MPN ROG STRIX LC II 240 ARGB Water Block Water block dimention:80 x 80 x 45 mm Block Material (CPU Plate):Copper Radiator Radiator Dimension: 121 x 272 x 27 mm Radiator Material: Aluminum Tube: Sleeved Rubber tube Tube Length: 380 mm Fan Fan:ROG Designed ARGB Radiator Fan - Size: 2 x Fan Slots (120mm) - Speed: 800 - 2500 RPM +/- 10% - Static Pressure:5.0 mmH2O - Air Flow: 80.95 CFM / 137.5 m3h - Noise: 37.6 dB(A) - Control Mode: PWM/ DC Special Features AURA Sync Support:Yes Compatibility Intel: LGA 1700, 1200, 115x, 2011, 2011-3, 2066 AMD: AM4, TR4 Note Package Content 1 x Liquid Cooler (pre-applied thermal compound) 2 x 120 mm ARGB Radiator Fan 1 x USB cable for software control 1 x 1-to-2 Fan Splitter Cable 1 x 1 to 4 ARGB spliter cable 1 x Accessory Pack of Screws and Brackets 1 x Quick Start Guide 1 x ROG Sticker Note - The mounting bracket is bundled with TR4 CPU Package

MPN B660M-HDV Unique Feature ASRock Super Alloy - Premium Power Choke - Sapphire Black PCB - High Density Glass Fabric PCB ASRock Hyper M.2 (PCIe Gen4x4) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update and APP Shop CPU - Supports 12th Gen Intel Core TM Processors (LGA1700) - Digi Power design - 6 Power Phase design - Supports Intel Hybrid Technology - Supports Intel Turbo Boost Max 3.0 Technology Chipset - Intel B660 Memory - Dual Channel DDR4 Memory Technology - 2 x DDR4 DIMM Slots - Supports DDR4 non-ECC, un-buffered memory up to 5066+(OC) Note - Supports ECC UDIMM memory modules (operate in non-ECC mode) - Max. capacity of system memory: 64GB - Supports Intel Extreme Memory Profile (XMP) 2.0 Note: Supports DDR4 3200 natively. BIOS - 128Mb AMI UEFI Legal BIOS with multilingual GUI support - ACPI 6.0 Compliant wake up events - SMBIOS 2.7 Support - CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V PROC, +0.82V PCH, +1.05V PCH Voltage Multi-adjustment Graphics - Intel Xe Graphics Architecture (Gen 12) - Three graphics output options: D-Sub, HDMI and DisplayPort 1.4 - Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) at 60Hz / 5K (5120x3200) at 120Hz - Supports D-Sub with max. resolution up to 1920x1200 at 60Hz - Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports Note: Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. Audio - 7.1 CH HD Audio (Realtek ALC897/887 Audio Codec) - Supports Surge Protection LAN - Gigabit LAN 10/100/1000 Mb/s - Giga PHY Intel I219V - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports UEFI PXE Slots - 1 x PCIe Gen4x16 Slot Note - 2 x PCIe Gen3x1 Slots - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module Note: Supports NVMe SSD as boot disks Storage - 4 x SATA3 6.0 Gb/s Connectors Note1 - 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode Note2 - 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2260/2280 SATA3 6.0 Gb/s and PCIe Gen3x4 (32 Gb/s) modes Note2 Note1: If M2_2 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled. Note2: Supports Intel Optane TM Technology (M2_2 only) Supports Intel Volume Management Device (VMD) Supports NVMe SSD as boot disks Supports ASRock U.2 Kit RAID - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Connector - 1 x COM Port Header - 1 x SPI TPM Header - 1 x Chassis Intrusion and Speaker Header - 1 x CPU Fan Connector (4-pin) Note1 - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) Note2 - 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) Note3 - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x Front Panel Audio Connector - 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) Note1: The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. Note2: The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. Note3: The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CPU_FAN2/WP and CHA_FAN12/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O - 2 x Antenna Mounting Points - 1 x PS/2 Mouse/Keyboard Port - 1 x D-Sub Port - 1 x HDMI Port - 1 x DisplayPort 1.4 - 3 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection) - 1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection) - 2 x USB 2.0 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software - ASRock Motherboard Utility (A-Tuning) - ASRock XFast LAN UEFI - ASRock EZ Mode - ASRock Full HD UEFI - ASRock My Favorites in UEFI - ASRock Instant Flash - ASRock Internet Flash - ASRock Easy RAID Installer Note: These utilities can be downloaded from ASRock Live Update and APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version) Accessories - Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 3 x Screws for M.2 Sockets Hardware Monitor - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans - CASE OPEN detection - Voltage monitoring: CPU Vcore, +1.05 PCH, DRAM, VCCIN AUX, +1.05V PROC, +0.82V PCH, +12V, +5V, +3.3V Form Factor - Micro ATX Form Factor: 9.6-in x 7.9-in, 24.4 cm x 20.1 cm - Solid Capacitor design OS - Microsoft Windows 10 64-bit / 11 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) Item Dimension (L inchxW inchxH inch) 11 x 10 x 3 Weight 3.00 lb

MPN ROMED8U-2T Form Factor Micro-ATX Processor System CPU Support AMD EPYC TM 7003 and 7002 Series Processors - A BIOS update is required to support AMD EPYC TM 7003 Series Processors. Socket Single Socket SP3 (LGA4094) Chipset System on Chip System Memory Supported DIMM Quantity 8 DIMM slots (1DPC) Supported Type Supports DDR4 288-pin RDIMM, LRDIMM, RDIMM/LRDIMM-3DS Max. Capacity per DIMM RDIMM: up to 64GB LRDIMM: up to 128GB RDIMM/LRDIMM-3DS: up to 256GB DIMM Frequency RDIMM/ LRDIMM: max. 3200MHz Voltage 1.2V PCIe Expansion Slots (SLOT7 close to CPU) PCIe x 16 SLOT6: PCIe4.0 x16 SLOT5: PCIe4.0 x16 SLOT4: PCIe4.0 x16 Other PCIe Expansion Connectors M.2 slot 1 M-key (PCIe4.0 x4 or SATA 6Gb/s), supports 2280 form factor SlimSAS 2 SlimSAS (PCIe4.0 x8) SATA/SAS Storage PCH Built-in Storage AMD EPYC 7003/7002 (11 SATA 6Gb/s): 2 Mini-SAS HD, 2 SATA 7-pin, 1 M.2 Ethernet Additional GbE Controller 1 Intel X710-AT2: 2 RJ45 (10GbE) Server Management BMC Controller ASPEED AST2500 IPMI Dedicated GLAN 1 x Realtek RTL8211E for dedicated management GLAN Graphics Controller ASPEED AST2500 Rear I/O UID Button/LED 1 VGA Port 1 DB15 USB 3.2 Gen1 Port 2 Type-A (USB3.2 Gen1) RJ45 2 RJ45 (10GbE) Dedicate LAN 1 RJ45 (Dedicated IPMI) Internal Connector/Headers Other Power Connectors 1 (6-pin) for HDD power Auxiliary Panel Header 1 (18-pin): chassis intrusion, system fault LED, locate, SMBus System Panel 1 (9-pin): power switch, reset switch, system power LED, HDD activity LED NMI Button 1 COM Header 1 Speaker Header 1 Fan Header 6 (6-pin) Thermal Sensor Header 1 TPM Header 1 (13-pin, SPI), 1 (17-pin, LPC) SGPIO Header 1 HSBP 1 SMBus header 1 PMB header 1 IPMB Header 1 Clear CMOS 1 (contact pads) USB 3.2 (Gen1) Header 1 (19-pin, 2 USB3.2 Gen1) Power Connector 2 (8-pin, ATX 12V), 1 (4-pin, ATX) LED Indicators Standby PWR LED 5vsb 1 Fan Fail LED 6 BMC heartbeat LED 1 System BIOS BIOS Type 32MB AMI UEFI Legal BIOS BIOS Features Plug and Play (PnP), ACPI 2.0 Compliance Wake Up Events, SMBIOS 2.8.0, ASRock Rack Instant Flash Hardware Monitor Temperature CPU, Memory, MB, Card side Temperature Sensing Fan CPU/Rear/Front Fan Tachometer CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) CPU/Rear/Front Fan Multi-Speed Control" Voltage Voltage Monitoring: Vsoc,Vcpu, VCCM, VPPM, 3v/5v/12v, +BAT, 3VSB, 5VSB Environment Temperature Operation temperature: 10 o C to 35 o C / Non operation temperature: -40 o C to 70 o C Humidity Non operation humidity: 20% to 90% ( Non condensing)

MPN SNK-P0081AP4 Server Form Factor 4U Cooling Type Active CPU Configuration Uni Processor, Dual Processor Supported CPU SKU 3rd Gen Intel Xeon Scalable Processors Supported CPU Socket FCLGA4189 Supported CPU TDP Up to 270 Watts Attached Cooling Fan Speed Control: 4-pin PWM Rated Voltage: 12.0 VDC Rated Speed: 5,000 RPM Acoustic Noise: 43 dB(A) at Rated Speed Position: Front Side MTBF/MTTF: 3,000,000 Hours Product Environmental Compliance RoHS and REACH compliant, details available upon request

MPN MBD-X12SPL-LN4F-O Form Factor ATX Processor CPU 3rd Gen Intel Xeon Scalable processors Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP Core Up to 40 cores System Memory Memory Capacity 8 DIMM slots Up to 2TB Intel Optane TM Persistent Memory 200 Series Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz, Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz Memory Type 3200/2933/2666MHz ECC 3DS , DDR4 LRDIMM, RDIMM DIMM Sizes 8GB, 16GB, 32GB, 64GB, 128GB, 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors On-Board Devices Chipset Intel C621A SATA Intel C621A controller for 10 SATA3 (6 Gbps) ports, RAID 0,1,5,10 IPMI ASPEED AST2600 BMC Graphics ASPEED AST2600 BMC Network Controllers Quad LAN with Intel i210 Gigabit Ethernet Controller Input / Output SATA 10 SATA3 (6Gbps) port(s) LAN 4 RJ45 Gigabit Ethernet LAN ports USB 6 USB 2.0 port(s) (4 via header, 2 rear) 5 USB 3.2 Gen1 port(s) (2 via header, 2 rear, 1 type A) Video Output 1 VGA port(s) Serial Port 1 COM Port(s) (1 header) DOM 2 SATA DOM (Disk on Module) power connector support TPM 1 TPM Header Expansion Slots PCI-E 1 PCI-E 4.0 x16, 1 PCI-E 4.0 x8 (in x16 slot), 2 PCI-E 4.0 x8, 3 PCI-E 3.0 x8 M.2 M.2 Interface: 1 SATA/PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI BIOS Features ACPI 6.2 SMBIOS 3.0 or later UEFI 2.7 Management Software SuperDoctor 5, SUM, KVM with dedicated LAN, SPM, Intel Node Manager, SSM, IPMI2.0, Watchdog Power Configurations Power-on mode for AC power recovery, ACPI Power Management, CPU thermal trip support for processor protection PC Health Monitoring Voltage VBAT, System temperature, Monitors CPU voltages, HT, Chassis intrusion header, 3.3V standby, +5V standby, +5V, +3.3V, +12V, +1.8V, 7-fan status LED UID/Remote UID Suspend static indicator LED CPU / System Overheat LED Temperature CPU thermal trip support PECI FAN 7x 4-pin fan headers (up to 7 fans) System level control PWM fan speed control Fan speed control Overheat LED indication Other Features WOL UID RoHS Chassis intrusion header Chassis intrusion detection ATX Power connector ACPI power management RoT Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -40 o C - 70 o C (-40 o F - 158 o F) Operating Relative Humidity Range 10% - 85% (non-condensing) Non Operating Relative Humidity Range 10% - 95% (non-condensing)

MPN SNK-P0080AP4 Server Form Factor 4U Cooling Type Active CPU Configuration Uni Processor, Dual Processor Supported CPU SKU 3rd Gen Intel Xeon Scalable Processors Supported CPU Socket FCLGA4189 Supported CPU TDP Up to 270 Watts Attached Cooling Fan Speed Control: 4-pin PWM Rated Voltage: 12.0 VDC Rated Speed: 5,000 RPM Acoustic Noise: 43 dB(A) at Rated Speed Position: Front Side MTBF/MTTF: 3,000,000 Hours Product Environmental Compliance RoHS and REACH compliant, details available upon request

MPN RL-KRZ53-R1 Water Block Material (Block) Copper Material (Housing) Plastic Pump Motor Speed 800 - 2,800 +/- 300 RPM Power 12V DC, 0.3A Radiator Material Aluminum Tube Length 400mm Material Ultra-low Evaporation Rubber with Nylon Braided Sleeve Cap Material Aluminum, Plastic Fan Control Yes NZXT RGB Channel Connector 1 Rotation Orientation Software adjustable Default, +90, +180, and -90 Degrees LCD Display Panel Active Area 2.36" (60mm) Diameter Color 24-bit True Color LCD Resolution 320 x 320px Brightness 650 cd/m 2 Fan Specs Model Aer RGB 2 120mm Quantity 2 Speed 500 - 1,500 +/- 300RPM Airflow 17.48 - 52.44 CFM Air Pressure 0.14 - 1.35 mm-H2O Noise 22 - 33 dBA Bearing Fluid Dynamic Bearing Power Consumption 12V DC, 0.18A, 2.2W Fan Connector 4-pin PWM Life 60,000 hours / 6 Years Compatible Socket and CPU Intel Socket LGA 1200, 115X, 1366, 2011, 2011-3, 2066 AMD AMD Socket AM4, sTRX4, TR4 (Threadripper bracket not included)

MPN RL-KRZ63-R1 Water Block Material (Block) Copper Material (Housing) Plastic Pump Motor Speed 800 - 2,800 +/- 300 RPM Power 12V DC, 0.3A Radiator Material Aluminum Tube Length 400mm Material Ultra-low Evaporation Rubber with Nylon Braided Sleeve Cap Material Aluminum, Plastic Fan Control Yes NZXT RGB Channel Connector 1 Rotation Orientation Software adjustable Default, +90, +180, and -90 Degrees LCD Display Panel Active Area 2.36" (60mm) Diameter Color 24-bit True Color LCD Resolution 320 x 320px Brightness 650 cd/m 2 Fan Specs Model Aer RGB 2 140mm Quantity 2 Speed 500 - 1,500 +/- 300RPM Airflow 30.39 - 91.19 CFM Air Pressure 0.17 - 1.52 mm-H2O Noise 22 - 33 dBA Bearing Fluid Dynamic Bearing Power Consumption 12V DC, 0.32A, 3.8W Fan Connector 4-pin PWM Life 60,000 hours / 6 Years Compatible Socket and CPU Intel Socket LGA 1200, 115X, 1366, 2011, 2011-3, 2066 AMD AMD Socket AM4, sTRX4, TR4 (Threadripper bracket not included)

MPN O11AMX PRODUCT NAME O11 Air MINI COLOR Black MATERIAL 4mm Aluminum Panel 0.8mm Mesh Panel 4.0 mm Tempered Glass MOTHERBOARD SUPPORT E-ATX (Max 280 mm wide)/ ATX/ Micro-ATX/ Mini-ITX PSU SUPPORT ATX (Max. 200 mm) INCLUDED FAN (Front) 2 X 140mm PWM Fan (Rear) 1 X 120mm PWM Fan FAN SUPPORT (Top) 120mm X3 / 140mm X2 (Side) 120mm X2 (Bottom) 120mm X2/ 140mm X2 (Front) 120mm X2/ 140mm X2 (Rear)120 mm X1 RADIATOR SUPPORT (Top) 240mm or 280mm (Side) 240mm (Bottom) 240mm or 280mm (Front) 240mm or 280mm DRIVE SUPPORT 6 X 2.5" SSD or 2 X 2.5" SSD + 4 X 3.5" HDD GPU LENGTH CLEARANCE 362 mm CPU HEIGHT CLEARANCE 170 mm EXPANSION SLOTS 7 or 5 (depends on the back panel) I/O PORTS 2 X USB 3.0 1 X USB 3.1 Type-c 1 X HD Audio DUST FILTER 1 x removable bottom dust tray

MPN O11AMW PRODUCT NAME O11 Air MINI COLOR White MATERIAL 4mm Aluminum Panel 0.8mm Mesh Panel 4.0 mm Tempered Glass MOTHERBOARD SUPPORT E-ATX (Max 280 mm wide)/ ATX/ Micro-ATX/ Mini-ITX PSU SUPPORT ATX (Max. 200 mm) INCLUDED FAN (Front) 2 X 140mm PWM Fan (Rear) 1 X 120mm PWM Fan FAN SUPPORT (Top) 120mm X3 / 140mm X2 (Side) 120mm X2 (Bottom) 120mm X2/ 140mm X2 (Front) 120mm X2/ 140mm X2 (Rear)120 mm X1 RADIATOR SUPPORT (Top) 240mm or 280mm (Side) 240mm (Bottom) 240mm or 280mm (Front) 240mm or 280mm DRIVE SUPPORT 6 X 2.5" SSD or 2 X 2.5" SSD + 4 X 3.5" HDD GPU LENGTH CLEARANCE 362 mm CPU HEIGHT CLEARANCE 170 mm EXPANSION SLOTS 7 or 5 (depends on the back panel) I/O PORTS 2 X USB 3.0 1 X USB 3.1 Type-c 1 X HD Audio DUST FILTER 1 x removable bottom dust tray

MPN MBD-X12SAE-5-O Physical Stats Form Factor ATX Dimensions 12" x 9.6" (30.48cm x 24.38cm) Processor/Cache CPU 10th Generation Intel Core i9/Core i7/Core i5/Core i3/Pentium/Celeron Processor, 11th Generation Intel Core i5/i7/i9 Processors, Intel Xeon W-1200 Processors, Intel Xeon W-1300 Processors Single Socket LGA-1200 (Socket H5) supported, CPU TDP supports Up to 125W TDP Cores / Cache Up to 8 cores System Memory Memory Capacity 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-3200MHz, in 4 DIMM slots Memory Type 128GB ECC/Non-ECC 3200MHz UDIMM DIMM Sizes 2GB, 4GB, 8GB, 16GB, 32GB Memory Voltage 1.2V On-Board Devices Chipset Intel W580 SATA Intel W580 controller for 4 SATA3 (6 Gbps) ports RAID 0,1,5,10 Network Controllers Single LAN with Intel Ethernet i225V Single LAN with Intel PHY I219LM LAN controller for AMT/vPro Audio ALC 888S HD Audio Input / Output LAN 1 RJ45 2.5 Gigabit Ethernet LAN port 1 RJ45 Gigabit Ethernet LAN ports USB 2 USB 2.0 ports (2 via headers) 2 USB 3.2 Gen1 ports (2 via headers) 4 USB 3.2 Gen2 ports (4 Rear Type A 2 USB 3.2 Gen2x2 ports (1 Type C) Video Output 1 DP 1.4a port, 1 HDMI 2.0b port, 1 DVI - D port Serial Port / Header 1 COM Port (1 header) TPM 1 TPM Header Expansion Slots PCI-E 2 PCI-E 4.0 x16 slots (16/NA or 8/8)2 PCI-E 3.0 x1 1 - 5V PCI 32bit M.2 M.2 Interface: 1 PCI-E 4.0 x4 and 2 PCI-E 3.0 x4, RAID 0 and 1 Form Factor: 2280/22110 Key: M-Key RAID 5 only applied for INTEL Storage Device System BIOS BIOS Type 256Mb SPI Flash with AMI BIOS BIOS Features ACPI 6.0 Plug and Play (PnP) BIOS rescue hot keys Riser card auto-detection support SMBIOS 3.0 or later Management Software AMT, SSM, SUM, SuperDoctor 5, vPro, Watchdog System Management Software SuperDoctor 5 Power Configurations ACPI Power Management Power-on mode for AC power recovery Power button override mechanism Wake-on-LAN PC Health Monitoring Voltage +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT Temperature N/A LED Power LED, Catastrophic Error LED Other Features 8-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion detection, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -20 o C - 60 o C (-4 o F - 140 o F)

MPN MBD-X12SPO-F-B Physical Stats Form Factor ATX Processor CPU 3rd Gen Intel Xeon Scalable processors Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP Core Up to 40 cores System Memory Memory Capacity 8 DIMM slots Up to 2TB Intel Optane Persistent Memory 200 Series Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz Memory Type 3200/2933/2666MHz ECC 3DS , DDR4 LRDIMM, RDIMM DIMM Sizes 8GB, 16GB, 32GB, 64GB, 128GB, 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors On-Board Devices Chipset Intel C621A SATA Intel C621A controller for 10 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2600 BMC Graphics ASPEED AST2600 BMC Network Controllers Dual LAN with Intel i350 Gigabit Ethernet Controller Input / Output SATA 10 SATA3 (6Gbps) port(s) LAN 2 RJ45 Gigabit Ethernet LAN ports USB 6 USB 2.0 port(s) (4 via header 2 rear) 5 USB 3.2 Gen1 port(s) (2 via header 2 rear 1 type A) Video Output 1 VGA port(s) Serial Port 2 COM Port(s) (1 header 1 rear) DOM 2 SATA DOM (Disk on Module) power connector support TPM 1 TPM Header Expansion Slots PCI-E 1 PCI-E 4.0 x16 M.2 M.2 Interface: 2 SATA/PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI BIOS Features ACPI 6.2 SMBIOS 3.0 or later UEFI 2.7 Management Software SuperDoctor 5, SUM, KVM with dedicated LAN, SPM, Intel Node Manager, SSM, IPMI2.0, Watchdog Power Configurations Power-on mode for AC power recovery, ACPI Power Management, CPU thermal trip support for processor protection PC Health Monitoring Voltage VBAT, System temperature, Monitors CPU voltages, HT, Chassis intrusion header, 3.3V standby, +5V standby, +5V, +3.3V, +12V, +1.8V, 7-fan status LED UID/Remote UID Suspend static indicator LED CPU / System Overheat LED Temperature CPU thermal trip support PECI FAN 7x 4-pin fan headers (up to 7 fans) System level control PWM fan speed control Fan speed control Overheat LED indication Other Features WOL UID RoHS Chassis intrusion header Chassis intrusion detection ATX Power connector ACPI power management RoT Operating Environment Operating Temperature Range 0 o C - 50 o C (32 o F - 122 o F) Non-Operating Temperature Range -40 o C - 70 o C (-40 o F - 158 o F) Operating Relative Humidity Range 10% - 85% (non-condensing) Non Operating Relative Humidity Range 10% - 95% (non-condensing)

MPN N7-B55XT-B1 CPU AMD Socket AM4 Ryzen Processors (3000, 4000, and 5000 Series Processors) Supported AMD Ryzen 5 3400G and Ryzen 3200G Not Supported Chipset AMD B550 Memory DIMM Slots 4 Max Memory Support 128GB Memory Architecture Dual-Channel OC Frequency (Vermeer CPUs) 4666+ MHz OC Frequency (Matisse CPUs) 4666+ MHz OC Frequency (Renoir APUs) 4733+ MHz Base Frequency 3200/ 2933/ 2667/ 2400/ 2133 Type ECC and non-ECC, un-buffered memory XMP Support Supported Integrated Graphics AMD Radeon Vega Series Graphics in Ryzen Series APU HDMI HDMI Max Resolution 4096x2160 at 60Hz Max Shared Memory 16GB with 32GB installed Microsoft PlayReady Supported Multi-GPU Support AMD 2-Way CrossFireX Technology Supported Expansion Slots PCIe x16 (x16 mode) 1 (Vermeer and Matisse - PCIe 4.0, Renoir - PCIe 3.0) PCIe x16 (x4 mode) 1 PCIe 3.0 x1 2 Storage (Chipset) M.2 Type 2242/2260/2280 (x4 mode) 1 (Vermeer and Matisse - PCIe 4.0, Renoir - PCIe 3.0) M.2 Type 2242/2260/2280 (PCIe 3.0 x2 and SATA mode) 1 SATA 6Gb/s 6x (M2_2 and SATA3_5_6 share lanes) RAID 0/1/5/10 Support Supported LAN Realtek RTL8125BG 2.5G Wireless Intel Dual-Band Wireless AX210 Wi-Fi 6E Protocol 802.11 a/b/g/n/ac/ax Frequency Bands 2.4 / 5 / 6GHz MU-MIMO Support Supported Bluetooth V5.2 Audio Realtek ALC1220 Codec Channels 8-Channel High Definition Audio Playback 32-bit / 192kHz DAC Capacitors Nichicon Fine Gold Series Rear I/O USB 3.2 Gen 2 (Type-C) 1 USB 3.2 Gen 2 (Type-A) 3 USB 3.2 Gen 1 (Type-A) 4 USB 2.0 2 HDMI 2.1 1 Wireless Antenna 2 (2T2R) LAN (RJ45) Port 1 5.1-Channel Audio Jacks 1 Optical S/PDIF 1 BIOS Flashback Button 1 Clear CMOS Button 1 Internal I/O M.2 (M Key), Type 2242/2260/2280 1 (PCIe 4.0/3.0 x4 mode), 1 (PCIe 3.0 x2 and SATA mode) M.2 (E Key) (For wireless cards) 1 SATA 6Gbps Ports 6 USB 3.2 Gen 2 Header (Type-C) 1 USB 3.2 Gen 1 Header 1 (Up to 2 ports) USB 2.0 Header 3 (Up to 6 ports) Front Panel Audio 1 CPU_FAN Connector 1 (Up to 24W) AIO_PUMP Connector 1 (Up to 24W) SYS_FAN Connector 5 (Up to 24W) NZXT RGB LED Header 2 5V ARGB Header 1 12V RGB Header 1 24-pin EATX Power 1 8-pin ATX 12V Power 1 4-pin ATX 12V Power 1 Power Button 1 Reset Button 1 POST LEDs 4 General Operating System Windows 10 64-bit Form Factor ATX

MPN CYP2UHSSTD Essentials Product Collection Heat-Sink Options Code Name Products formerly Coyote Pass Included Items (1) 2U tall heat sink Supplemental Information Description 2U Tall Heat Sink

MPN CD8068904657502 Essentials Product Collection 3rd Generation Intel Xeon Scalable Processors Code Name Products formerly Ice Lake Vertical Segment Server Processor Number 6326 Lithography 10 nm CPU Specifications Number of Cores 16 Number of Threads 32 Processor Base Frequency 2.90 GHz Max Turbo Frequency 3.50 GHz Cache 24 MB Number of UPI Links 3 TDP 185 W Supplemental Information Embedded Options Available Yes Memory Specifications Max Memory Size (dependent on memory type) 6 TB Memory Types DDR4-3200 Maximum Memory Speed 3200 MHz Max Number of Memory Channels 8 ECC Memory Supported Yes Intel Optane Persistent Memory Supported Yes Expansion Options Scalability 2S PCI Express Revision 4.0 Max Number of PCI Express Lanes 64 Package Specifications Sockets Supported FCLGA4189 TCASE 78 o C Package Size 77.5mm x 56.5mm Advanced Technologies Intel Speed Select Technology Core Power Yes Intel Speed Select Technology Turbo Frequency Yes Intel Deep Learning Boost (Intel DL Boost) Yes Intel Speed Select Technology - Base Frequency Yes Intel Resource Director Technology (Intel RDT) Yes Intel Speed Shift Technology Yes Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions Yes Intel 64 Yes Instruction Set Extensions Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512 Number of AVX-512 FMA Units 2 Intel Volume Management Device (VMD) Yes Security and Reliability Intel AES New Instructions Yes Intel Software Guard Extensions (Intel SGX) Yes with Intel SPS Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Run Sure Technology Yes Mode-based Execute Control (MBE) Yes Intel Total Memory Encryption Yes

MPN CD8068904655303 Essentials Product Collection 3rd Generation Intel Xeon Scalable Processors Code Name Products formerly Ice Lake Vertical Segment Server Processor Number 4314 Lithography 10 nm CPU Specifications Number of Cores 16 Number of Threads 32 Processor Base Frequency 2.40 GHz Max Turbo Frequency 3.40 GHz Cache 24 MB Number of UPI Links 2 TDP 135 W Intel UPI Speed 10.4 GT/s Supplemental Information Embedded Options Available Yes Memory Specifications Max Memory Size (dependent on memory type) 6 TB Memory Types DDR4-2667 Maximum Memory Speed 2667 MHz Max Number of Memory Channels 8 ECC Memory Supported Yes Intel Optane Persistent Memory Supported Yes Expansion Options Scalability 2S PCI Express Revision 4.0 Max Number of PCI Express Lanes 64 Package Specifications Sockets Supported FCLGA4189 TCASE 86 o C Package Size 77.5mm x 56.5mm Advanced Technologies Intel Deep Learning Boost (Intel DL Boost) Yes Intel Resource Director Technology (Intel RDT) Yes Intel Speed Shift Technology Yes Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions Yes Intel 64 Yes Instruction Set Extensions Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512 Number of AVX-512 FMA Units 2 Intel Volume Management Device (VMD) Yes Security and Reliability Intel AES New Instructions Yes Intel Software Guard Extensions (Intel SGX) Yes with Intel SPS Intel Trusted Execution Technology Yes Execute Disable Bit Yes Mode-based Execute Control (MBE) Yes Intel Total Memory Encryption Yes Intel Platform Firmware Resilience Support Yes Maximum Enclave Size Support for Intel SGX 8 GB Intel Crypto Acceleration Yes

MPN CD8068904657701 Essentials Product Collection 3rd Generation Intel Xeon Scalable Processors Code Name Products formerly Ice Lake Vertical Segment Server Processor Number 6342 Lithography 10 nm CPU Specifications Number of Cores 24 Number of Threads 48 Processor Base Frequency 2.80 GHz Max Turbo Frequency 3.50 GHz Cache 36 MB Number of UPI Links 3 TDP 230 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 6 TB Memory Types DDR4-3200 Maximum Memory Speed 3200 MHz Max Number of Memory Channels 8 ECC Memory Supported Yes Intel Optane Persistent Memory Supported Yes Expansion Options Scalability 2S PCI Express Revision 4.0 Max Number of PCI Express Lanes 64 Package Specifications Sockets Supported FCLGA4189 TCASE 81 o C Package Size 77.5mm x 56.5mm Advanced Technologies Intel Speed Select Technology Core Power Yes Intel Speed Select Technology Turbo Frequency Yes Intel Deep Learning Boost (Intel DL Boost) Yes Intel Speed Select Technology - Performance Profile Yes Intel Resource Director Technology (Intel RDT) Yes Intel Speed Shift Technology Yes Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions Yes Intel 64 Yes Instruction Set Extensions Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512 Number of AVX-512 FMA Units 2 Intel Volume Management Device (VMD) Yes Security and Reliability Intel AES New Instructions Yes Intel Software Guard Extensions (Intel SGX) Yes with Intel SPS Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Run Sure Technology Yes Mode-based Execute Control (MBE) Yes Intel Total Memory Encryption Yes

MPN CD8068904572204 Essentials Product Collection 3rd Generation Intel Xeon Scalable Processors Code Name Products formerly Ice Lake Vertical Segment Server Processor Number 6348 Lithography 10 nm CPU Specifications Number of Cores 28 Number of Threads 56 Processor Base Frequency 2.60 GHz Max Turbo Frequency 3.50 GHz Cache 42 MB Number of UPI Links 3 TDP 235 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 6 TB Memory Types DDR4-3200 Maximum Memory Speed 3200 MHz Max Number of Memory Channels 8 ECC Memory Supported Yes Intel Optane Persistent Memory Supported Yes Expansion Options Scalability 2S PCI Express Revision 4.0 Max Number of PCI Express Lanes 64 Package Specifications Sockets Supported FCLGA4189 TCASE 80 o C Package Size 77.5mm x 56.5mm Advanced Technologies Intel Speed Select Technology Core Power Yes Intel Speed Select Technology Turbo Frequency Yes Intel Deep Learning Boost (Intel DL Boost) Yes Intel Speed Select Technology - Base Frequency Yes Intel Resource Director Technology (Intel RDT) Yes Intel Speed Shift Technology Yes Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions Yes Intel 64 Yes Instruction Set Extensions Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512 Number of AVX-512 FMA Units 2 Intel Volume Management Device (VMD) Yes Security and Reliability Intel AES New Instructions Yes Intel Software Guard Extensions (Intel SGX) Yes with Intel SPS Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Run Sure Technology Yes Mode-based Execute Control (MBE) Yes Intel Total Memory Encryption Yes

MPN PRO A520M-C II/CSM CPU AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors Refer to www.asus.com for CPU support list. Chipset AMD A520 Chipset Memory DDR4 4866(O.C.)/4600(O.C.)/4466(O.C.)/4400(O.C.)/4333(O.C.)/4266(O.C.)/4200(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/346(O.C.)/3400(O.C.)/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz, Un-buffered Memory Dual Channel Memory Architecture ECC memory (ECC mode) support varies by CPU. Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types. Graphics 1 x DisplayPort 1.2 1 x D-Sub 1 x DVI-D Graphics specifications may vary between CPU types. The DVI-D port and the DisplayPort cannot work at the same time. Only the DVI-D port functions when the two ports are both connected. Expansion Slots 1 x PCIe 3.0 x16 (x16 mode) AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors 1 x PCIe 3.0 x16 slot (supports x16 mode) AMD A520 Chipset 2 x PCIe 3.0 x1 slots 1 x PCI slot Storage Supports 1 x M.2 slot and 4 x SATA 6Gb/s ports AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 and SATA modes) AMD A520 Chipset 4 x SATA 6Gb/s ports Support RAID 0, 1, 10 Ethernet 1 x Realtek 1Gb Ethernet ASUS LANGuard USB Rear USB:Total 6 ports 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB:Total 6 ports 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Audio Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. Back Panel I/O Ports 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 1 x Realtek 1Gb Ethernet port 3 x Audio jacks 1 x COM port 1 x PS/2 Keyboard (purple) port 1 x PS/2 Mouse (green) port Intrernal I/O Connectors Fan and Cooling related 1 x 4-pin CPU Fan header 2 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 1 x M.2 slot (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 1 x Clear CMOS header 1 x Chassis Intrude header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x LPC debug header 1 x LPT header 1 x SMBUS header 1 x Speaker header 1 x 10-1 pin System Panel header Special Features ASUS Q-Design - ASUS Q-DIMM - ASUS Q-Slot ASUS Thermal Solution - Aluminum heatsink design ASUS EZ DIY - Box Headers Bespoke Motherboard Design and Business Focused Features - ASUS Self Recovering BIOS - ASUS Event Log - ASUS Commercial BIOS kit - Anti-Moisture Coating - 24/7 Reliability - Overcurrent Protection TPM 2.0 IC Onboard Software Features ASUS Exclusive Software IT Management software supported - ASUS Control Center Express(ACCE) BIOS 128 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PME, PXE Accessories Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x I/O Shield 1 x M.2 SSD screw package Installation Media 1 x Support DVD Documentation 1 x ACC Express Activation Key Card 1 x User manual Form Factor microATX 24.4cm x 22.9cm

MPN H610M-HDV/M.2 Unique Feature ASRock Super Alloy - Premium Power Choke - Sapphire Black PCB - High Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen3x4 and SATA3) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update and APP Shop CPU - Supports 12th Gen Intel Core TM Processors (LGA1700) - Digi Power design - 6 Power Phase design - Supports Intel Hybrid Technology - Supports Intel Turbo Boost Max 3.0 Technology Chipset - Intel H610 Memory - Dual Channel DDR4 Memory Technology - 2 x DDR4 DIMM Slots - Supports DDR4 non-ECC, un-buffered memory up to 3200 - Supports ECC UDIMM memory modules (operate in non-ECC mode) - Max. capacity of system memory: 64GB - Supports Intel Extreme Memory Profile (XMP) 2.0 BIOS - 128Mb AMI UEFI Legal BIOS with multilingual GUI support - ACPI 6.0 Compliant wake up events - SMBIOS 2.7 Support - CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V PROC, +0.82V PCH, +1.05V PCH Voltage Multi-adjustment Graphics - Intel Xe Graphics Architecture (Gen 12) - Three graphics output options: D-Sub, HDMI and DisplayPort 1.4 - Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) at 60Hz / 5K (5120x3200) at 120Hz - Supports D-Sub with max. resolution up to 1920x1200 at 60Hz - Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports Note: Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. Audio - 7.1 CH HD Audio (Realtek ALC897/887 Audio Codec) - Supports Surge Protection LAN - Gigabit LAN 10/100/1000 Mb/s - Giga PHY Intel I219V - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports UEFI PXE Slots - 1 x PCIe Gen4x16 Slot Note - 2 x PCIe Gen3x1 Slots - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module Note: Supports NVMe SSD as boot disks Storage - 4 x SATA3 6.0 Gb/s Connectors Note1 - 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2260/2280 SATA3 6.0 Gb/s and PCIe Gen3x4 (32 Gb/s) modes Note2 Note1: If M2_2 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled. Note2: Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x COM Port Header - 1 x SPI TPM Header - 1 x Chassis Intrusion and Speaker Header - 1 x CPU Fan Connector (4-pin) Note1 - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) Note2 - 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) Note3 - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x Front Panel Audio Connector - 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) Note1: The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. Note2: The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. Note3: The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CPU_FAN2/WP and CHA_FAN12/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O - 2 x Antenna Mounting Points - 1 x PS/2 Mouse/Keyboard Port - 1 x D-Sub Port - 1 x HDMI Port - 1 x DisplayPort 1.4 - 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 2 x USB 2.0 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software - ASRock Motherboard Utility (A-Tuning) - ASRock XFast LAN UEFI - ASRock EZ Mode - ASRock Full HD UEFI - ASRock My Favorites in UEFI - ASRock Instant Flash - ASRock Internet Flash Note: These utilities can be downloaded from ASRock Live Update and APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version) Accessories - Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 2 x Screws for M.2 Sockets Hardware Monitor - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans - CASE OPEN detection - Voltage monitoring: CPU Vcore, +1.05 PCH, DRAM, VCCIN AUX, +1.05V PROC, +0.82V PCH, +12V, +5V, +3.3V Form Factor - Micro ATX Form Factor: 9.6-in x 7.9-in, 24.4 cm x 20.1 cm - Solid Capacitor design OS - Microsoft Windows 10 64-bit / 11 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) Item Dimension (L inchxW inchxH inch) 11 x 10 x 3 Weight 3.00 lb

MPN BX8070811700 Essentials Product Collection 11th Generation Intel Core TM i7 Processors Code Name Products formerly Rocket Lake Vertical Segment Desktop Processor Number i7-11700 Lithography 14 nm Use Conditions PC/Client/Tablet CPU Specifications Number of Cores 8 Number of Threads 16 Processor Base Frequency 2.50 GHz Max Turbo Frequency 4.90 GHz Cache 16 MB Intel Smart Cache Bus Speed 8 GT/s Intel Turbo Boost Max Technology 3.0 Frequency 4.90 GHz Intel Turbo Boost Technology 2.0 Frequency 4.80 GHz TDP 65 W Supplemental Information Embedded Options Available No Datasheet https://www.intel.com/content/www/us/en/products/docs/processors/core/core-technical-resources.html Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types DDR4-3200 Max Number of Memory Channels 2 Max Memory Bandwidth 50 GB/s ECC Memory Supported No Processor Graphics Processor Graphics Intel UHD Graphics 750 Graphics Base Frequency 350 MHz Graphics Max Dynamic Frequency 1.30 GHz Graphics Video Max Memory 64 GB Execution Units 32 4K Support Yes, at 60Hz Max Resolution (HDMI) 4096x2160 at 60Hz Max Resolution (DP) 5120 x 3200 at 60Hz Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 at 60Hz DirectX Support 12.1 OpenGL Support 4.5 Intel Quick Sync Video Yes Intel InTru TM 3D Technology Yes Intel Clear Video HD Technology Yes Intel Clear Video Technology Yes Number of Displays Supported 3 Device ID 0x4C8A OpenCL Support 3.0 Expansion Options Scalability 1S Only PCI Express Revision 4.0 PCI Express Configurations Up to 1x16+1x4, 2x8+1x4, 1x8+3x4 Max Number of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1200 Max CPU Configuration 1 Thermal Solution Specification PCG 2019C TJUNCTION 100 o C Advanced Technologies Intel Deep Learning Boost (Intel DL Boost) Yes Intel Thermal Velocity Boost No Intel Turbo Boost Max Technology 3.0 Yes Intel Turbo Boost Technology 2.0 Intel vPro Platform Eligibility Yes Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2, Intel AVX-512 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Intel Identity Protection Technology Yes Intel Stable Image Platform Program (SIPP) Yes Intel Gaussian and Neural Accelerator 2.0 Yes Security and Reliability Intel AES New Instructions Yes Secure Key Yes Intel Software Guard Extensions (Intel SGX) No Intel OS Guard Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Boot Guard Yes

MPN CD8068904571601 Essentials Product Collection 3rd Generation Intel Xeon Scalable Processors Code Name Products formerly Ice Lake Vertical Segment Server Processor Number 6354 Lithography 10 nm CPU Specifications Number of Cores 18 Number of Threads 36 Processor Base Frequency 3.00 GHz Max Turbo Frequency 3.60 GHz Cache 39 MB Number of UPI Links 3 TDP 205 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 6 TB Memory Types DDR4-3200 Maximum Memory Speed 3200 MHz Max Number of Memory Channels 8 ECC Memory Supported Yes Intel Optane Persistent Memory Supported Yes Expansion Options Scalability 2S PCI Express Revision 4.0 Max Number of PCI Express Lanes 64 Package Specifications Sockets Supported FCLGA4189 TCASE 77 o C Package Size 77.5mm x 56.5mm Advanced Technologies Intel Speed Select Technology Core Power Yes Intel Speed Select Technology Turbo Frequency Yes Intel Deep Learning Boost (Intel DL Boost) Yes Intel Speed Select Technology - Base Frequency Yes Intel Resource Director Technology (Intel RDT) Yes Intel Speed Shift Technology Yes Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions Yes Intel 64 Yes Instruction Set Extensions Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512 Number of AVX-512 FMA Units 2 Intel Volume Management Device (VMD) Yes Security and Reliability Intel AES New Instructions Yes Intel Software Guard Extensions (Intel SGX) Yes with Intel SPS Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Run Sure Technology Yes Mode-based Execute Control (MBE) Yes Intel Total Memory Encryption Yes

MPN CD8068904657601 Essentials Product Collection 3rd Generation Intel Xeon Scalable Processors Code Name Products formerly Ice Lake Vertical Segment Server Processor Number 6334 Lithography 10 nm CPU Specifications Number of Cores 8 Number of Threads 16 Processor Base Frequency 3.60 GHz Max Turbo Frequency 3.70 GHz Cache 18 MB Number of UPI Links 3 TDP 165 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 6 TB Memory Types DDR4-3200 Maximum Memory Speed 3200 MHz Max Number of Memory Channels 8 ECC Memory Supported Yes Intel Optane Persistent Memory Supported Yes Expansion Options Scalability 2S PCI Express Revision 4.0 Max Number of PCI Express Lanes 64 Package Specifications Sockets Supported FCLGA4189 TCASE 69 o C Package Size 77.5mm x 56.5mm Advanced Technologies Intel Speed Select Technology Core Power Yes Intel Speed Select Technology Turbo Frequency Yes Intel Deep Learning Boost (Intel DL Boost) Yes Intel Speed Select Technology - Base Frequency Yes Intel Resource Director Technology (Intel RDT) Yes Intel Speed Shift Technology Yes Intel Turbo Boost Technology 2.0 Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions Yes Intel 64 Yes Instruction Set Extensions Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512 Number of AVX-512 FMA Units 2 Intel Volume Management Device (VMD) Yes Security and Reliability Intel AES New Instructions Yes Intel Software Guard Extensions (Intel SGX) Yes with Intel SPS Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Run Sure Technology Yes Mode-based Execute Control (MBE) Yes Intel Total Memory Encryption Yes

MPN PRO B550M-C/CSM CPU AMD AM4 Socket for AMD Ryzen TM 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors Chipset AMD B550 Memory AMD Ryzen TM 5000 Series/ 3000 Series Desktop Processors 4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory AMD Ryzen TM 4000 G-Series Desktop Processors 4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory Dual Channel Memory Architecture ECC Memory (ECC mode) support varies by CPU. Graphic 2 x DisplayPort 1 x HDMI 2.1(4K at 60HZ) Graphics specifications may vary between CPU types. Expansion Slots AMD Ryzen TM 5000 Series/ 3000 Series Desktop Processors 1 x PCIe 4.0 x16 (x16 mode) AMD Ryzen TM 4000 G-Series Desktop Processors 1 x PCIe 3.0 x16 (x16 mode) AMD B550 Chipset 1 x PCIe 3.0 x4 1 1 x PCI Support PCIe bifurcation for RAID on CPU function. Storage Total supports 2 x M.2 slot(s) and 4 x SATA 6Gb/s ports AMD Ryzen TM 5000 Series/ 3000 Series Desktop Processors : 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support AMD RyzenTM 4000 G-Series Processors : 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support AMD B550 Chipset : 1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support 4 x SATA 6Gb/s port(s), Support Raid 0, 1, 10 LAN Realtek RTL8111H 1Gb Ethernet Audio Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Choose the chassis with HD audio module in front panel to support 8-channel audio output. USB Ports Rear USB Port ( Total 6 ) 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C) 2 x USB 3.2 Gen 1 port(s)(2 x Type-A) 2 x USB 2.0 port(s)(2 x Type-A) Front USB Port ( Total 7 ) 4 x USB 3.2 Gen 1 port(s)(4 x Type-A) 3 x USB 2.0 port(s) Software Features ASUS Exclusive Software IT Management software supported - ASUS Control Center Express(ACCE) ASUS Special Features ASUS Q-Design - ASUS Q-DIMM - ASUS Q-Slot ASUS Thermal Solution - Aluminum heatsink design ASUS EZ DIY - Box Headers Bespoke Motherboard Design and Business Focused Features - ASUS Self Recovering BIOS - ASUS Event Log - ASUS Commercial BIOS kit - Anti-Moisture - 24/7 Reliability - Overcurrent Protection TPM2.0 IC Onboard Back I/O Ports 1 x Realtek RTL8111H 1 x PS/2 keyboard (purple) 1 x PS/2 mouse (green) 2 x DisplayPort 1 x HDMI 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C) 2 x USB 3.2 Gen 1 Type-A 2 x USB 2.0 3 x Audio jack(s) Internal I/O Ports 1 x CPU Fan connector(s) 2 x Chassis Fan connector(s) 2 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.2 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 3 USB 2.0 port(s) 2 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode and X4 PCIE mode) 1 x M.2 with E key for Wi-Fi module 1 x LPT header 4 x SATA 6Gb/s connector(s) 1 x Thunderbolt header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors 1 x Front panel audio connector(s) (AAFP) 1 x SMBus header(s) 1 x System panel(s) 1 x Clear CMOS jumper(s) 1 x COM port header 1 x Chassis intrusion header 1 x LPC Debug header 1 x Speaker connector Accessories 1 x ACC Express Activation Key Card I/O Shield 2 x SATA 6Gb/s cable(s) 1 x Supporting DVD User manual 3 x M.2 SSD screw package(s) 2 x M.2 SSD Hex screw packages BIOS 256 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PXE Operating System Windows 10 64-bit Form Factor mATX Form Factor 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm ) Note 1 The PCIe x4 slot runs x2 mode when the PCI slot is occupied.
