Hard Drives

MPN ST4000NM000A Specifications 512n SATA Capacity 4TB Features Protection Information (T10 DIF) - Humidity Sensor Yes SuperParity Yes Low Halogen Yes PowerChoice TM Technology Yes PowerBalance TM Technology Yes Cache, Multisegmented (MB) 256 Advanced Write Caching (Internal NOR flash) Yes Reliability/Data Integrity Vibration, Nonoperating: 10Hz to 500Hz (Grms) 5 MTBF 2,000,000hr Reliability Rating at Full 24x7 Operation (AFR) 0.44% Nonrecoverable Read Errors per Bits Read, Max 1 sector per 10E15 Power-On Hours 8760 Bytes per Sector 512 Performance Spindle Speed (RPM) 7200 Interface Access Speed (Gb/s) 6.0, 3.0, 1.5 Max Sustainable Transfer Rate 215MB/s Average Latency (ms) 4.16 Interface Ports Single Rotational Vibration at 1500Hz (rad/s 2 ) 12.5 Power Consumption Idle Average (W) 5.38W Average Operating Power 10.77W Power Supply Requirements +12 V and +5 V Environmental/Temperature Temperature, Operating ( o C) 5 o C - 60 o C Shock, Operating Read/Write (Gs) 70/40Gs Shock, Nonoperating, 1ms/2ms (Gs) 150/300

MPN ST14000NM002G Specifications 12Gb/s SAS Capacity 14TB Features Helium Sealed-Drive Design Yes Protection Information (T10 DIF) Yes SuperParity Yes Low Halogen Yes PowerChoice TM Idle Power Technology Yes PowerBalance TM Power/Performance Technology Yes Hot-Plug Support Yes Cache, Multisegmented (MB) 256 Organic Solderability Preservative Yes RSA 2048 Firmware Verification (SD and D) Yes Reliability/Data Integrity Mean Time Between Failures (MTBF, hours) 2,500,000 Reliability Rating at Full 24x7 Operation (AFR) 0.35% Nonrecoverable Read Errors per Bits Read 1 sector per 10E15 Power-On Hours per Year (24x7) 8,760 512e Sector Size (Bytes per Sector) 512, 520, 528 4Kn Sector Size (Bytes per Sector) 4096, 4160, 4224 Performance Spindle Speed (RPM) 7200RPM Interface Access Speed (Gb/s) 12.0, 6.0, 3.0 Max. Sustained Transfer Rate OD (MB/s,MiB/s) 261, 249 Random Read/Write 4K QD16 WCD (IOPS) 170/440 Average Latency (ms) 4.16 Interface Ports Dual Rotation Vibration at 20-1500 Hz (rad/sec 2 ) 12.5 POWER CONSUMPTION Idle A (W) Average 5W Max Operating, Random Read/Write 4K/16Q (W) 10.2, 6.2 Power Supply Requirements +12 V and +5 V Environmental Temperature, Operating ( o C) 5 o C - 60 o C Vibration, Nonoperating: 2 to 500Hz (Grms) 2.27 Shock, Operating 2ms (Read/Write) (Gs) 50 Shock, Nonoperating 2ms (GS) 200

MPN MG06ACA10TE Form Factor 3.5-inch Interface SATA 6 Gbit/s Formatted Capacity 10 TB Buffer Size 256 MiB Rotation Speed 7,200 rpm Data Transfer Speed ( Sustained ) 237 MiB/s Typ. MTTF 2,500,000 hours Power Consumption( Idle - A ) 7.3 W Typ.

MPN MG07ACA12TE 512 emulation ( 512e ) Form Factor 3.5-inch Interface SATA 6 Gbit/s Formatted Capacity 12 TB Buffer Size 256 MiB Rotation Speed 7,200 rpm Data Transfer Speed ( Sustained ) 242 MiB/s Typ. MTTF 2,500,000 h Power Consumption ( Idle - A ) 4.25 W Typ.

MPN ST6000VX001 Specifications Standard Model Numbers : ST6000VX001 (Later 6 TB and 3 TB models are ST6000VX001 and ST3000VX009.)note SkyHawk TM Health Management Included : Yes Interface SATA 6 Gb/s SATA : 6 Gb/s Features and Performance Drive Bays Supported : 8+ Cameras Supported : Up to 64 Max. Sustained Transfer Rate OD (MB/s) : 180MB/s Cache (MB) : 256 Reliability/Data Integrity Tarnish Resistant : Yes Load/Unload Cycles : 300,000 Non-recoverable Read Errors per Bits Read, Max : 1 per 10E15 Power-On Hours per Year (247) : 8,760 8 Workload Rate Limit (WRL) : 180 (SkyHawk surveillance drives are designed for always-on workloads of 180 TB/year. For higher transaction workloads, see Seagates enterprise-class drive offerings.)note MTBF : 1,000,000 hr Power Management Startup Current, Typical (12V, A) : 1.8 Average Operating Power (W) : 5 W Idling Average (W) : 3.4 W Standby Mode/Sleep Mode, Typical (W) : 0.25/0.25 Voltage Tolerance (5 V) : +-/5% Voltage Tolerance (12 V) : +-/10% Environmental/Temperature Operating (ambient, min o C) : 0 Operating (drive case, max o C) : 70 (Seagate does not recommend operating at sustained extreme temperatures. Operating at higher temperatures will reduce useful life of the products.)note Non-operating (ambient, min o C) : -40 Physical Carton Unit Quantity : 20 Cartons per Pallet / Cartons per Layer : 40/8

MPN ST8000DM004 Specifications Capacity: 8TB Bytes per Sector: 4096 Heads/Disks: 8/4 Performance Interface: SATA 6Gb/s SATA Transfer Rates Supported (Gb/s): 6.0/3.0/1.5 Max. Sustained Transfer Rate OD (MB/s): 190MB/s Cache, Multisegmented (MB): 256 Reliability/Data Integrity Load/Unload Cycles: 300,000 Nonrecoverable Read Errors per Bits Read, Max: 1 per 10E14 Power-On Hours per Year (24x7): 2400 Workload Rate Limit (TB/Year): 55 Power Management Startup Power (A): 2.0 Operating Mode, Typical (W): 5.3 Idle Average (W): 3.4W Standby Mode/Sleep Mode, Typical (W): 0.25/0.25 Voltage Tolerance, Inc. Noise (5V): +/-5% Voltage Tolerance, Inc. Noise (12V): +/-10% Environmental/Temperature Operating (ambient, min): 0 o C Operating (drive case, max): 60 o C Nonoperating (ambient): -40 o C - 70 o C Halogen Free: Yes RoHS Compliance: Yes

MPN ST2400MM0129 Capacity 2.4TB Spindle Speed (RPM) 10000RPM Average Latency (ms) 2.9 Sustained Transfer Rate (Outer to Inner Diameter,MB/s) 270 to 117 Cache, Multisegmented (MB) 256 I/O Acceleration and Response Time Optimization Enabled NAND Flash Type eMLC NAND Flash Size 16GB Intelligent NAND Endurance Management Yes Secure Download Diagnostics (SDD) and Instant Secure Erase Option Yes FastFormat (512e/4Kn AF Switching) Yes 12Gb/s SAS Yes Disks/Heads 4/8 External Transfer Rate (MB/s) 1200 Nonrecoverable Read Errors per Bits Read, Max 1 per 10E16 Annualized Failure Rate (AFR) 0.44% Typical Op (A) +5V/+12V 0.47/0.50 Typical Operating (W) 8.5 Average Idle Power (W) 4.8 Performance Efficiency Index (Idle W/GB) 0.0020 Item Dimension (L inchxW inchxH inch) 4 x 3 x 1 Weight 1.00lb

MPN ST1800MM0129 Capacity 1.8TB Spindle Speed (RPM) 10000RPM Average Latency (ms) 2.9 Sustained Transfer Rate (Outer to Inner Diameter,MB/s) 270 to 117 Cache, Multisegmented (MB) 256 I/O Acceleration and Response Time Optimization Enabled NAND Flash Type eMLC NAND Flash Size 16GB Intelligent NAND Endurance Management Yes Secure Download Diagnostics (SDD) and Instant Secure Erase Option Yes FastFormat (512e/4Kn AF Switching) Yes 12Gb/s SAS Yes Disks/Heads 3/6 External Transfer Rate (MB/s) 1200 Nonrecoverable Read Errors per Bits Read, Max 1 per 10E16 Annualized Failure Rate (AFR) 0.44% Typical Op (A) +5V/+12V 0.46/0.42 Typical Operating (W) 7.5 Average Idle Power (W) 4.4 Performance Efficiency Index (Idle W/GB) 0.0024 Item Dimension (L inchxW inchxH inch) 4 x 3 x 1 Weight 1.00lb

MPN ST1200MM0009 Capacity 1.2TB Spindle Speed (RPM) 10000RPM Average Latency (ms) 2.9 Sustained Transfer Rate (Outer to Inner Diameter,MB/s) 250 to 108 Cache, Multisegmented (MB) 128 Secure Download Diagnostics (SDD) and Instant Secure Erase Option Yes 12Gb/s SAS Yes Disks/Heads 2/4 External Transfer Rate (MB/s) 1200 Nonrecoverable Read Errors per Bits Read, Max 1 per 10E16 Annualized Failure Rate (AFR) 0.44% Typical Op (A) +5V/+12V 0.45/0.38 Typical Operating (W) 7.25 Average Idle Power (W) 4.26 Performance Efficiency Index (Idle W/GB) 0.0036 Item Dimension (L inchxW inchxH inch) 4 x 3 x 1 Weight 1.00lb

MPN ST10000NM002G Capacities 10TB Interface 12Gb/s SAS Specifications Standard Model FastFormat (512e/4Kn) Features Helium Sealed-Drive Design Yes Protection Information (T10 DIF) Yes SuperParity Yes Low Halogen Yes PowerChoice Idle Power Technology Yes PowerBalance Power/Performance Technology Yes Hot-Plug Support3 Yes Cache, Multisegmented (MB) 256 Organic Solderability Preservative Yes RSA 2048 Firmware Verification (SDD) Yes Reliability/Data Integrity Mean Time Between Failures (MTBF, hours) 2,500,000 Reliability Rating Full 247 Operation (AFR) 0.35% Nonrecoverable Read Errors per Bits Read 1 sector per 10E15 Power-On Hours per Year (247) 8760 512e Sector Size (Bytes per Sector) 512, 520, 528 4Kn Sector Size (Bytes per Sector) 4096, 4160,4224 Performance Spindle Speed (RPM) 7200RPM Interface Access Speed (Gb/s) 12.0, 6.0, 3.0 Max. Sustained Transfer Rate OD (MB/s,MiB/s) 245, 233 Random Read/Write 4K QD16 WCD (IOPS) 170/440 Average Latency (ms) 4.16 Interface Ports Dual Rotation Vibration 20-1500 Hz (rad/sec) 12.5 Power Consumption Idle A (W) Average 5.0W Max Operating, Random Read/Write 4K/16Q (W) 10.0, 6.2 Power Supply Requirements +12 V and +5 V

MPN ST500LM030 Formatted capacity 500GB Guaranteed sectors 976,773,168 Heads 2 Disks 1 Bytes per sector 512 (logical) / 4096 (physical) Recording density 2276 Kb/in Track density 580 Ktracks/in avg Areal density 1320 Gb/in 2 avg Spindle speed 5400 RPM Maximum sustained data rate, OD read 140 MB/s Interface SATA 6Gb/s ATA data-transfer modes supported PIO modes 0-4 Multiword DMA modes 0-2 Ultra DMA modes 0-6 Cache buffer 128 MB Average latency 5.6 ms Startup current, Max (+5V) 1.0 A Voltage tolerance (including noise) 5V +/- 5% Non-Operating (Ambient o C) -40 o to 70 o Operating ambient temperature (min o C) 0 o Operating temperature (drive case max o C) 60 o Temperature gradient 20 o C per hour max (operating) 35 o C per hour max (non-operating) Relative humidity 5% to 95% (operating) 5% to 95% (non-operating) Relative humidity gradient (max) 30% per hour Wet bulb temperature 37.7 o C max (operating) 40.0 o C max (non-operating) Altitude, operating -304.8 m to 3048 m (1000 ft to 10,000+ ft) Altitude, non-operating (below mean sea level, max) -304.8 m to 12,192 m (1000 ft to 40,000+ ft) Operational Shock 400 Gs at 2 ms max Non-Operational Shock 1000 Gs at 1 ms max Vibration, operating 5-200 Hz: 2.0 Gs 201-500 Hz: 1.0 Gs Vibration, non-operating 5-500 Hz: 5.0 Gs Non-recoverable read errors 1 per 10 14 bits read Rated workload Average annualized workload rating: <55 TB/year. The AFR specification for the product assumes the I/O workload does not exceed the average Load-unload cycles 600,000 at 25 o C, 50% rel. Supports Hotplug operation per the Serial ATA Revision 3.2 specification Yes

MPN ST2000LM015 Bytes per Sector (logical/physical) 512/4096 Interface SATA 6Gb/s Data Transfer Rate (MB/s) Up to 140 Cache (MB) 128 Spindle Speed (RPM) 5400 Load/Unload Cycles 600,000 Head-Rest Method QuietStep Ramp Load Nonrecoverable Read Errors 1 per 10E14 Startup Current (+5V, A) 1.0 Read/Write Power, Average (W) 1.7/1.8 Idle Power, Average (W) 0.5 Temperature, Operating( o C) 0 o C - 60 o C Temperature, Nonoperating( o C) -40 o C - 70 o C Shock, Operating: 2ms (Gs) 400Gs Shock, Nonoperating: 1ms (Gs) 1000Gs Acoustic, Seek/Idle, Typical (bels) 2.4bels/2.2bels

MPN ST2000NX0253 PowerChoice on-demand power option Yes Low Halogen Yes RAID Rebuild Yes Mean Time Between Failures (MTBF, hours) 1.4 million Reliability Rating Full 24x7 operation 0.63% Nonrecoverable Read Errors per Bits Read 1 sector per 10E15 Power-On Hours per Year 8760 Bytes per Sector 512 Spindle Speed (RPM) 7200 Cache Buffer, Multisegmented (MB) 128 Interface Access Speed 6.0, 3.0, 1.5 Max. Sustained Transfer Rate (MB/s) 136 Average Latency (ms) 4.16 Interface Ports Single RV Tolerance (rad/s2 to 1800Hz) 16 Idle Power, Average (W) 3.87 Typical Operating, Random Read (W) 5.22 PowerChoice Technology (Standby) (W) 1.14 Power Supply Requirements +12V and +5V Temperature, Operating (C) 5 to 55 Vibration, Operating, 5Hz to 500Hz (Gs) 0.5 Vibration, Nonoperating, 5Hz to 500Hz 3.0 Shock, Operating, 2ms (Gs) 25 Shock, Nonoperating, 2ms (Gs) 400 Acoustics, Typical Idle (bels) 2.8 Acoustics, Typical Seek (bels) 3.2

MPN ST2000NX0243 PowerChoice on-demand power option Yes Low Halogen Yes RAID Rebuild Yes Mean Time Between Failures (MTBF, hours) 1.4 million Reliability Rating at Full 24x7 operation 0.63% Nonrecoverable Read Errors per Bits Read 1 sector per 10E15 Power-On Hours per Year 8760 Interface Access Speed 6.0, 3.0, 1.5 Max. Sustained Transfer Rate (MB/s) 136 Average Latency (ms) 4.16 Interface Ports Single RV Tolerance (rad/s2 to 1800Hz) 16 Idle Power, Average (W) 3.87 Typical Operating, Random Read (W) 5.22 PowerChoice Technology (Standby) (W) 1.14 Power Supply Requirements +12V and +5V Temperature, Operating (C) 5 to 55 Vibration, Operating, 5Hz to 500Hz (Gs) 0.5 Vibration, Nonoperating, 5Hz to 500Hz 3.0 Shock, Operating, 2ms (Gs) 25 Shock, Nonoperating, 2ms (Gs) 400 Acoustics, Typical Idle (bels) 2.8 Acoustics, Typical Seek (bels) 3.2

MPN WD30EFZX Capacity 3 TB Cache Size 128 MB Disk Speed (RPM) 5400rpm Interface SATA Cache Size (MB) 128MB Transfer Rate up to 175MB/s Compatibility Designed with CMR technology for small or medium-sized businesses in RAID-optimized NAS systems with up to 8 bays. Perfect for handling increased workloads, including expanded OS compatibility and ZFS.

MPN WD40EFAX Capacity 4 TB Interface SATA Transfer Rate up to 180MB/s Form Factor 3.5 in Cache Size 256 MB Disk Speed (RPM) 5400rpm Compatibility WD Red NAS Hard Drives are designed specifically for NAS systems that have 1 to 8 drive bays in both 3.5-inch and 2.5-inch form factors.

MPN WD10SPSX Interface SATA 6 Gb/s Formatted capacity 1,000,204MB User sectors per drive 1,953,525,168 Form factor 2.5-inch Advanced Format (AF) Yes RoHS compliant Yes Performance Data transfer rate (max) Interface Speed 6 Gb/s Cache (MB) 64 Performance Class 7200 RPM Average Drive Ready Time (sec) 3.8 Reliability/Data Integrity Load/unload cycles 600,000 Non-recoverable read errors per bits read <1 in 10 14 Power Management 5VDC +/- 10% (A, peak) 1.1 Average power requirements (W) Read/Write 2.0 Idle 0.85 Standby and Sleep 0.25 Environmental Specifications Temperature ( o C) Operating 0 to 65 Non-operating -40 to 65 Acoustics (dBA) Idle 24 Seek (average) 25

MPN WD20SPZX Capacity 2 TB Interface SATA 6Gb/s Form Factor RPM Class 5400RPM

MPN WD10SPZX Interface SATA 6 Gb/s Formatted capacity 1TB Form factor 2.5-inch Advanced Format (AF) Yes RoHS compliant 1 Yes Buffer to host 6 Gb/s Host to/from drive (sustained) 130 MB/s (nominal) Cache (MB) 128 Performance Class 5400 RPM Class Load/unload cycles2 600,000 Non-recoverable read errors per bits read <1 in 10 14 Read/Write 1.5 W Idle 0.5 W Standby/Sleep 0.1 W Operating ( o C) 0 to 60 Non-operating ( o C) -40 to 65 Operating (2 ms, read/write) 300G Non-operating (2 ms) 650G Idle 19 Seek (average) 21

MPN WD10EZEX Interface SATA 6Gb/s Formatted Capacity 1,000,204 MB User Sectors per Drive 1,953,525,169 SATA Latching Connector Yes Form Factor 3.5 inch RoHS Compliant Yes Performance Data Transfer Rate (Max) Buffer to Host: 6 Gb/s Host to/from Drive (Sustained): 150MB/s Cache (MB): 64 Rotational Speed (RPM): 7200 Reliability/Data Integrity Load/Unload Cycles: 300,000 Non-Recoverable Read Errors Per Bits Read: <1 in 10M Power Management 12VDC Peak (A, 10%): 2.5 Average Power Requirements (W) Read/Write: 6.8 Idle: 6.1 Standby: 1.2 Sleep: 1.2 Environmental Specifications Temperature (C) Operating: 0 to 60 Non-Operating: -40 to 70 Shock (GS) Operating (2ms read/write): 30 Operating (2ms Read): 65 Non-Operating (1ms): 350 Average Acoustics (dBA) Idle Mode: 29 Performance Seek Mode: 30

MPN WD2003FZEX Stock code ISwbd2000 Brand Western Digital Series Black Model WD2003FZEX ROHS Y Type SATA 6Gb/s Capacity 2TB Form factor / drive height 1" RPM 7200rpm Platter size 3.5" Cache 64MB Read speed (Max) 164 Main Type (Socket) SATA
