM, SUM, SuperDoctor 5, Watchdog Power Configurations ACPI Power Management CPU thermal trip support for processor protection Power-on mode for AC power recovery PC Health Monitoring Voltage +1.8V, +12V, +3.3V, +5V, +5V standby, 3.3V standby, 7-fan status, Chassis intrusion header, HT, Monitors CPU voltages, System temperature, VBAT Temperature PECI, CPU thermal trip support LED CPU / System Overheat LED, UID/Remote UID, Suspend static indicator LED Other Features ACPI power management, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, RoHS, RoT, UID, WOL Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -40 o C - 70 o C (-40 o F - 158 o F) Operating Relative Humidity Range 10% - 85% (non-condensing) Non-Operating Relative Humidity Range 10% - 95% (non-condensing)

MPN MBD-X12SPO-F-B Physical Stats Form Factor ATX Processor CPU 3rd Gen Intel Xeon Scalable processors Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP Core Up to 40 cores System Memory Memory Capacity 8 DIMM slots Up to 2TB Intel Optane Persistent Memory 200 Series Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz Memory Type 3200/2933/2666MHz ECC 3DS , DDR4 LRDIMM, RDIMM DIMM Sizes 8GB, 16GB, 32GB, 64GB, 128GB, 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors On-Board Devices Chipset Intel C621A SATA Intel C621A controller for 10 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2600 BMC Graphics ASPEED AST2600 BMC Network Controllers Dual LAN with Intel i350 Gigabit Ethernet Controller Input / Output SATA 10 SATA3 (6Gbps) port(s) LAN 2 RJ45 Gigabit Ethernet LAN ports USB 6 USB 2.0 port(s) (4 via header 2 rear) 5 USB 3.2 Gen1 port(s) (2 via header 2 rear 1 type A) Video Output 1 VGA port(s) Serial Port 2 COM Port(s) (1 header 1 rear) DOM 2 SATA DOM (Disk on Module) power connector support TPM 1 TPM Header Expansion Slots PCI-E 1 PCI-E 4.0 x16 M.2 M.2 Interface: 2 SATA/PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI BIOS Features ACPI 6.2 SMBIOS 3.0 or later UEFI 2.7 Management Software SuperDoctor 5, SUM, KVM with dedicated LAN, SPM, Intel Node Manager, SSM, IPMI2.0, Watchdog Power Configurations Power-on mode for AC power recovery, ACPI Power Management, CPU thermal trip support for processor protection PC Health Monitoring Voltage VBAT, System temperature, Monitors CPU voltages, HT, Chassis intrusion header, 3.3V standby, +5V standby, +5V, +3.3V, +12V, +1.8V, 7-fan status LED UID/Remote UID Suspend static indicator LED CPU / System Overheat LED Temperature CPU thermal trip support PECI FAN 7x 4-pin fan headers (up to 7 fans) System level control PWM fan speed control Fan speed control Overheat LED indication Other Features WOL UID RoHS Chassis intrusion header Chassis intrusion detection ATX Power connector ACPI power management RoT Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -40 o C - 70 o C (-40 o F - 158 o F) Operating Relative Humidity Range 10% - 85% (non-condensing) Non Operating Relative Humidity Range 10% - 95% (non-condensing)

MPN N7-B55XT-B1 CPU AMD Socket AM4 Ryzen Processors (3000, 4000, and 5000 Series Processors) Supported AMD Ryzen 5 3400G and Ryzen 3200G Not Supported Chipset AMD B550 Memory DIMM Slots 4 Max Memory Support 128GB Memory Architecture Dual-Channel OC Frequency (Vermeer CPUs) 4666+ MHz OC Frequency (Matisse CPUs) 4666+ MHz OC Frequency (Renoir APUs) 4733+ MHz Base Frequency 3200/ 2933/ 2667/ 2400/ 2133 Type ECC and non-ECC, un-buffered memory XMP Support Supported Integrated Graphics AMD Radeon Vega Series Graphics in Ryzen Series APU HDMI HDMI Max Resolution 4096x2160 at 60Hz Max Shared Memory 16GB with 32GB installed Microsoft PlayReady Supported Multi-GPU Support AMD 2-Way CrossFireX Technology Supported Expansion Slots PCIe x16 (x16 mode) 1 (Vermeer and Matisse - PCIe 4.0, Renoir - PCIe 3.0) PCIe x16 (x4 mode) 1 PCIe 3.0 x1 2 Storage (Chipset) M.2 Type 2242/2260/2280 (x4 mode) 1 (Vermeer and Matisse - PCIe 4.0, Renoir - PCIe 3.0) M.2 Type 2242/2260/2280 (PCIe 3.0 x2 and SATA mode) 1 SATA 6Gb/s 6x (M2_2 and SATA3_5_6 share lanes) RAID 0/1/5/10 Support Supported LAN Realtek RTL8125BG 2.5G Wireless Intel Dual-Band Wireless AX210 Wi-Fi 6E Protocol 802.11 a/b/g/n/ac/ax Frequency Bands 2.4 / 5 / 6GHz MU-MIMO Support Supported Bluetooth V5.2 Audio Realtek ALC1220 Codec Channels 8-Channel High Definition Audio Playback 32-bit / 192kHz DAC Capacitors Nichicon Fine Gold Series Rear I/O USB 3.2 Gen 2 (Type-C) 1 USB 3.2 Gen 2 (Type-A) 3 USB 3.2 Gen 1 (Type-A) 4 USB 2.0 2 HDMI 2.1 1 Wireless Antenna 2 (2T2R) LAN (RJ45) Port 1 5.1-Channel Audio Jacks 1 Optical S/PDIF 1 BIOS Flashback Button 1 Clear CMOS Button 1 Internal I/O M.2 (M Key), Type 2242/2260/2280 1 (PCIe 4.0/3.0 x4 mode), 1 (PCIe 3.0 x2 and SATA mode) M.2 (E Key) (For wireless cards) 1 SATA 6Gbps Ports 6 USB 3.2 Gen 2 Header (Type-C) 1 USB 3.2 Gen 1 Header 1 (Up to 2 ports) USB 2.0 Header 3 (Up to 6 ports) Front Panel Audio 1 CPU_FAN Connector 1 (Up to 24W) AIO_PUMP Connector 1 (Up to 24W) SYS_FAN Connector 5 (Up to 24W) NZXT RGB LED Header 2 5V ARGB Header 1 12V RGB Header 1 24-pin EATX Power 1 8-pin ATX 12V Power 1 4-pin ATX 12V Power 1 Power Button 1 Reset Button 1 POST LEDs 4 General Operating System Windows 10 64-bit Form Factor ATX

MPN PRO A520M-C II/CSM CPU AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors Refer to www.asus.com for CPU support list. Chipset AMD A520 Chipset Memory DDR4 4866(O.C.)/4600(O.C.)/4466(O.C.)/4400(O.C.)/4333(O.C.)/4266(O.C.)/4200(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/346(O.C.)/3400(O.C.)/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz, Un-buffered Memory Dual Channel Memory Architecture ECC memory (ECC mode) support varies by CPU. Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types. Graphics 1 x DisplayPort 1.2 1 x D-Sub 1 x DVI-D Graphics specifications may vary between CPU types. The DVI-D port and the DisplayPort cannot work at the same time. Only the DVI-D port functions when the two ports are both connected. Expansion Slots 1 x PCIe 3.0 x16 (x16 mode) AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors 1 x PCIe 3.0 x16 slot (supports x16 mode) AMD A520 Chipset 2 x PCIe 3.0 x1 slots 1 x PCI slot Storage Supports 1 x M.2 slot and 4 x SATA 6Gb/s ports AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 and SATA modes) AMD A520 Chipset 4 x SATA 6Gb/s ports Support RAID 0, 1, 10 Ethernet 1 x Realtek 1Gb Ethernet ASUS LANGuard USB Rear USB:Total 6 ports 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB:Total 6 ports 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Audio Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. Back Panel I/O Ports 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 1 x Realtek 1Gb Ethernet port 3 x Audio jacks 1 x COM port 1 x PS/2 Keyboard (purple) port 1 x PS/2 Mouse (green) port Intrernal I/O Connectors Fan and Cooling related 1 x 4-pin CPU Fan header 2 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 1 x M.2 slot (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 1 x Clear CMOS header 1 x Chassis Intrude header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x LPC debug header 1 x LPT header 1 x SMBUS header 1 x Speaker header 1 x 10-1 pin System Panel header Special Features ASUS Q-Design - ASUS Q-DIMM - ASUS Q-Slot ASUS Thermal Solution - Aluminum heatsink design ASUS EZ DIY - Box Headers Bespoke Motherboard Design and Business Focused Features - ASUS Self Recovering BIOS - ASUS Event Log - ASUS Commercial BIOS kit - Anti-Moisture Coating - 24/7 Reliability - Overcurrent Protection TPM 2.0 IC Onboard Software Features ASUS Exclusive Software IT Management software supported - ASUS Control Center Express(ACCE) BIOS 128 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PME, PXE Accessories Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x I/O Shield 1 x M.2 SSD screw package Installation Media 1 x Support DVD Documentation 1 x ACC Express Activation Key Card 1 x User manual Form Factor microATX 24.4cm x 22.9cm

MPN H610M-HDV/M.2 Unique Feature ASRock Super Alloy - Premium Power Choke - Sapphire Black PCB - High Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen3x4 and SATA3) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update and APP Shop CPU - Supports 12th Gen Intel Core TM Processors (LGA1700) - Digi Power design - 6 Power Phase design - Supports Intel Hybrid Technology - Supports Intel Turbo Boost Max 3.0 Technology Chipset - Intel H610 Memory - Dual Channel DDR4 Memory Technology - 2 x DDR4 DIMM Slots - Supports DDR4 non-ECC, un-buffered memory up to 3200 - Supports ECC UDIMM memory modules (operate in non-ECC mode) - Max. capacity of system memory: 64GB - Supports Intel Extreme Memory Profile (XMP) 2.0 BIOS - 128Mb AMI UEFI Legal BIOS with multilingual GUI support - ACPI 6.0 Compliant wake up events - SMBIOS 2.7 Support - CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V PROC, +0.82V PCH, +1.05V PCH Voltage Multi-adjustment Graphics - Intel Xe Graphics Architecture (Gen 12) - Three graphics output options: D-Sub, HDMI and DisplayPort 1.4 - Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) at 60Hz / 5K (5120x3200) at 120Hz - Supports D-Sub with max. resolution up to 1920x1200 at 60Hz - Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports Note: Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. Audio - 7.1 CH HD Audio (Realtek ALC897/887 Audio Codec) - Supports Surge Protection LAN - Gigabit LAN 10/100/1000 Mb/s - Giga PHY Intel I219V - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports UEFI PXE Slots - 1 x PCIe Gen4x16 Slot Note - 2 x PCIe Gen3x1 Slots - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module Note: Supports NVMe SSD as boot disks Storage - 4 x SATA3 6.0 Gb/s Connectors Note1 - 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2260/2280 SATA3 6.0 Gb/s and PCIe Gen3x4 (32 Gb/s) modes Note2 Note1: If M2_2 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled. Note2: Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x COM Port Header - 1 x SPI TPM Header - 1 x Chassis Intrusion and Speaker Header - 1 x CPU Fan Connector (4-pin) Note1 - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) Note2 - 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) Note3 - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x Front Panel Audio Connector - 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) Note1: The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. Note2: The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. Note3: The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CPU_FAN2/WP and CHA_FAN12/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O - 2 x Antenna Mounting Points - 1 x PS/2 Mouse/Keyboard Port - 1 x D-Sub Port - 1 x HDMI Port - 1 x DisplayPort 1.4 - 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 2 x USB 2.0 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software - ASRock Motherboard Utility (A-Tuning) - ASRock XFast LAN UEFI - ASRock EZ Mode - ASRock Full HD UEFI - ASRock My Favorites in UEFI - ASRock Instant Flash - ASRock Internet Flash Note: These utilities can be downloaded from ASRock Live Update and APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version) Accessories - Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 2 x Screws for M.2 Sockets Hardware Monitor - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans - CASE OPEN detection - Voltage monitoring: CPU Vcore, +1.05 PCH, DRAM, VCCIN AUX, +1.05V PROC, +0.82V PCH, +12V, +5V, +3.3V Form Factor - Micro ATX Form Factor: 9.6-in x 7.9-in, 24.4 cm x 20.1 cm - Solid Capacitor design OS - Microsoft Windows 10 64-bit / 11 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) Item Dimension (L inchxW inchxH inch) 11 x 10 x 3 Weight 3.00 lb

MPN MBD-M12SWA-TF-O Form Factor E-ATX Processor/Cache CPU Single AMD Ryzen TM Threadripper TM PRO 3000WX Series Processor Socket sWRX8/SP3 Supports CPU TDP up to 280W Cores Up to 64 Cores System Memory Memory Capacity 8 DIMM slots Supports up to 256GB Unbuffered non-ECC UDIMM or 2TB Registered ECC DDR 3200MHz SDRAM 8-channel memory bus Memory Type DDR4 3200 MHz Unbuffered non-ECC UDIMM/Registered ECC, 288-pin gold-plated DIMMs DIMM Sizes 8GB, 16GB, 32GB, 64GB, 128GB, 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) On-Board Devices Chipset AMD WRX80 SATA AMD WRX80 controller for 4 SATA3 (6 Gbps)ports, Software RAID 0,1,5,10 Network Controllers 10G LAN: Single LAN via Marvell AQC113C 10Gb controller 1GbE LAN: Single LAN via via Intel i210AT controller (shared with IPMI) IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2600 BMC Audio ALC4050H + ALC1220 7.1 Channel HD Audio Graphics ASPEED AST2600 BMC VGA connector is dedicated for IPMI Input / Output SATA 4 SATA3 (6 Gbps) ports LAN 1 RJ45 10GBase-T LAN port 1 RJ45 GbE LAN port (shared with IPMI) USB 1 USB 3.2 Gen2x2 port (Type C, 20Gbps) 5 USB 3.2 Gen2 ports (4 Type A, 1 front Intel Type C header, 10Gbps) 5 USB 3.2 Gen1 ports (3 Type A, 1 via header) 2 USB 2.0 via header VGA 1 VGA port (dedicated for IPMI) Others 1 COM port (rear) 1 TPM 2.0 header Expansion Slots PCI-Express 6 PCI-E 4.0 x16 slots M.2 Interface: 4 PCI-E 4.0 x4 Form factor: 2280, 22110 Key: M-key Software RAID 0,1,5,10 support U.2 Interface: 2 U.2 Sockets Software RAID 0,1 support Chassis ( Optimized for M12SWA-TF ) Tower/5U Rackmountable SCGS7A-2000B Server(s) (with M12SWA-TF) Model(s) AS -5014A-TT System BIOS BIOS Type AMI 256Mb Flash EEPROM Management Software Super Doctor 5 Watch Dog SUM IPMI, KVM with shared LAN Power Configurations ACPI Power Management Power button override mechanism Keyboard wakeup from S5 S3/S4 PC Health Monitoring CPU Monitors CPU Core Voltages, +3.3V, +12V, +3.3Vstb, +5Vstb, Vcore, Vmem Supports system management utility FAN Up to 10 4-pin fan headers Status monitor for speed control Temperature Monitoring for CPU and chassis environment CPU Thermal Trip Support I 2 C Temperature Sensing Logic LED CPU / System Overheat LED Other Features Chassis Intrusion Detection Chassis Intrusion Header Operating Environment / Compliance Environmental Specifications Operating Temperature: 0 o C to 50 o C (32 o F to 122 o F) Non-operating Temperature: -5 o C to 55 o C (23 o F to 131 o F) FCC class B

MPN PRO B550M-C/CSM CPU AMD AM4 Socket for AMD Ryzen TM 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors Chipset AMD B550 Memory AMD Ryzen TM 5000 Series/ 3000 Series Desktop Processors 4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory AMD Ryzen TM 4000 G-Series Desktop Processors 4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory Dual Channel Memory Architecture ECC Memory (ECC mode) support varies by CPU. Graphic 2 x DisplayPort 1 x HDMI 2.1(4K at 60HZ) Graphics specifications may vary between CPU types. Expansion Slots AMD Ryzen TM 5000 Series/ 3000 Series Desktop Processors 1 x PCIe 4.0 x16 (x16 mode) AMD Ryzen TM 4000 G-Series Desktop Processors 1 x PCIe 3.0 x16 (x16 mode) AMD B550 Chipset 1 x PCIe 3.0 x4 1 1 x PCI Support PCIe bifurcation for RAID on CPU function. Storage Total supports 2 x M.2 slot(s) and 4 x SATA 6Gb/s ports AMD Ryzen TM 5000 Series/ 3000 Series Desktop Processors : 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support AMD RyzenTM 4000 G-Series Processors : 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support AMD B550 Chipset : 1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support 4 x SATA 6Gb/s port(s), Support Raid 0, 1, 10 LAN Realtek RTL8111H 1Gb Ethernet Audio Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Choose the chassis with HD audio module in front panel to support 8-channel audio output. USB Ports Rear USB Port ( Total 6 ) 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C) 2 x USB 3.2 Gen 1 port(s)(2 x Type-A) 2 x USB 2.0 port(s)(2 x Type-A) Front USB Port ( Total 7 ) 4 x USB 3.2 Gen 1 port(s)(4 x Type-A) 3 x USB 2.0 port(s) Software Features ASUS Exclusive Software IT Management software supported - ASUS Control Center Express(ACCE) ASUS Special Features ASUS Q-Design - ASUS Q-DIMM - ASUS Q-Slot ASUS Thermal Solution - Aluminum heatsink design ASUS EZ DIY - Box Headers Bespoke Motherboard Design and Business Focused Features - ASUS Self Recovering BIOS - ASUS Event Log - ASUS Commercial BIOS kit - Anti-Moisture - 24/7 Reliability - Overcurrent Protection TPM2.0 IC Onboard Back I/O Ports 1 x Realtek RTL8111H 1 x PS/2 keyboard (purple) 1 x PS/2 mouse (green) 2 x DisplayPort 1 x HDMI 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C) 2 x USB 3.2 Gen 1 Type-A 2 x USB 2.0 3 x Audio jack(s) Internal I/O Ports 1 x CPU Fan connector(s) 2 x Chassis Fan connector(s) 2 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.2 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 3 USB 2.0 port(s) 2 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode and X4 PCIE mode) 1 x M.2 with E key for Wi-Fi module 1 x LPT header 4 x SATA 6Gb/s connector(s) 1 x Thunderbolt header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors 1 x Front panel audio connector(s) (AAFP) 1 x SMBus header(s) 1 x System panel(s) 1 x Clear CMOS jumper(s) 1 x COM port header 1 x Chassis intrusion header 1 x LPC Debug header 1 x Speaker connector Accessories 1 x ACC Express Activation Key Card I/O Shield 2 x SATA 6Gb/s cable(s) 1 x Supporting DVD User manual 3 x M.2 SSD screw package(s) 2 x M.2 SSD Hex screw packages BIOS 256 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PXE Operating System Windows 10 64-bit Form Factor mATX Form Factor 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm ) Note 1 The PCIe x4 slot runs x2 mode when the PCI slot is occupied.

MPN MBD-H12SSL-NT-B Physical Stats Form Factor ATX Processor/Chipset CPU Single AMD EPYC TM 7002 series Processor Socket SP3 Cores Up to 64 Cores Chipset System on Chip System Memory Memory Capacity 8 DIMM slots Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM 8-channel memory bus Memory Type DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs DIMM Sizes 8GB, 16GB, 32GB, 64GB, 128GB, 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) On-Board Devices SATA SATA3 (6 Gbps) IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2500 BMC Network Controllers Dual 10GBase-T LAN via Broadcom BCM57416 1 Realtek RTL8211F PHY (dedicated IPMI) VGA ASPEED AST2500 BMC Input / Output SATA/NVMe Hybrid 2 SlimSAS x8 (each: 8 SATA3 or 2 NVMe) LAN Dual 10GBase-T LAN ports 1 RJ45 Dedicated IPMI LAN port USB 6 USB 3.0 ports (4 rear + 2 via header) VGA 1 VGA port Others 1 COM port (rear) 2 SATA DOM power connectors 1 TPM 2.0 header Expansion Slots PCI-Express 5 PCI-E 4.0 x16 2 PCI-E 4.0 x8 M.2 Interface: 2 PCI-E 4.0 x4 Form factor: 2280, 22110 Key: M-key System BIOS BIOS Type AMI 256Mb SPI Flash EEPROM BIOS Features Plug and Play (PnP) DMI 2.3 PCI 2.2 ACPI 5.1 USB Keyboard Support SMBIOS 3.1.1 Management Software Super Doctor 5 Watch Dog NMI SUM IPMI 2.0, KVM with dedicated LAN Power Configurations ACPI Power Management Power-on mode control for AC power loss recovery PC Health Monitoring CPU Monitors CPU Core Voltages, +3.3V, +5V, +5V standby, +3.3V standby CPU switching voltage regulator Supports system management utility VBAT FAN Up to 7-fan status tachometer monitoring Up to 7 4-pin fan headers Dual Cooling Zone Status monitor for speed control Pulse Width Modulated (PWM) fan connectors Temperature Monitoring for CPU and chassis environment CPU Thermal Trip Support Thermal control for 7x Fan connectors I 2 C Temperature Sensing Logic LED CPU / System Overheat LED Other Features Chassis Intrusion Detection Chassis Intrusion Header UID Operating Environment / Compliance Environmental Specifications Operating Temperature: 10 o C to 35 o C (50 o F to 95 o F) Non-operating Temperature: -40 o C to 70 o C (-40 o F to 158 o F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)

MPN MBD-H12SSL-C-B Physical Stats Form Factor ATX Processor/Chipset CPU Single AMD EPYC TM 7002 series Processor Socket SP3 Cores Up to 64 Cores Chipset System on Chip System Memory Memory Capacity 8 DIMM slots Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM 8-channel memory bus Memory Type DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs DIMM Sizes 8GB, 16GB, 32GB, 64GB, 128GB, 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) On-Board Devices SATA SATA3 (6 Gbps) SAS Broadcom 3008 SAS3 (12 Gbps) controller RAID 0, 1, 10 IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2500 BMC Network Controllers Dual gigabit LAN via Broadcom BCM5720 1 Realtek RTL8211F PHY (dedicated IPMI) VGA ASPEED AST2500 BMC Input / Output SATA 8 SATA3 (6 Gbps) ports SAS 2 SAS3 (12 Gbps) ports LAN 2 RJ45 Gigabit Ethernet LAN ports 1 RJ45 Dedicated IPMI LAN port USB 6 USB 3.0 ports (4 rear + 2 via header) VGA 1 VGA port Others 1 COM port (rear) 2 SATA DOM power connectors 1 TPM 2.0 header Expansion Slots PCI-Express 5 PCI-E 4.0 x16 2 PCI-E 4.0 x8 M.2 Interface: 2 PCI-E 4.0 x4 Form factor: 2280, 22110 Key: M-key System BIOS BIOS Type AMI 256Mb SPI Flash EEPROM BIOS Features Plug and Play (PnP) DMI 2.3 PCI 2.2 ACPI 5.1 USB Keyboard Support SMBIOS 3.1.1 Management Software Super Doctor 5 Watch Dog NMI SUM IPMI 2.0, KVM with dedicated LAN Power Configurations ACPI Power Management Power-on mode control for AC power loss recovery PC Health Monitoring CPU Monitors CPU Core Voltages, +3.3V, +5V, +5V standby, +3.3V standby CPU switching voltage regulator Supports system management utility VBAT FAN Up to 7-fan status tachometer monitoring Up to 7 4-pin fan headers Dual Cooling Zone Status monitor for speed control Pulse Width Modulated (PWM) fan connectors Temperature Monitoring for CPU and chassis environment CPU Thermal Trip Support Thermal control for 7x Fan connectors I 2 C Temperature Sensing Logic LED CPU / System Overheat LED Other Features Chassis Intrusion Detection Chassis Intrusion Header UID Operating Environment / Compliance Environmental Specifications Operating Temperature: 10 o C to 35 o C (50 o F to 95 o F) Non-operating Temperature: -40 o C to 70 o C (-40 o F to 158 o F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)

MPN SPC621D8-2L2T Form Factor ATX Processor System CPU Supports 3rd Gen Intel Xeon Scalable processors Socket Single Socket P+ (LGA 4189) Chipset Intel C621A System Memory Supported DIMM Quantity 8 DIMM slots (1DPC) Supported Type Supports DDR4 288-pin RDIMM, LRDIMM, RDIMM/LRDIMM-3DS, Intel Optane TM Persistent Memory 200 series Max. Capacity per DIMM RDIMM: up to 64GB RDIMM-3DS: up to 256GB LRDIMM: up to 128GB LRDIMM-3DS: up to 256GB DIMM Frequency max. 3200MHz Voltage 1.2V PCIe Expansion Slots (SLOT7 close to CPU) PCIe x 16 SLOT7: PCIe4.0 x16 SLOT5: PCIe4.0 x16 SLOT3: PCIe4.0 x16 SLOT1: PCIe4.0 x16 Note: SLOT7/5/3 auto-switch to PCIe4.0 x8 when SLOT6/4/2 occupied PCIe x 8 SLOT6: PCIe4.0 x8 SLOT4: PCIe4.0 x8 SLOT2: PCIe4.0 x8 Other PCIe Expansion Connectors M.2 slot 1 M-key (PCIe3.0 x4 or SATA 6Gb/s), supports 22110/2280/2242 form factor 1 M-key (PCIe3.0 x1 or SATA 6Gb/s), supports 22110/2280/2242 form factor SATA/SAS Storage PCH Built-in Storage Intel C621A (8 SATA 6Gb/s RAID 0/1/5/10): 1 Mini-SAS HD, 2 SATA DOM, 2 M.2 Ethernet Additional GbE Controller Intel X710-AT2: 2 RJ45 (10 GbE) Intel i210: 2 RJ45 (1GbE) Server Management BMC Controller ASPEED AST2500 IPMI Dedicated GLAN 1 x Realtek RTL8211E for dedicated management GLAN Graphics Controller ASPEED AST2500 VRAM DDR4 16MB Rear I/O UID Button/LED 1 VGA Port 1 DB15 USB 3.2 Gen1 Port 4 Type-A (USB3.2 Gen1) RJ45 2 RJ45 (10GbE), 2 RJ45 (1GbE) Dedicate LAN 1 dedicated IPMI Internal Connector/Headers Auxiliary Panel Header 1 (18-pin): chassis intrusion, system fault LED, LAN1/LAN2 activity LED, locate, SMBus System Panel 1 (9-pin): power switch, reset switch, system power LED, HDD activity LED COM Header 1 Video output 1 Speaker Header 1 Buzzer 1 Fan Header 5 (6-pin) Thermal Sensor Header 1 TPM Header 1 (17-pin, LPC), 1 (13-pin, SPI) VROC header 1 SGPIO Header 1 SMBus header 1 PMB header 1 IPMB Header 1 Clear CMOS 1 (contact pads) USB 3.2 (Gen1) Header 1 (19-pin, 2 USB3.2 Gen1) USB 3.2 (Gen2) Header 2 (Type-C, 2 USB3.2 Gen2) USB 2.0 Header 1 (9-pin, 2 USB2.0) Type A USB 2.0 Port 1 (Type-A, 1 USB2.0) NMI Header 1 Power Connector 1 (24-pin, ATX main power), 1 (8-pin, ATX 12V), 1 (4-pin, ATX 12V), 1 (3-pin, SATA power) ME/SPS Recovery 1 NC-SI 1 LED Indicators Standby PWR LED 5vsb 1 80 Debug Port LED 1 Fan Fail LED 5 LED Indicators Standby PWR LED 5vsb 1 80 Debug Port LED 1 Fan Fail LED 5 Hardware Monitor Temperature CPU, PCH, MB, Card side Temperature Sensing Fan CPU/Rear/Front Fan Tachometer CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) CPU/Rear/Front Fan Multi-Speed Control Voltage +12V, +5V, +3.3V, CPU Vcore, DRAM, 1.05V_PCH, +BAT, 3.3VSB, 5VSB Environment Temperature Operation temperature: 10 o C to 35 o C / Non operation temperature: -40 o C to 70 o C Humidity Non operation humidity: 20% to 90% ( Non condensing)

MPN B550MPVDHWIFI SOCKET AMD Socket AM4 CPU (MAX SUPPORT) Support for 3rd Gen AMD Ryzen TM processors and future AMD Ryzen TM processors with BIOS update CHIPSET AMD B550 Chipset DDR4 MEMORY 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400 + Mhz by JEDEC and A-XMP OC MODE MEMORY CHANNEL Dual DIMM SLOTS 4 MAX MEMORY (GB) 128 PCI-E X16 1 PCI-E GEN Gen4 / Gen3 PCI-E X1 2 SATAIII 4 M.2 SLOT 2 RAID 0/1/10 TPM (HEADER) 1 LAN 1x Realtek RTL8111HN Gigabit LAN USB 3.2 PORTS (FRONT) 1(Gen 1, Type C), 2(Gen 1, Type A) USB 3.2 PORTS (REAR) 4(Gen 1, Type A) USB 2.0 PORTS (FRONT) 4 USB 2.0 PORTS (REAR) 2 SERIAL PORTS(FRONT) 1 AUDIO PORTS (REAR) 3 HD audio connectors DISPLAYPORT 1 VGA 1 HDMI 1 DIRECTX 12 FORM FACTOR MATX OPERATING SYSTEM Support for Windows 10 64-bit

MPN B550APRO SOCKET AM4 CPU (MAX SUPPORT) RYZEN 9 CHIPSET AMD B550 Chipset DDR4 MEMORY 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400 + Mhz by JEDEC and A-XMP OC MODE MEMORY CHANNEL Dual DIMM SLOTS 4 MAX MEMORY (GB) 128 PCI-E X16 2 PCI-E GEN Gen4 / Gen3 PCI-E X1 2 SATAIII 6 M.2 SLOT 2 RAID 0/1/10 TPM (HEADER) 1 LAN 1x Realtek RTL8111H Gigabit LAN USB 3.2 PORTS (FRONT) 1(Gen 1, Type C), 2(Gen 1, Type A) USB 3.2 PORTS (REAR) 1(Gen 2, Type C), 1(Gen 2, Type A), 2(Gen 1, Type A) USB 2.0 PORTS (FRONT) 4 USB 2.0 PORTS (REAR) 4 SERIAL PORTS(FRONT) 1 AUDIO PORTS (REAR) 6 HD audio connectors DISPLAYPORT 1 HDMI 1 DIRECTX 12 FORM FACTOR ATX CROSSFIRE Y OPERATING SYSTEM Support for Windows 10 64-bit

MPN B550M-HDV Unique Feature ASRock Super Alloy - Premium 50A Power Choke - Sapphire Black PCB - High Density Glass Fabric PCB ASRock Hyper M.2 (PCIe Gen4x4) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update and APP Shop CPU - Supports 3 rd Gen AMD AM4 Ryzen TM / future AMD Ryzen TM Processors note1 - 6 Power Phase design Note1: Not compatible with AMD Ryzen TM 5 3400G and Ryzen TM 3 3200G. Chipset - AMD B550 Memory - Dual Channel DDR4 Memory Technology - 2 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC and non-ECC, un-buffered memory - AMD Ryzen series APUs support DDR4 4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC and non-ECC, un-buffered memory - Max. capacity of system memory: 64GB note2 - Supports Extreme Memory Profile (XMP) memory modules - 15Mu Gold Contact in DIMM Slots SR: Single rank DIMM, 1Rx4 or 1Rx8 on DIMM module label DR: Dual rank DIMM, 2Rx4 or 2Rx8 on DIMM module label Note2: Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS - 256Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, CPU VDDCR_SOC, DRAM, VDDP Voltage Multi-adjustment Graphics - Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU note1 - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. note2 - Three graphics output options: D-Sub, DVI-D and HDMI - Supports Triple Monitor - Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports DVI-D with max. resolution up to 1920x1200 at 60Hz - Supports D-Sub with max. resolution up to 1920x1200 at 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.1 - Supports HDCP 2.3 with DVI-D and HDMI 2.1 Ports - Supports 4K Ultra HD (UHD) playback with HDMI 2.1 Port - Supports Microsoft PlayReady Note1: Actual support may vary by CPU Note2: The Max shared memory 16GB requires 32GB system memory installed. Audio - 7.1 CH HD Audio (Realtek ALC887 Audio Codec) - Supports Surge Protection LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s - Realtek RTL8111H - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Slots AMD Ryzen series CPUs (Matisse) - 1 x PCI Express 4.0 x16 Slot (PCIE1: x16 mode) note1 AMD Ryzen series APUs - 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode) note1 - 1 x PCI Express 3.0 x1 Slot Note1: Supports NVMe SSD as boot disks Storage - 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) note1 Note1: Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x SPI TPM Header - 1 x COM Port Header - 1 x Chassis Intrusion and Speaker Header - 1 x CPU Fan Connector (4-pin) note1 - 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control) note2 - 1 x 24 pin ATX Power Connector - 1 x 4 pin 12V Power Connector - 1 x Front Panel Audio Connector - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) Note1: The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. Note2: The Chassis Fan supports the water cooler fan of maximum 1A (12W) fan power. CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O - 1 x PS/2 Mouse/Keyboard Port - 1 x D-Sub Port - 1 x DVI-D Port - 1 x HDMI Port - 2 x USB 2.0 Ports (Supports ESD Protection) - 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software - ASRock Motherboard Utility (A-Tuning) - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash Note: These utilities can be downloaded from ASRock Live Update and APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 1 x Screw for M.2 Socket Hardware Monitor - Temperature Sensing: CPU, Chassis Fans - Fan Tachometer: CPU, Chassis Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis Fans - Fan Multi-Speed Control: CPU, Chassis Fans - CASE OPEN detection - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor - Micro ATX Form Factor: 9.0-in x 7.9-in, 23.0 cm x 20.1 cm - Solid Capacitor design OS - Microsoft Windows 10 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)

MPN B550 PHANTOM GAMING 4 AC Gaming Armor Memory - 15Mu Gold Contact in DIMM Slots Cooling - XXL Aluminum Alloy Heatsink Audio - Nahimic Audio Unique Feature ASRock Super Alloy - XXL Aluminum Alloy Heatsink - Premium 50A Power Choke - Sapphire Black PCB - High Density Glass Fabric PCB - 2oz Copper PCB Intel 802.11ac WiFi ASRock Steel Slot Gen4 ASRock Hyper M.2 (PCIe Gen4x4) ASRock POST Status Checker (PSC) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update and APP Shop CPU - Supports 3 rd Gen AMD AM4 Ryzen TM / future AMD Ryzen TM Processors note1 - Digi Power design - 8 Power Phase design Note1: Not compatible with AMD Ryzen TM 5 3400G and Ryzen TM 3 3200G. Chipset - AMD B550 Memory - Dual Channel DDR4 Memory Technology - 4 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4533+(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC and non-ECC, un-buffered memory - AMD Ryzen series APUs support DDR4 4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC and non-ECC, un-buffered memory - Max. capacity of system memory: 128GB note2 - Supports Extreme Memory Profile (XMP) memory modules - 15Mu Gold Contact in DIMM Slots SR: Single rank DIMM, 1Rx4 or 1Rx8 on DIMM module label x is equal to 1 or 2 DR: Dual rank DIMM, 2Rx4 or 2Rx8 on DIMM module label Note2: Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS - 256Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, CPU VDDCR_SOC, DRAM, VPPM, 1.05V_PROM_S5, 2.5V_PROM, +1.8VSB, VDDP Voltage Multi-adjustment Graphics - Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU note1 - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. note2 - Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.1 - Supports HDCP 2.3 with HDMI 2.1 Port - Supports 4K Ultra HD (UHD) playback with HDMI 2.1 Port - Supports Microsoft PlayReady Note1: Actual support may vary by CPU Note2: The Max shared memory 16GB requires 32GB system memory installed. Audio - 7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio Codec) - Premium Blu-ray Audio support - Supports Surge Protection - PCB Isolate Shielding - Individual PCB Layers for R/L Audio Channel - Nahimic Audio LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s - Realtek RTL8111H - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Wireless LAN - Intel 802.11ac WiFi Module - Supports IEEE 802.11a/b/g/n/ac - Supports Dual-Band (2.4/5 GHz) - Supports high speed wireless connections up to 433Mbps - Supports Bluetooth 4.2 + High speed class II Slots AMD Ryzen series CPUs (Matisse) - 2 x PCI Express x16 Slots (PCIE1: Gen4x16 mode, PCIE3: Gen3 x4 mode) note1 AMD Ryzen series APUs - 2 x PCI Express x16 Slots (PCIE1: Gen3x16 mode, PCIE3: Gen3 x4 mode) note1 - 2 x PCI Express 3.0 x1 Slots - Supports AMD Quad CrossFireX TM and CrossFireX TM - 1 x M.2 Socket (Key E) with the bundled WiFi-802.11ac module Note1: Supports NVMe SSD as boot disks Storage - 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2260/2280/22110 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) note1 Note1: Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x COM Port Header - 1 x SPI TPM Header - 1 x Power LED and Speaker Header - 2 x RGB LED Headers note1 - 2 x Addressable LED Headers note2 - 1 x CPU Fan Connector (4-pin) note3 - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) note4 - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x 4 pin 12V Power Connector - 1 x Front Panel Audio Connector - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) Note1: Support in total up to 12V/3A, 36W LED Strip Note2: Support in total up to 5V/3A, 15W LED Strip Note3: The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. Note4: The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP, CHA_FAN3/WP and CHA_FAN4/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O - 2 x Antenna Ports - 1 x PS/2 Mouse/Keyboard Port - 1 x HDMI Port - 6 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software - ASRock Motherboard Utility (Phantom Gaming Tuning) - ASRock Polychrome SYNC - ASRock Key Master - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash Note: These utilities can be downloaded from ASRock Live Update and APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 2 x ASRock WiFi 2.4/5 GHz Antennas - 1 x Screw for M.2 Socket Hardware Monitor - Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, VPPM, 1.05V_PROM_S5, +1.8V, VDDP Form Factor - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm - Solid Capacitor design - 2oz Copper PCB OS - Microsoft Windows 10 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)

MPN ROMED8-2T MB Physical Status Form Factor - ATX Processor System CPU - AMD EPYC TM 7002/7001 series processor family - max 225W Socket - Single Socket SP3 (LGA4094) System Memory Capacity - 8 DIMM slots Type - Eight Channel DDR4 memory technology - Supports DDR4 RDIMM and LRDIMM DIMM Size Per DIMM - RDIMM: 64GB note1 ,32GB, 16GB, 8GB note1 - LRDIMM: 256GB note1 ,128GB, 64GB note2 - NV DIMM:32GB note3 Note1: 64GB wait device to validate Note2: 256GB wait device to validate Note3: wait device to validate DIMM Frequency - RDIMM: 3200/2933/2666/2400MHz - LRDIMM: 3200/2933/2666/2400MHz - NV DIMM: 3200/2666/2400MHz note1 Note1: wait device to validate Voltage - 1.2V Expansion Slot PCIe 4.0 x 16 - PCIE1: Gen4 x16 link - PCIE2: Gen4 x16 link or Gen4x8 link+2x M.2+2x miniSASHD or no PCIE slot +2x OCulink+2xM.2+2x miniSASHD(by jumper) - PCIE3: Gen4 x16 link - PCIE4: Gen4 x16 link - PCIE5: Gen4 x16 link - PCIE6: Gen4 x16 link - PCIE7: Gen4 x16 link Storage SATA Controller - 8 x SATA3 6.0 Gb/s (SATA_0_3:by miniSASHD.SATA_3 share with SATA_8(by BOM option), SATA_4_7: by miniSASHD,share with PCIE2 by Jumper) OCuLink for U.2 - 2( OCU1 and OCU2, share with PCIE2 by Jumper) Ethernet Interface - 10000/1000 /100 Mbps by Intel X550-AT2 LAN Controller - 2 x RJ45 10G base-T by Intel X550-AT2 - 1 x RJ45 Dedicated IPMI LAN port by RTL8211E - Supports Wake-On-LAN - Supports Energy E_cient Ethernet 802.3az - Supports Dual LAN with Teaming function - Supports PXE - LAN1 supports NCSI Management BMC Controller - ASPEED AST2500 IPMI Dedicated GLAN - 1 x Realtek RTL8211E for dedicated management GLAN Features - Watch Dog - NMI Graphics Controller - ASPEED AST2500 VRAM - DDR4 512MB Rear Panel I/O VGA Port - 1 x D-Sub USB 3.1 Gen1 Port - 2 USB 3.1 Gen2 Port - 1(Type C) Lan Port - 2+1 RJ45 Gigabit Ethernet LAN port - LAN Ports with LED (ACT/LINK LED and SPEED LED) Serial Port - 1 x COM port UID Button/UID LED - 1 Internal Connector SATA DOM - 1(BOM option) M.2 - 2(M2_1(share with PCIE2 by Jumper): 2230/2242/2260/2280, SATA/PCIE Gen4(X4),M2_2:2230/2242/2260/2280/22110, SATA/PCIE(X4)) Auxiliary Panel Header - 1 (includes chassis intrusion, location button and LED, and front LAN LED) TR1 Header - 1 TPM Header - 1 IPMB Header - 1 Fan Header - 7 Fans x 6-pin (1CPU/4Front/2Rear) ATX Power - 1 x (24-pin) + 1 x (8-pin) + 1 x (4-pin) + 1 x (6-pin)(6 pin for GPU for PCIE Slot) USB 3.1 (Gen1) Header - 1 (supports 2 USB 3.0 ports) USB 3.1 (Gen2) Header - 1 (supports 2 USB 3.0 ports) NMI Button - 1 Front Panel - 1(rst, pwrbtn, hddled, pwrled) Speaker Header - 1(4pin) BMC_SMB Header - 1 Clear CMOS - 1 PSU SMB Header - 1 Onboard LED Fan Fail LED - 7 System BIOS BIOS Type - 32MB AMI UEFI Legal BIOS BIOS Features - Plug and Play (PnP) - ACPI 2.0 Compliance Wake Up Events - SMBIOS 2.8 Support - ASRock Rack Instant Flash Hardware Monitor Temperature - CPU Temperature Sensing - MB/TR1/Card side Temperature Sensing Fan - CPU/Rear/Front Fan Tachometer - CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU Temperature) - CPU/Rear/Front Fan Multi-Speed Control Voltage - Voltage Monitoring: Vsoc,Vcpu, VCCM, VPPM, 3V/5V/12V, +BAT, 3VSB, 5VSB Environment Temperature Operation temperature: 10 o C - 35 o C / Non operation temperature: -40 o C - 70 o C
