Computer Components&Parts

MPN 400-HY-CX36-V1 Waterblock Premium Retention parts for Intel LGA1700/1200/115X AMD retention ring for AM5/AM4/TR4 (bracket not included) Material: 100% Copper LED: Fully-controllable 2.1" 480 x 480 RGB LCD Display Pump Noise Level: 20dB(A) (MAX) LCD Display Size: 2.1 Radiator Material: Aluminum Fan Bearing: Hydro-Dynamic Bearing Speed: 0-2580 RPM Airflow: 73.15 CFM (MAX) Static Pressure: 3.77 mm-H2O (MAX) Noise Level: 35.0 dB(A) (MAX) LED: Fully-customizable ARGB

Physical Stats Form Factor Micro-ATX Processor CPU 12th Generation Intel Core i9/Core i7/Core i5/Core i3/Pentium/Celeron Processor Single Socket LGA-1700 supported Core Up to 16 cores System Memory Memory Capacity 4 DIMM slots Up to 128GB UDIMM, DDR5-4400MHz Supports up to 128GB of DDR5 UDIMM with speeds of up to 4400MT/s with one DIMM, or 4000MT/s with two DIMM single rank, or 3600MT/s with two DIMM dual rank in four memory slots Memory Type 4400/4000/3600MHz DIMM Sizes 4GB, 8GB, 16GB, 32GB Memory Voltage 1.1V On-Board Devices Chipset Intel Q670E SATA Intel Q670E controller for 4 SATA3 (6 Gbps) ports RAID 0,1,5,10 Audio ALC 888S HD Audio Network Controllers Dual LAN with Intel Ethernet i225LM Input / Output SATA 4 SATA3 (6Gbps) port(s) USB 2 USB 2 port(s) (2 via header) 6 USB 3.1 Gen2 port(s) (2 via header 4 rear type A) 2 USB 3.1 Gen1 port(s) (2 via header) Video Output 1 DVI - D port(s), 1 HDMI 2.0b port(s), 2 DP (DisplayPort) port(s) Serial Port 4 COM Port(s) (2 header RS232/422/485 2 header RS232) TPM TPM Header and Chip both Expansion Slots PCI-E 1 PCI-E 5.0 x16, 2 PCI-E 4.0 x4 (in x8 slot) M.2 M.2 Interface: 1 PCI-E 4.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI BIOS Features ACPI 6.1 SMBIOS 3.0 or later PCI FW 3.0 UEFI 2.7 RTC (Real Time Clock) Wakeup Management Software SuperDoctor 5, AMT, vPro System Management Software Wake-on-LAN, Watchdog Power Configurations ACPI Power Management, ATX Power connector, +12V DC Power Input PC Health Monitoring Voltage VBAT, 4 fans with tachometer monitoring, 1.05 (PCH), +5V standby, +5V, +3.3V, +12V, +1.8V, +1.5V, +1.35V LED Power LED Temperature Monitoring for CPU and chassis environment CPU thermal trip support Other Features RoHS, M.2 NGFF connector, Chassis intrusion detection, ATX Power connector, ACPI power management, 12V DC or ATX Power Source FAN 5x 4-pin fan headers (up to 5 fans) Operating Environment Operating Temperature Range 0 o C - 60 o C (32 o F - 140 o F) Non-Operating Temperature Range -40 o C - 85 o C (-40 o F 185 o F) Operating Relative Humidity Range 10% - 85% (non-condensing) Non Operating Relative Humidity Range 5% - 95% (non-condensing)

Motherboard Support: Mini-ITX, Micro-ATX, ATX, and EATX (Up to 272mm) Enclosure Type: Mid-Tower Case Material: SGCC Steel, Tempered Glass COMPATIBILITY and CLEARANCE Max CPU Cooler Clearance: Up to 185mm Max GPU Clearance: Up to 400mm Front Radiator Clearance: 60mm Top Radiator Clearance: 30mm Cable Management: 18-22mm FRONT I/O PORTS USB 3.2 Gen 1 Type-A: 2 USB 3.2 Gen 2 Type-C: 1 Headset Audio Jack: 1 EXPANSION SLOTS Standard: 7 Vertical: 0 DRIVE BAYS 2.5": 4+2 3.5": 2 FAN SUPPORT Front: 3 x 120mm / 3 x 140mm Top: 3 x 120mm / 2 x 140mm Rear: 1 x 120mm / 1 x 140mm Filters: All Air Intakes RADIATOR SUPPORT Front: Up to 360mm with Push/Pull Top: Up to 360mm Rear: Up to 140mm FAN SPECS Model: F120Q (Case Version) Speed: 1200 +/- 240RPM Airflow: 62.18 CFM Static: 1.05 mm - H2O Noise: 25.1 dBA Fan Connector: 3-pin

Motherboard Support: Mini-ITX, Micro-ATX, ATX, and EATX (Up to 272mm) Enclosure Type: Mid-Tower Case Material: SGCC Steel, Tempered Glass COMPATIBILITY and CLEARANCE Max CPU Cooler Clearance: Up to 185mm Max GPU Clearance: Up to 400mm Front Radiator Clearance: 60mm Top Radiator Clearance: 30mm Cable Management: 18-22mm FRONT I/O PORTS USB 3.2 Gen 1 Type-A: 2 USB 3.2 Gen 2 Type-C: 1 Headset Audio Jack: 1 EXPANSION SLOTS Standard: 7 Vertical: 0 DRIVE BAYS 2.5": 4+2 3.5": 2 FAN SUPPORT Front: 3 x 120mm / 3 x 140mm Top: 3 x 120mm / 2 x 140mm Rear: 1 x 120mm / 1 x 140mm Filters: All Air Intakes RADIATOR SUPPORT Front: Up to 360mm with Push/Pull Top: Up to 360mm Rear: Up to 140mm FAN SPECS Model: F120Q (Case Version) Speed: 1200 +/- 240RPM Airflow: 62.18 CFM Static: 1.05 mm - H2O Noise: 25.1 dBA Fan Connector: 3-pin

Motherboard Support: Mini-ITX, Micro-ATX, ATX, and EATX (Up to 272mm) Enclosure Type: Mid-Tower Case Material: SGCC Steel, Tempered Glass COMPATIBILITY and CLEARANCE Max CPU Cooler Clearance: Up to 185mm Max GPU Clearance: Up to 400mm Front Radiator Clearance: 60mm Top Radiator Clearance: 30mm Cable Management: 18-22mm FRONT I/O PORTS USB 3.2 Gen 1 Type-A: 2 USB 3.2 Gen 2 Type-C: 1 Headset Audio Jack: 1 RGB AND FAN CONTROLLER Fan Channels: 3 NZXT RGB Connector: 6 (Support up to 120 LEDs) EXPANSION SLOTS Standard: 7 Vertical: 0 DRIVE BAYS 2.5": 4+2 3.5": 2 FAN SUPPORT Front: 3 x 120mm / 3 x 140mm Top: 3 x 120mm / 2 x 140mm Rear: 1 x 120mm / 1 x 140mm Filters: All Air Intakes RADIATOR SUPPORT Front: Up to 360mm with Push/Pull Top: Up to 360mm Rear: Up to 140mm FAN SPECS Model: F140Q (Case Version) Speed: 1200 +/- 240RPM Airflow: 99.56 CFM Static Pressure: 1.14 mm-H2O Noise: 24.18 dBA Fan Connector: 3-pin FAN SPECS Model: F140 RGB Speed: 500 - 1800 RPM Airflow: 24.85 - 89.48 CFM Static Pressure: 0.94 - 3.39 mm-H2O Noise: 20 - 32.5 dBA Fan Connector: 4-pin

MODEL NAME GeForce RTX 3060 Ti GAMING X 8G LHR GRAPHICS PROCESSING UNIT NVIDIA GeForce RTX 3060 Ti INTERFACE PCI Express Gen 4 CORE CLOCKS Boost: 1770 MHz CUDA CORES 4864 Units MEMORY SPEED 14 Gbps MEMORY 8GB GDDR6 MEMORY BUS 256-bit OUTPUT DisplayPort x 3 (v1.4a) HDMI x 1 (Supports 4K at 120Hz as specified in HDMI 2.1) HDCP SUPPORT Y POWER CONSUMPTION 220 W POWER CONNECTORS 8-pin x 1 + 6-pin x 1 RECOMMENDED PSU 600 W DIRECTX VERSION SUPPORT 12 API OPENGL VERSION SUPPORT 4.6 MAXIMUM DISPLAYS 4 VR READY Y G-SYNC TECHNOLOGY Y ADAPTIVE VERTICAL SYNC Y DIGITAL MAXIMUM RESOLUTION 7680 x 4320

Model LANCOOL II MESH RGB+ type C Motherboard E-ATX(width: under 280mm)/ATX/M-ATX/ITX PSU 210mm Color black/ snow edition Materials Steel 4.0mm tempered glass (both sides) Fan Support Front (multi-way fan/radiator bracket): 3 x 120mm or 2 x 140mm Top: 2 x 120/140mm Rear: 1 x 120mm Above PSU Chamber: 2 x 120mm Radiator Front (multi-way fan/radiator bracket): 1 x 360/280/240mm Top: 1 x 240mm (aligned to the left) VGA Length 384mm CPU Clearance 176mm Drive Behind MB Tray: 2 x 2.5 SSD Behind the right flip panel: 2 x 2.5SSD Hard Drive Cage: 3 x 3.5 HDD/2.5 SSD Above PSU Chamber: 2 x 2.5 SSD Slot 7 I/O Ports C button for color control M button for lighting mode control 1 x TRRS AUDIO 2 x USB 3.0 1 x USB 3.1 TYPEC Dust Filters 1 x Top (magnetic), 1 x Bottom (tray) Incl Fans 3 x included 120mm 3-PIN 1300 RPM ARGB fans Rated Speed:1300RPM +/-10 % Air Flow:49.14CFM Noise:25.0dB(A)

Essentials Product Collection 13th Generation Intel Core i5 Processors Code Name Products formerly Raptor Lake Vertical Segment Desktop Processor Number i5-13600K Lithography Intel 7 Use Conditions PC/Client/Tablet CPU Specifications Total Cores 14 Number of Performance-cores 6 Number of Efficient-cores 8 Total Threads 20 Max Turbo Frequency 5.10 GHz Performance-core Max Turbo Frequency 5.10 GHz Efficient-core Max Turbo Frequency 3.90 GHz Performance-core Base Frequency 3.50 GHz Efficient-core Base Frequency 2.60 GHz Cache 24 MB Intel Smart Cache Total L2 Cache 20 MB Processor Base Power 125 W Maximum Turbo Power 181 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s Max Number of Memory Channels 2 Max Memory Bandwidth 89.6 GB/s ECC Memory Supported Yes Processor Graphics Processor Graphics Intel UHD Graphics 770 Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 1.50 GHz Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1 Execution Units 32 Max Resolution (HDMI) 4096 x 2160 at 60Hz Max Resolution (DP) 7680 x 4320 at 60Hz Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 at 120Hz DirectX Support 12 OpenGL Support 4.5 OpenCL Support 3.0 Multi-Format Codec Engines 2 Intel Quick Sync Video Yes Intel Clear Video HD Technology Yes Number of Displays Supported 4 Device ID 0xA780 Expansion Options Direct Media Interface (DMI) Revision 4.0 Max Number of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations Up to 1x16+4, 2x8+4 Max Number of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 TJUNCTION 100 o C Advanced Technologies Intel Gaussian and Neural Accelerator 3.0 Intel Thread Director Yes Intel Deep Learning Boost (Intel DL Boost) Yes Intel Speed Shift Technology Yes Intel Turbo Boost Max Technology 3.0 No Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Intel Volume Management Device (VMD) Yes Security and Reliability Intel Standard Manageability (ISM) Yes Intel Control-Flow Enforcement Technology Yes Intel AES New Instructions Yes Secure Key Yes Intel OS Guard Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel Stable IT Platform Program (SIPP) Yes Intel Virtualization Technology with Redirect Protection (VT-rp) Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes

Essentials Product Collection 12th Generation Intel Core i9 Processors Code Name Products formerly Alder Lake Vertical Segment Desktop Processor Number i9-12900F Lithography Intel 7 Use Conditions PC/Client/Tablet CPU Specifications Total Cores 16 Number of Performance-cores 8 Number of Efficient-cores 8 Total Threads 24 Max Turbo Frequency 5.10 GHz Intel Turbo Boost Max Technology 3.0 Frequency 5.10 GHz Performance-core Max Turbo Frequency 5.00 GHz Efficient-core Max Turbo Frequency 3.80 GHz Performance-core Base Frequency 2.40 GHz Efficient-core Base Frequency 1.80 GHz Cache 30 MB Intel Smart Cache Total L2 Cache 14 MB Processor Base Power 65 W Maximum Turbo Power 202 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max Number of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s Expansion Options Direct Media Interface (DMI) Revision 4.0 Max Number of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations Up to 1x16+4, 2x8+4 Max Number of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C TJUNCTION 100 o C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel Gaussian and Neural Accelerator 3.0 Intel Thread Director Yes Intel Deep Learning Boost (Intel DL Boost) Yes Intel Optane Memory Supported Yes Intel Speed Shift Technology Yes Intel Turbo Boost Max Technology 3.0 Yes Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Intel Volume Management Device (VMD) Yes Security and Reliability Intel Standard Manageability (ISM) Yes Intel AES New Instructions Yes Secure Key Yes Intel OS Guard Yes Execute Disable Bit Yes Intel Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel Control-Flow Enforcement Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes

CPU Intel Socket LGA1700 for 12th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 Refer to www.asus.com for CPU support list. Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. Chipset Intel H610 Chipset Memory 2 x DIMM, Max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) Actual memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for memory support list. Graphics 1 x DisplayPort 1 x D-Sub port 1 x HDMI port Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. Supports max. 4K at 60Hz as specified in DisplayPort 1.4. Supports 4K at 60Hz as specified in HDMI 2.1. Expansion Slots Intel 12th Gen Processors 1 x PCIe 4.0 x16 slot Intel H610 Chipset 2 x PCIe 3.0 x1 slots 1 x PCI slot Storage Total supports 1 x M.2 slots and 4 x SATA 6Gb/s ports Intel H610 Chipset M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode) 4 x SATA 6Gb/s ports Ethernet 1 x Intel 1Gb Ethernet ASUS LANGuard Wireless and Bluetooth M.2 slot only (Key E, CNVi and PCIe) Wi-Fi module is sold separately. USB Rear USB (Total 4 ports) 2 x USB 3.2 Gen 2 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 8 ports) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 3 x USB 2.0 headers support additional 6 USB 2.0 ports Audio Realtek 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking Supports up to 24-Bit/192 kHz playback A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. Back Panel I/O Ports 2 x USB 3.2 Gen 2 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x D-Sub port 1 x HDMI port 1 x Intel 1Gb Ethernet port 3 x Audio jacks 1 x COM port 1 x PS/2 Keyboard (purple) port 1 x PS/2 Mouse (green) port Internal I/O Connectors Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin Chassis Fan header Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 1 x M.2 slot (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 3 x USB 2.0 headers support additional 6 USB 2.0 ports Miscellaneous 1 x Clear CMOS header 1 x Chassis Intrude header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x COM debug header 1 x LPT header 1 x M.2 slot (Key E) 1 x SMBUS header 1 x Speaker header 1 x 10-1 pin System Panel header Special Features ASUS EZ DIY - Box Headers Bespoke Motherboard Design and Business Focused Features - Q-LED Core - ASUS Self Recovering BIOS - ASUS Event Log - ASUS Commercial BIOS kit - Anti-Moisture Coating - 24/7 Reliability - Overcurrent Protection TPM IC Onboard Software Features ASUS Exclusive Software IT Management software supported - ASUS Control Center Express(ACCE) BIOS 128 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PME, PXE Accessories Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x I/O Shield 1 x M.2 SSD screw package 1 x M.2 Key E screw package Installation Media 1 x Support DVD Documentation 1 x ACC Express Activation Key Card 1 x User guide Operating System Windows 11 64-bit, Windows 10 64-bit Form Factor mATX Form Factor 9.6 inch x 8.7 inch ( 24.4 cm x 22 cm ) Including below info in 600 series refreshed NPI: Supports 13th gen Intel Core TM desktop processors. BIOS update may be required to boot the 13th gen Intel Core TM desktop processors

CPU Intel Socket LGA1700 for 12th Gen Intel Core, Pentium Gold and Celeron Processors Note1 Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 Note2 Note1: Refer to www.asus.com for CPU support list. Note2: Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. Chipset Intel H610 Chipset Memory 2 x DIMM, Max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) Note: Actual memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). Graphics 1 x DisplayPort 1.4 Note2 1 x D-Sub 1 x HDMI port Note3 Note1: Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. Note1: Support DisplayPort 1.4 with max. resolution of 4K60Hz. Please refer to www.intel.com for any updates. Note3: Support HDMI 2.1 with max. resolution of 4K60Hz. Please refer to www.intel.com for any updates. Expansion Slots Intel 12th Gen Processors 1 x PCIe 4.0 x16 slot Storage Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports Intel H610 Chipset M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode) 4 x SATA 6Gb/s ports Ethernet 1 x Realtek 1Gb Ethernet Wireless and Bluetooth M.2 slot only (Key E, CNVi and PCIe) Note: Wi-Fi module is sold separately. USB Rear USB (Total 4 ports) 2 x USB 3.2 Gen 1 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 4 ports) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 1 x USB 2.0 header supports additional 2 USB 2.0 ports Audio Realtek 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Audio Shielding - Dedicated audio PCB layers Note: A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. Back Panel I/O Ports 2 x USB 3.2 Gen 1 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x D-Sub port 1 x HDMI port 1 x Realtek 1Gb Ethernet port 3 x Audio jacks 1 x PS/2 Keyboard/Mouse combo port Internal I/O Connectors Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin Chassis Fan header Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 1 x M.2 slot (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 1 x USB 2.0 header supports additional 2 USB 2.0 ports Miscellaneous 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x Mono-out header(with Amp IC) 1 x SMBUS header 1 x S/PDIF Out header 1 x Speaker header 1 x SPI TPM header (14-1pin) 1 x 10-1 pin System Panel header Special Features ASUS 5X PROTECTION III - DIGI+ VRM - LANGuard - Overvoltage Protection - SafeSlot Core - Stainless-Steel Back I/O ASUS Q-Design - Q-DIMM - Q-LED (CPU (red), DRAM (yellow), VGA (white), Boot Device (yellow green)) - Q-Slot ASUS Thermal Solution - Aluminum heatsink design Software Features ASUS Exclusive Software Armoury Crate AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU DIGI+ VRM Fan Xpert ASUS CPU-Z Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode BIOS 128 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PME, PXE Accessories Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x I/O Shield 1 x M.2 Screw Package Installation Media 1 x Support DVD Documentation 1 x User guide Operating System Windows 11 64-bit, Windows 10 64-bit Form Factor Mini ITX Form Factor Including below info in 600 series refreshed NPI: Supports 13th gen Intel Core TM desktop processors. BIOS update may be required to boot the 13th gen Intel Core TM desktop processors

Platform Desktop Market Segment Mainstream Desktop Product Family AMD Ryzen TM Processors Product Line AMD Ryzen TM 5 Desktop Processors Consumer Use Yes Regional Availability Global, China, NA, EMEA, APJ, LATAM Former Codename "Vermeer" Architecture "Zen 3" Number of CPU Cores 6 Multithreading (SMT) Yes Number of Threads 12 Max. Boost Clock Up to 4.4GHz Base Clock 3.5GHz L1 Cache 384KB L2 Cache 3MB L3 Cache 32MB Default TDP 65W Processor Technology for CPU Cores TSMC 7nm FinFET Processor Technology for I/O Die 12nm (Globalfoundries) CPU Compute Die (CCD) Size 74mm 2 I/O Die (IOD) Size 125mm 2 Package Die Count 2 Unlocked for Overclocking Yes CPU Socket AM4 Socket Count 1P Supporting Chipsets X570 X470 X370 B550 B450 B350 A520 CPU Boost Technology Precision Boost 2 Instruction Set x86-64 Supported Extensions AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 Thermal Solution (PIB) AMD Wraith Stealth Max. Operating Temperature (Tjmax) 90 o C OS Support Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit Note: Operating System (OS) support will vary by manufacturer. Connectivity USB Type-C Support Yes Native USB 3.2 Gen 2 (10Gbps) Ports 4 Native USB 3.2 Gen 1 (5Gbps) Ports 0 Native USB 2.0 (480Mbps) Ports 0 Native SATA Ports 2 PCI Express Version PCIe 4.0 Native PCIe Lanes (Total/Usable) 24/20 Additional Usable PCIe Lanes from Motherboard AMD X570 : 16x Gen 4 AMD X470 : 2x Gen 3 AMD X470 : 8x Gen 2 NVMe Support Boot, RAID0, RAID1, RAID10 System Memory Type DDR4 Memory Channels 2 Max. Memory 128GB System Memory Subtype UDIMM System Memory Specification Up to 3200MHz Max Memory Speed 2x1R : DDR4-3200 2x2R : DDR4-3200 4x1R : DDR4-2933 4x2R : DDR4-2667 ECC Support Yes (Requires mobo support) Graphics Capabilities Integrated Graphics No Graphics Model Discrete Graphics Card Required Key Features Supported Technologies AMD StoreMI Technology AMD "Zen 3" Core Architecture AMD Ryzen TM VR-Ready Premium

Form Factor ATX Processor CPU 12th Generation Intel Core TM i3/i5/i7/i9 Processors Single Socket LGA-1700 (Socket H5) supported, CPU TDP supports Up to 125W TDP Core Up to 16(8+8) cores System Memory Memory Capacity 4 DIMM slots 128GB ECC/non-ECC UDIMM, DDR5-4400MHz Memory Type 128GB DIMM Sizes 8GB, 16GB, 32GB Memory Voltage 1.1V On-Board Devices Chipset Intel W680 SATA Intel W680 controller for 8 SATA3 (6 Gbps) ports, RAID 0,1,5,10 IPMI ASPEED AST2600 BMC Audio ALC 888S HD Audio Network Controllers Single LAN with Intel PHY I219LM LAN controller, for AMT/vPro Single LAN with Intel Ethernet i225LM Single LAN with Realtek RTL8211F PHY (dedicated IPMI), Dedicated LAN for IPMI Input / Output LAN 1 RJ45 Dedicated IPMI LAN port 1 RJ45 Gigabit Ethernet LAN ports 1 RJ45 2.5 Gigabit Ethernet LAN port USB 4 USB 2 port(s) (2 via header, 2 rear) 4 USB 3.2 Gen2 port(s) (4 rear type A) 3 USB 3.2 Gen1 port(s) (2 via header, 1 Vertical) 2 USB 3.2 Gen2x2 port(s) (1 rear type C, 1 via header) Video Output 1 VGA port(s), 1 DVI - D port(s), 1 DP 1.4a port(s), 1 HDMI 2.1 port(s) Serial Port 1 COM Port(s) (1 header) TPM 1 TPM Header Expansion Slots PCI-E 2 PCI-E 3.0 x4, 2 PCI-E 5.0 x16 slots (16/NA or 8/8) 1 - 5V PCI 32bit M.2 M.2 Interface: 3 PCI-E 4.0 x4, RAID 0, 1, 5 Form Factor: 2280 Key: M-Key System BIOS BIOS Type 256MB SPI Flash with AMI BIOS BIOS Features ACPI 6.0 Plug and Play (PnP) BIOS rescue hot keys Riser card auto-detection support SMBIOS 3.0 or later Management Software SuperDoctor 5, SUM, SSM, AMT, vPro, Watchdog, IPMI (Intelligent Platform Management Interface) v2.0 with KVM support System Management Software SuperDoctor 5 Power Configurations Power-on mode for AC power recovery, ACPI Power Management, Power button override mechanism, Wake-on-LAN PC Health Monitoring Voltage VBAT, System temperature, CPU temperature, 3.3V standby, 1.05 (PCH), +5V standby, +5V, +3.3V, +12V, CPU thermal trip support, +1.8V PCH LED Power LED Catastrophic Error LED FAN 5x 4-pin fan headers (up to 5 fans) Fan speed control Overheat LED indication Other Features CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, Chassis intrusion detection, ATX Power connector, ACPI power management, 8-pin 12v DC power connector Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -20 o C - 60 o C (-4 o F - 140 o F)

Physical Stats Form Factor ATX Processor CPU 12th Generation Intel Core i3/i5/i7/i9 Processors Single Socket LGA-1700 (Socket H5) supported, CPU TDP supports Up to 125W TDP Core Up to 16(8+8) cores System Memory Memory Capacity 4 DIMM slots 128GB ECC/non-ECC UDIMM, DDR5-4400MHz Memory Type 128GB DIMM Sizes 8GB, 16GB, 32GB Memory Voltage 1.1V On-Board Devices Chipset Intel W680 SATA Intel W680 controller for 8 SATA3 (6 Gbps) ports RAID 0,1,5,10 Audio ALC 888S HD Audio Network Controllers Single LAN with Intel PHY I219LM LAN controller Single LAN with Intel Ethernet i225V Input / Output LAN 1 RJ45 Gigabit Ethernet LAN ports 1 RJ45 2.5 Gigabit Ethernet LAN port USB 3 USB 3.2 Gen1 port(s) (2 via header 1 Vertical) 3 USB 3.2 Gen2 port(s) (3 rear type A) 2 USB 3.2 Gen2x2 port(s) (1 rear type C 1 via header) 4 USB 2 port(s) (4 via header) Video Output 1 DVI - D port(s), 1 DP 1.4a port(s), 1 HDMI 2.1 port(s) Serial Port 1 COM Port(s) (1 header) TPM 1 TPM Header Expansion Slots PCI-E 2 PCI-E 3.0 x4, 2 PCI-E 5.0 x16 slots (16/NA or 8/8) 1 - 5V PCI 32bit M.2 M.2 Interface: 3 PCI-E 4.0 x4, RAID 0, 1, 5 Form Factor: 2280 Key: M-Key System BIOS BIOS Type 256MB SPI Flash with AMI BIOS BIOS Features ACPI 6.0 Plug and Play (PnP) BIOS rescue hot keys Riser card auto-detection support SMBIOS 3.0 or later Management Software SuperDoctor 5, SUM, SSM, AMT, vPro, Watchdog System Management Software SuperDoctor 5 Power Configurations Power-on mode for AC power recovery, ACPI Power Management, Power button override mechanism, Wake-on-LAN PC Health Monitoring Voltage VBAT, System temperature, CPU temperature, 3.3V standby, 1.05 (PCH), +5V standby, +5V, +3.3V, +12V, CPU thermal trip support, +1.8V PCH LED Power LED Catastrophic Error LED FAN 5x 4-pin fan headers (up to 5 fans) Fan speed control Overheat LED indication Other Features CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, Chassis intrusion detection, ATX Power connector, ACPI power management, 8-pin 12v DC power connector Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -20 o C - 60 o C (-4 o F - 140 o F)

Physical Stats Form Factor ATX Processor CPU 12th Generation Intel Core i3/i5/i7/i9 Processors Single Socket LGA-1700 (Socket H5) supported, CPU TDP supports Up to 125W TDP Core Up to 16(8+8) cores System Memory Memory Capacity 4 DIMM slots 128GB ECC/non-ECC UDIMM, DDR5-4400MHz Memory Type 128GB DIMM Sizes 8GB, 16GB, 32GB Memory Voltage 1.1V On-Board Devices Chipset Intel W680 SATA Intel W680 controller for 8 SATA3 (6 Gbps) ports RAID 0,1,5,10 Audio ALC 888S HD Audio Network Controllers Single LAN with Intel PHY I219LM LAN controller Single LAN with Intel Ethernet i225V Input / Output LAN 1 RJ45 Gigabit Ethernet LAN ports 1 RJ45 2.5 Gigabit Ethernet LAN port USB 3 USB 3.2 Gen1 port(s) (2 via header 1 Vertical) 3 USB 3.2 Gen2 port(s) (3 rear type A) 2 USB 3.2 Gen2x2 port(s) (1 rear type C 1 via header) 4 USB 2 port(s) (4 via header) Video Output 1 DVI - D port(s), 1 DP 1.4a port(s), 1 HDMI 2.1 port(s) Serial Port 1 COM Port(s) (1 header) TPM 1 TPM Header Expansion Slots PCI-E 2 PCI-E 3.0 x4, 2 PCI-E 5.0 x16 slots (16/NA or 8/8) 1 - 5V PCI 32bit M.2 M.2 Interface: 3 PCI-E 4.0 x4, RAID 0, 1, 5 Form Factor: 2280 Key: M-Key System BIOS BIOS Type 256MB SPI Flash with AMI BIOS BIOS Features ACPI 6.0 Plug and Play (PnP) BIOS rescue hot keys Riser card auto-detection support SMBIOS 3.0 or later Management Software SuperDoctor 5, SUM, SSM, AMT, vPro, Watchdog System Management Software SuperDoctor 5 Power Configurations Power-on mode for AC power recovery, ACPI Power Management, Power button override mechanism, Wake-on-LAN PC Health Monitoring Voltage VBAT, System temperature, CPU temperature, 3.3V standby, 1.05 (PCH), +5V standby, +5V, +3.3V, +12V, CPU thermal trip support, +1.8V PCH LED Power LED Catastrophic Error LED FAN 5x 4-pin fan headers (up to 5 fans) Fan speed control Overheat LED indication Other Features CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, Chassis intrusion detection, ATX Power connector, ACPI power management, 8-pin 12v DC power connector Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -20 o C - 60 o C (-4 o F - 140 o F)

Physical Stats Form Factor ATX Dimension 12.1" x 10" (30.73cm x 25.4cm) Processor CPU 3rd Gen Intel Xeon Scalable processors Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP Core Up to 40 cores System Memory Memory Capacity 8 DIMM slots Up to 2TB Intel Optane Persistent Memory 200 Series Up to 2TB ECC LRDIMM, DDR4-3200MHz Up to 2TB ECC RDIMM, DDR4-3200MHz Memory Type ECC , DDR4 LRDIMM, RDIMM DIMM Sizes 8GB, 16GB, 32GB, 64GB, 128GB, 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors On-Board Devices Chipset Intel C621A SATA Intel C621A controller for 10 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2600 BMC Graphics ASPEED AST2600 BMC Network Controllers Dual LAN with 10GBase-T with Intel X550 Input / Output LAN 2 RJ45 10 Gigabit Ethernet LAN ports USB 4 USB 2.0 port(s) (2 rear 2 via header) 5 USB 3.2 Gen1 port(s) (2 via header 2 rear 1 type A) Video Output 1 VGA D-Sub Connector port(s) Serial Port 1 COM Port(s) (1 header) DOM 2 SATA DOM (Disk on Module) power connector support TPM 1 TPM Header Expansion Slots PCI-E 2 PCI-E 4.0 x16, 1 PCI-E 4.0 x8 (in x16 slot), 2 PCI-E 4.0 x8 M.2 M.2 Interface: 1 SATA/PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI BIOS Features ACPI 6.2 SMBIOS 3.0 or later UEFI 2.7 Management Software SuperDoctor 5, SUM, KVM with dedicated LAN, SPM, Intel Node Manager, SSM, IPMI2.0, Watchdog System Management Software IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support Power Configurations Power-on mode for AC power recovery, ACPI Power Management, CPU thermal trip support for processor protection PC Health Monitoring Voltage VBAT, System temperature, Monitors CPU voltages, HT, Chassis intrusion header, 3.3V standby, +5V standby, +5V, +3.3V, +12V, +1.8V, 7-fan status LED UID/Remote UID BMC/IPMI Heartbeat LED Suspend static indicator LED CPU / System Overheat LED Temperature CPU thermal trip support PECI FAN 7x 4-pin fan headers (up to 7 fans) System level control PWM fan speed control Fan speed control Overheat LED indication Other Features UID, RoHS, Dual Cooling Zones, Chassis intrusion detection, ATX Power connector, ACPI power management, RoT, NCSI header Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -20 o C - 60 o C (-4 o F - 140 o F) Operating Relative Humidity Range 10% - 85% (non-condensing) Non Operating Relative Humidity Range 10% - 95% (non-condensing)

CPU (MAX SUPPORT) i9 SOCKET 1700 CHIPSET Intel H610 Chipset DDR4 MEMORY 3200(MAX) / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz MEMORY CHANNEL Dual DIMM SLOTS 2 MAX MEMORY (GB) 64 PCI-E X16 1 SATAIII 4 PCI-E X1 1 M.2 SLOT 1 TPM (HEADER) 1 LAN 1x Intel I219V Gigabit LAN controller USB 3.2 PORTS (FRONT) 2(Gen 1, Type A) USB 3.2 PORTS (REAR) 2(Gen 1, Type A) USB 2.0 PORTS (FRONT) 2 USB 2.0 PORTS (REAR) 4 AUDIO PORTS (REAR) Realtek ALC892/ ALC897 Codec DISPLAYPORT 1 VGA 1 HDMI 1 DIRECTX 12 FORM FACTOR M-ATX OPERATING SYSTEM Support for Windows 11 64-bit, Windows 10 64-bit

CPU (MAX SUPPORT) i9 SOCKET 1700 CHIPSET Intel Z690 Chipset DDR4 MEMORY 5000(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz MEMORY CHANNEL Dual DIMM SLOTS 4 MAX MEMORY (GB) 128 PCI-E X16 2 PCI-E X1 3 SATAIII 4 M.2 SLOT 2 RAID 0/1/5/10 TPM (HEADER) 1 LAN Realtek RTL8125BG 2.5Gbps LAN controller USB 3.2 PORTS (FRONT) 4(Gen 1, Type A) USB 3.2 PORTS (REAR) 1(Gen 2x2, Type C), 4(Gen 1, Type A) USB 2.0 PORTS (FRONT) 4 USB 2.0 PORTS (REAR) 2 AUDIO PORTS (REAR) Realtek ALC897 Codec DISPLAYPORT 1 HDMI 1 DIRECTX 12 FORM FACTOR ATX CROSSFIRE Y OPERATING SYSTEM Support for Windows 11 64-bit, Windows 10 64-bit

COLOR Anodized Black Exterior Matte Black Interior RISER CABLE GENERATION PCIe 4.0 CAPACITY 11L MATERIALS Aluminum Exterior SPCC Steel Interior MOTHERBOARD SUPPORT Mini-ITX FAN SUPPORT Top: 2x 120mm RADIATOR SUPPORT Top: 1x 240mm (55mm. max total thickness with fans) PSU SUPPORT SFX, SFX-L GPU LENGTH CLEARANCE Max 322mm CPU COOLER CLEARANCE Max 55mm DRIVE SUPPORT 1x 2.5 inch SSD EXPANSION SLOT 3 I/O PORTS 1x USB 3.0 TYPE-A, 1x USB 3.1 TYPE-C, 1x Mic, 1x HD Audio.

Essentials Product Collection 12th Generation Intel Core i5 Processors Code Name Products formerly Alder Lake Vertical Segment Desktop Processor Number i5-12600 Lithography Intel 7 Use Conditions PC/Client/Tablet, Workstation CPU Specifications Total Cores 6 Number of Performance-cores 6 Number of Efficient-cores 0 Total Threads 12 Max Turbo Frequency 4.80 GHz Performance-core Max Turbo Frequency 4.80 GHz Performance-core Base Frequency 3.30 GHz Cache 18 MB Intel Smart Cache Total L2 Cache 7.5 MB Processor Base Power 65 W Maximum Turbo Power 117 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max Number of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s ECC Memory Supported Yes Processor Graphics Processor Graphics Intel UHD Graphics 770 Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 1.45 GHz Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1 Execution Units 32 Max Resolution (HDMI) 4096 x 2160 at 60Hz Max Resolution (DP) 7680 x 4320 at 60Hz Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 at 120Hz DirectX Support 12 OpenGL Support 4.5 Multi-Format Codec Engines 2 Intel Quick Sync Video Yes Intel Clear Video HD Technology Yes Number of Displays Supported 4 Device ID 0x4690 OpenCL Support 2.1 Expansion Options Direct Media Interface (DMI) Revision 4.0 Max Number of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations Up to 1x16+4, 2x8+4 Max Number of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C TJUNCTION 100 o C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel Gaussian and Neural Accelerator 3.0 Intel Thread Director No Intel Deep Learning Boost (Intel DL Boost) Yes Intel Optane Memory Supported Yes Intel Speed Shift Technology Yes Intel Turbo Boost Max Technology 3.0 No Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Intel Volume Management Device (VMD) Yes Security and Reliability Intel vPro Platform Eligibility Yes Intel vPro Enterprise Platform Eligibility Yes Intel vPro Essentials Platform Eligibility Yes Intel Threat Detection Technology (TDT) Yes Intel Active Management Technology (AMT) Yes Intel Standard Manageability (ISM) Yes Intel One-Click Recovery Yes Intel Hardware Shield Eligibility Yes Intel AES New Instructions Yes Secure Key Yes Intel OS Guard Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel Control-Flow Enforcement Technology Yes Intel Total Memory Encryption - Multi Key Yes Intel Total Memory Encryption Yes Intel Stable IT Platform Program (SIPP) Yes Intel Virtualization Technology with Redirect Protection (VT-rp) Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes

Essentials Product Collection 12th Generation Intel Core i3 Processors Code Name Products formerly Alder Lake Vertical Segment Desktop Processor Number i3-12100 Lithography Intel 7 Use Conditions PC/Client/Tablet CPU Specifications Total Cores 4 Number of Performance-cores 4 Number of Efficient-cores 0 Total Threads 8 Max Turbo Frequency 4.30 GHz Performance-core Max Turbo Frequency 4.30 GHz Performance-core Base Frequency 3.30 GHz Cache 12 MB Intel Smart Cache Total L2 Cache 5 MB Processor Base Power 60 W Maximum Turbo Power 89 W Supplemental Information Embedded Options Available Yes Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max Number of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s Processor Graphics Processor Graphics Intel UHD Graphics 730 Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 1.40 GHz Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1 Execution Units 24 Max Resolution (HDMI) 4096 x 2160 at 60Hz Max Resolution (DP) 7680 x 4320 at 60Hz Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 at 120Hz DirectX Support 12 OpenGL Support 4.5 Multi-Format Codec Engines 1 Intel Quick Sync Video Yes Intel Clear Video HD Technology Yes Number of Displays Supported 4 Device ID 0x4692 OpenCL Support 2.1 Expansion Options Direct Media Interface (DMI) Revision 4.0 Max Number of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations Up to 1x16+4, 2x8+4 Max Number of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C TJUNCTION 100 o C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel Gaussian and Neural Accelerator 3.0 Intel Thread Director No Intel Deep Learning Boost (Intel DL Boost) Yes Intel Optane Memory Supported Yes Intel Speed Shift Technology Yes Intel Turbo Boost Max Technology 3.0 No Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Intel Volume Management Device (VMD) Yes Security and Reliability Intel Threat Detection Technology (TDT) Yes Intel Standard Manageability (ISM) Yes Intel AES New Instructions Yes Secure Key Yes Intel OS Guard Yes Execute Disable Bit Yes Intel Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel Control-Flow Enforcement Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes

Essentials Product Collection 12th Generation Intel Core i3 Processors Code Name Products formerly Alder Lake Vertical Segment Desktop Processor Number i3-12100F Lithography Intel 7 Use Conditions PC/Client/Tablet CPU Specifications Total Cores 4 Number of Performance-cores 4 Number of Efficient-cores 0 Total Threads 8 Max Turbo Frequency 4.30 GHz Performance-core Max Turbo Frequency 4.30 GHz Performance-core Base Frequency 3.30 GHz Cache 12 MB Intel Smart Cache Total L2 Cache 5 MB Processor Base Power 58 W Maximum Turbo Power 89 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max Number of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s Expansion Options Direct Media Interface (DMI) Revision 4.0 Max Number of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations Up to 1x16+4, 2x8+4 Max Number of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C TJUNCTION 100 o C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel Gaussian and Neural Accelerator 3.0 Intel Thread Director No Intel Deep Learning Boost (Intel DL Boost) Yes Intel Optane Memory Supported Yes Intel Speed Shift Technology Yes Intel Turbo Boost Max Technology 3.0 No Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Intel Volume Management Device (VMD) Yes Security and Reliability Intel Standard Manageability (ISM) Yes Intel AES New Instructions Yes Secure Key Yes Intel OS Guard Yes Execute Disable Bit Yes Intel Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel Control-Flow Enforcement Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes

Essentials Product Collection 12th Generation Intel Core i9 Processors Code Name Products formerly Alder Lake Vertical Segment Desktop Processor Number i9-12900 Lithography Intel 7 Use Conditions PC/Client/Tablet, Workstation CPU Specifications Total Cores 16 Number of Performance-cores 8 Number of Efficient-cores 8 Total Threads 24 Max Turbo Frequency 5.10 GHz Intel Turbo Boost Max Technology 3.0 Frequency 5.10 GHz Performance-core Max Turbo Frequency 5.00 GHz Efficient-core Max Turbo Frequency 3.80 GHz Performance-core Base Frequency 2.40 GHz Efficient-core Base Frequency 1.80 GHz Cache 30 MB Intel Smart Cache Total L2 Cache 14 MB Processor Base Power 65 W Maximum Turbo Power 202 W Supplemental Information Embedded Options Available Yes Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max Number of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s ECC Memory Supported Yes Processor Graphics Processor Graphics Intel UHD Graphics 770 Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 1.55 GHz Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1 Execution Units 32 Max Resolution (HDMI) 4096 x 2160 at 60Hz Max Resolution (DP) 7680 x 4320 at 60Hz Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 at 120Hz DirectX Support 12 OpenGL Support 4.5 Multi-Format Codec Engines 2 Intel Quick Sync Video Yes Intel Clear Video HD Technology Yes Number of Displays Supported 4 Device ID 0x4680 OpenCL Support 2.1 Expansion Options Direct Media Interface (DMI) Revision 4.0 Max Number of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations Up to 1x16+4, 2x8+4 Max Number of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C TJUNCTION 100 o C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel Gaussian and Neural Accelerator 3.0 Intel Thread Director Yes Intel Deep Learning Boost (Intel DL Boost) Yes Intel Optane Memory Supported Yes Intel Speed Shift Technology Yes Intel Turbo Boost Max Technology 3.0 Yes Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Intel Volume Management Device (VMD) Yes Security and Reliability Intel vPro Platform Eligibility Yes Intel vPro Enterprise Platform Eligibility Yes Intel vPro Essentials Platform Eligibility Yes Intel Threat Detection Technology (TDT) Yes Intel Active Management Technology (AMT) Yes Intel Standard Manageability (ISM) Yes Intel One-Click Recovery Yes Intel Hardware Shield Eligibility Yes Intel AES New Instructions Yes Secure Key Yes Intel OS Guard Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel Control-Flow Enforcement Technology Yes Intel Total Memory Encryption - Multi Key Yes Intel Total Memory Encryption Yes Intel Stable IT Platform Program (SIPP) Yes Intel Virtualization Technology with Redirect Protection (VT-rp) Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes

CPU Intel Socket LGA1700 for 12th Gen Intel Core TM , Pentium Gold and Celeron Processors Note1 Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 Note2 Note1: Refer to www.asus.com for CPU support list. Note2: Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. Chipset Intel Z690 Chipset Memory 4 x DIMM, Max. 128GB, DDR5 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 Non-ECC, Un-buffered Memory Note Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem II Note: Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. Graphics 1 x DisplayPort Note2 1 x HDMI port Note3 Note1: Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. Note2: Supports max. 4K at 60Hz as specified in DisplayPort 1.4 Note3: Supports 4K at 60Hz as specified in HDMI 2.1. Note4: VGA resolution support depends on processors or graphic cards resolution. Expansion Slots Intel 12th Gen Processors Note1 1 x PCIe 5.0 x16 slot Intel Z690 Chipset Note2 1 x PCIe 3.0 x16 slot (supports x4 mode) 1 x PCIe 3.0 x4 slot 2 x PCIe 3.0 x1 slots Note1: Please check PCIe bifurcation table in support site. Note2: Supports Intel Optane Memory H Series on PCH-attached PCIe slot Storage Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports Note1 Intel 12th Gen Processors M.2_1 slot (Key M), type 2242/2260/2280/22110 - Intel 12th Gen processors support PCIe 4.0 x4 mode Intel Z690 Chipset Note2 M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 and SATA modes) M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports Note1: Intel Rapid Storage Technology supports NVMe RAID 0/1/5, SATA RAID 0/1/5/10. Note2: Intel Rapid Storage Technology supports Intel Optane Memory H Series on PCH attached M.2 slots. Ethernet 1 x Intel 2.5Gb Ethernet TUF LANGuard Wireless and Bluetooth Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band Note1 Bluetooth v5.2 hardware ready Note2 Note1: WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later. Note2: Bluetooth v5.2 function will be ready in Windows 11 or later. USB Rear USB (Total 8 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 2 x USB 3.2 Gen 2 ports (2 x Type-A) 5 x USB 3.2 Gen 1 ports (4 x Type-A + 1 x USB Type-C) Front USB (Total 7 ports) 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Audio Realtek 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Audio Shielding - Rear optical S/PDIF out port - Premium audio capacitors - Dedicated audio PCB layers - Audio Cover Back Panel I/O Ports 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 2 x USB 3.2 Gen 2 ports (2 x Type-A) 5 x USB 3.2 Gen 1 ports (4 x Type-A + 1 x USB Type-C) 1 x DisplayPort 1 x HDMI port 1 x Wi-Fi Module 1 x Intel 2.5Gb Ethernet port 5 x Audio jacks 1 x Optical S/PDIF out port Internal I/O Connectors Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 1 x 4-pin +12V Power connector Storage related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x AURA RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thunderbolt TM header Special Features SUS TUF PROTECTION - DIGI+ VRM (- Digital power design with DrMOS) - Enhanced DRAM Overcurrent Protection - ESD Guards - TUF LANGuard - Overvoltage Protection - Safeslot - Stainless-Steel Back I/O ASUS Q-Design - M.2 Q-Latch - Q-DIMM - Q-LED (CPU (red), DRAM (yellow), VGA (white), Boot Device (yellow green)) - Q-Slot ASUS Thermal Solution - M.2 heatsink - VRM heatsink design ASUS EZ DIY - CPU Socket lever protector - ProCool - Pre-mounted I/O shield - SafeDIMM AURA Sync - AURA RGB header - Addressable Gen 2 headers Software Features ASUS Exclusive Software Armoury Crate - AURA Creator - AURA Sync - Fan Xpert 4 - Two-Way AI Noise Cancelation AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU DIGI+ VRM TUF GAMING CPU-Z DTS Audio Processing MyAsus Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode BIOS 192 (128+64) Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PME, PXE Accessories Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x ASUS Wi-Fi moving antenna 2 x M.2 Rubber Packages 1 x M.2 SSD screw package 1 x TUF GAMING sticker Installation Media 1 x Support DVD Documentation 1 x TUF Certification card 1 x User guide Operating System Windows 11 64-bit, Windows 10 64-bit Form Factor ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) Including below info in Z690 refreshed NPI: Supports 13th gen Intel Core TM desktop processors. BIOS update may be required to boot the 13th gen Intel Core TM desktop processors
