MPN BX80684E2224 Essentials Product Collection Intel Xeon E Processor Code Name Products formerly Coffee Lake Vertical Segment Server Processor Number E-2224 Lithography 14 nm Performance Specifications Number of Cores 4 Number of Threads 4 Processor Base Frequency 3.40 GHz Max Turbo Frequency 4.60 GHz Cache 8 MB Intel Smart Cache Bus Speed 8 GT/s Intel Turbo Boost Technology 2.0 Frequency 4.60 GHz TDP 71 W Supplemental Information Embedded Options Available No Description Support for up to 128GB system memory may require a BIOS update. Please contact your hardware provider regarding availability for your system. Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types DDR4-2666 Max Number of Memory Channels 2 ECC Memory Supported Yes Processor Graphics Graphics Output N/A 4K Support No Max Resolution (HDMI 1.4) N/A Max Resolution (DP) N/A Max Resolution (eDP - Integrated Flat Panel) N/A Max Resolution (VGA) N/A DirectX Support N/A OpenGL Support N/A Intel Quick Sync Video No Intel InTru 3D Technology No Intel Clear Video HD Technology No Intel Clear Video Technology No Device ID N/A Expansion Options Scalability 1S Only PCI Express Revision 3.0 PCI Express Configurations 1x16,2x8,1x8+2x4 Max Number of PCI Express Lanes 16 Package Specifications Sockets Supported FCLGA1151 Max CPU Configuration 1 TCASE 69.3 o C TJUNCTION 100 Package Size 37.5 mm x 37.5 mm Advanced Technologies Intel Optane Memory Supported Yes Intel Turbo Boost Technology 2.0 Intel vPro Platform Eligibility Yes Intel Hyper-Threading Technology No Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions Yes Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Security and Reliability Intel AES New Instructions Yes Secure Key Yes Intel Software Guard Extensions (Intel SGX) Yes with Intel ME Intel Memory Protection Extensions (Intel MPX) Yes Intel OS Guard Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Boot Guard Yes

MPN PRIME B550-PLUS CPU Build in AMD AM4 Socket 3rd Gen AMD Ryzen Processors Refer to www.asus.com for CPU support list Chipset AMD B550 Memory 4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory Next Generation AMD Ryzen PRO Processors 4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory Dual Channel Memory Architecture Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). Graphic 1 x DisplayPort 1.2 1 x HDMI 2.1(4K at 60HZ) Graphics specifications may vary between CPU types. Multi-GPU Support Supports AMD 2-Way CrossFireX Technology Expansion Slots 3rd Gen AMD Ryzen Processors 1 x PCIe 4.0 x16 (x16 mode) AMD B550 Chipset 1 x PCIe 3.0 x16 (x4 mode) 3 x PCIe 3.0 x1 Support PCIe bifurcation for RAID on CPU function. Storage Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports 3rd Gen AMD Ryzen Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support(SATA and PCIe 4.0 x4 mode) AMD B550 Chipset : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA and PCIE 3.0 x 4 mode) 6 x SATA 6Gb/s port(s), Support Raid 0, 1, 10 LAN Realtek RTL8111H ASUS LANGuard Audio Realtek ALC887 7.1-Channel High Definition Audio CODEC - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature : - Optical S/PDIF out port(s) at back panel - LED-illuminated design - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors - Unique de-pop circuit USB Ports Rear USB Port ( Total 8 ) 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C) 4 x USB 3.2 Gen 1 port(s)(4 x Type-A) 2 x USB 2.0 port(s)(2 x Type-A) Front USB Port ( Total 6 ) 2 x USB 3.2 Gen 1 port(s)(2 x Type-A) 4 x USB 2.0 port(s)(4 x Type-A) Software Features ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert 4 - EZ update ASUS CPU-Z AI Charger DAEMON Tools Norton Anti-virus software (Free Trial for 60 days) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode ASUS Special Features ASUS 5X PROTECTION III - ASUS DIGI+ VRM - ASUS Enhanced DRAM Overcurrent Protection - ASUS ESD Guards - ASUS LANGuard - ASUS Overvoltage Protection - ASUS SafeSlot Core - ASUS Stainless-Steel Back I/O ASUS Q-Design - ASUS Q-DIMM - ASUS Q-LED (CPU red, DRAM yellow, VGA white, Boot Device yellow green) - ASUS Q-Slot ASUS Thermal Solution - Aluminum heatsink design ASUS EZ DIY - SafeSlot AURA Sync - Standard RGB headers - Addressable Gen 2 RGB header Back I/O Ports 1 x DisplayPort 1 x HDMI 1 x LAN (RJ45) port(s) 2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C) 4 x USB 3.2 Gen 1 (blue) Type-A 2 x USB 2.0 1 x Optical S/PDIF out 5 x Audio jack(s) Internal I/O Ports 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 3 x Chassis Fan connector(s) 1 x AIO_PUMP connector 2 x Aura RGB Strip Headers 1 x Addressable Gen 2 header(s) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support(SATA and PCIe 4.0 x4 mode) 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA and PCIE 3.0 x 4 mode) 1 x SPI TPM header 6 x SATA 6Gb/s connector(s) 1 x Thunderbolt header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors 1 x Front panel audio connector(s) (AAFP) 1 x Thermal sensor connector(s) 1 x Clear CMOS jumper(s) 1 x System panel connector 1 x COM port header Accessories Users manual I/O Shield 2 x SATA 6Gb/s cable(s) 1 x Supporting DVD 1 x M.2 SSD screw package(s) BIOS 256 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PME, PXE Operating System Windows 10 64-bit Form Factor ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

MPN PRIME H510M-E CPU Intel Socket LGA1200 for 11th Gen Intel Core TM Processors and 10th Gen Intel Core TM , Pentium Gold and Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 Refer to www.asus.com for CPU support list. Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. Chipset Intel H510 Chipset Memory Memory Channels:2DDR4 (Dual Channel) Max Memory Size:64GB DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) 10th Gen Intel Core TM i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz. 11th Gen Intel processors support 2933/2800/2666/2400/2133 natively. Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency Graphics 1 x DisplayPort 1.4 1 x D-Sub 1 x HDMI TM 2.0 Graphics specifications may vary between CPU types. Intel 11th and 10th Gen processors support DisplayPort 1.4 with max. resolution of 4096 x 2304 at 60Hz. Please refer to www.intel.com for any update. Only Intel 11th Gen processors support HDMI TM 2.0 with max. resolution of 4K at 60Hz, others will only support HDMI TM 1.4 with max. resolution of 4K at 30Hz. Please refer to www.intel.com for any updates. Expansion Slots Intel 11th and 10th Gen Processors Expansion Slots Intel 11th and 10th Gen Processors 1 x PCIe 4.0/3.0 x16 slot - Intel 11th Gen processors support PCIe 4.0 x16 - Intel 10th Gen processors support PCIe 3.0 x16 Intel H510 Chipset 2 x PCIe 3.0 x1 slots Storage Supports 1 x M.2 slot and 4 x SATA 6Gb/s ports Intel H510 Chipset M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 and SATA modes) 4 x SATA 6Gb/s ports The M.2 slot shares bandwidth with SATA6G_2. When a device in SATA mode is installed on the M.2 slot, SATA6G_2 port cannot be used. Ethernet 1 x Intel I219-V 1Gb Ethernet USB Rear USB:Total 4 ports 2 x USB 3.2 Gen 1 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB:Total 6 ports 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Audio ALC887/897 Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback" Audio Features - Audio Shielding - Premium Japanese audio capacitors - Dedicated audio PCB layers A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. Back Panel I/O Ports 2 x USB 3.2 Gen 1 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x D-Sub port 1 x HDMI TM port 1 x Intel I219-V 1Gb Ethernet port 3 x Audio jacks 1 x PS/2 Keyboard (purple) port 1 x PS/2 Mouse (green) port Intrernal I/O Connectors Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin Chassis Fan header Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 1 x M.2 slot (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 1 x RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x S/PDIF Out header 1 x Speaker header 1 x SPI TPM header (14-1pin) 1 x 10-1 pin System Panel header Special Features ASUS 5X PROTECTION III - DIGI+ VRM - LANGuard - Overvoltage Protection - SafeSlot Core - Stainless-Steel Back I/O ASUS Q-Design - Q-DIMM - Q-Slot ASUS Thermal Solution - Aluminum heatsink design ASUS Lighting Control - RGB header Software Features ASUS Exclusive Software Armoury Crate AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU DIGI+ VRM Fan Xpert - EZ update ASUS CPU-Z AI Charger DAEMON Tools Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode BIOS 128 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PME, PXE Accessories Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x I/O Shield 1 x M.2 SSD screw package Installation Media 1 x Support DVD Documentation 1 x User manual Operating System Windows 10 64bit Form Factor microATX 22.6cm x 21.1cm

MPN P12R-E/10G-2T Processor / System Bus 1 x Socket LGA1200 Intel Pentium TM processors Intel Xeon E Processors Core Logic Intel C256 Chipset Memory Total Slots : 4 (2-channel) Capacity : Maximum up to 128GB UDIMM Memory Type : DDR4 3200/2933/2666 UDIMM Memory Size : 32GB, 16GB, 8GB Note: Refer to support page for more information Expansion Slots Total Slot : 4 Slot Location 1 : PCI-E x8 (Gen3 X4 Link) Slot Location 2 : PCI-E x8 (Gen3 X4 Link) Slot Location 4 : PCI-E x8 (Gen4 X8 Link) Slot Location 6 : PCI-E x16 (Gen4 X16 Link), Auto switch to x8 link if slot 4 is occupied Form Factor ATX (12"x9.6", 305mm x 244mm) ASUS Features FAN speed control Rack Ready (Rack and Pedestal dual use) ASUS Control Center Storage Storage Controller : 8 x SATA3 6Gb/s ports by 4 Mini-SAS HD connectors 2 x M.2 connector(2242/2260/2280/22110) both SATA and PCIe mode Note1 SAS Controller : ASUS PIKE II 3008-8i 8-port SAS 12G RAID card ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card Networking 1 x Dual Port Intel X710-AT2 Gigabit 10G LAN Controller + 1 x Mgmt LAN Graphic Aspeed AST2600 with 64MB VRAM Note2 On Board I/O 1 x VGA Header Note2 1 x HDMI Note3 1 x TPM header 1 x COM port 1 x PS/2 KB/MS port 1 x Onboard header for optional management card 6 x Fan Header , 4pin 1 x SMBus 1 x Chassis Intruder 4 x Front LAN LED 1 x Serial Port Header 1 x PSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector) 2 x M.2 Connector 2 x USB3.2 Gen2 ports 2 x USB3.2 Gen1 ports 1 x USB3.2 Gen1 header Back I/O Ports 2 x USB 3.2 Gen 2 2 x USB 3.2 Gen 1 1 x HDMI Port (useable only with iGPU) 1 x VGA Port (VGA from BMC) 2 x GbE LAN + 1 x Mgmt LAN 1 x PS/2 KB/Mouse Management Solution ASUS Control Center Enterprise (Optional) ASMB10-iKVM for KVM-over-Internet (Optional) Environment Operation temperature: 10 o C to 50 o C Non operation temperature: -40 o C to 70 o C Non operation humidity: 20% to 90% ( Non condensing) Note: The boundary condition above is based on 8.3W of PCH TDP spec . If the LFM estimate is higher than acceptable value from customer, ASUS can provide boundary condition with raw power for reference. Accessories Gift Box (1-in-1) 1 x Support CD 1 x I/O shield 4 x SATA 6G cables 1 x Plate for LGA1200 Bulk Pack (10-in-1) 1 x Support CD 1 x I/O shield 1 x Plate for LGA1200 Monitoring CPU Temperature Fan RPM Note 1.Gen4 x4 Link and Gen3 x2 Link,gray SATA port will disable when M.2 is SATA signal 2.VGA from BMC 3.HDMI (useable only with iGPU)

MPN A520M-HDV Unique Feature ASRock Super Alloy - Premium 50A Power Choke - Sapphire Black PCB - High Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen3 x4 and SATA3) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update and APP Shop CPU - Supports 3 rd Gen AMD AM4 Ryzen TM / future AMD Ryzen TM Processors (3000 and 4000 Series Processors) - 6 Power Phase design Not compatible with AMD Ryzen TM 5 3400G and Ryzen TM 3 3200G. Chipset - AMD A520 Memory - Dual Channel DDR4 Memory Technology - 2 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC and non-ECC, un-buffered memory - AMD Ryzen series APUs (Renoir) support DDR4 4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC and non-ECC, un-buffered memory - Max. capacity of system memory: 64GB - Supports Extreme Memory Profile (XMP) memory modules - 15micro Gold Contact in DIMM Slots Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS - 128Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, CPU VDDCR_SOC, DRAM, VDDP Voltage Multi-adjustment Graphics - Integrated AMD Radeon TM Vega Series Graphics in Ryzen Series APU - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. - Three graphics output options: D-Sub, DVI-D and HDMI - Supports Triple Monitor - Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports DVI-D with max. resolution up to 1920x1200 at 60Hz - Supports D-Sub with max. resolution up to 1920x1200 at 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.1 - Supports HDCP 2.3 with DVI-D and HDMI 2.1 Ports - Supports 4K Ultra HD (UHD) playback with HDMI 2.1 Port - Supports Microsoft PlayReady Actual support may vary by CPU The Max shared memory 16GB requires 32GB system memory installed. Audio - 7.1 CH HD Audio (Realtek ALC887 Audio Codec) - Supports Surge Protection LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s - Realtek RTL8111H - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Slots - 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode) - 1 x PCI Express 3.0 x1 Slot Supports NVMe SSD as boot disks Storage - 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x SPI TPM Header - 1 x COM Port Header - 1 x Chassis Intrusion and Speaker Header - 1 x CPU Fan Connector (4-pin) - 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector - 1 x 4 pin 12V Power Connector - 1 x Front Panel Audio Connector - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. The Chassis Fan supports the water cooler fan of maximum 1A (12W) fan power. CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O - 1 x PS/2 Mouse/Keyboard Port - 1 x D-Sub Port - 1 x DVI-D Port - 1 x HDMI Port - 2 x USB 2.0 Ports (Supports ESD Protection) - 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software - ASRock Motherboard Utility (A-Tuning) - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash These utilities can be downloaded from ASRock Live Update and APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 1 x Screw for M.2 Socket Hardware Monitor - Temperature Sensing: CPU, Chassis Fans - Fan Tachometer: CPU, Chassis Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis Fans - Fan Multi-Speed Control: CPU, Chassis Fans - CASE OPEN detection - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor - Micro ATX Form Factor - Solid Capacitor design OS - Microsoft Windows 10 64-bit Certifications - FCC, CEv - ErP/EuP ready (ErP/EuP ready power supply is required)

MPN Z690 STEEL LEGEND Unique Feature ASRock USB 3.2 Gen2 - ASRock Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s) - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s) ASRock Super Alloy - XXL Aluminum Alloy Heatsink - Premium Power Choke - 50A Dr.MOS - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) - I/O Armor - Matte Black PCB - High Density Glass Fabric PCB - 2oz Copper PCB 2.5G LAN ASRock Auto Driver Installer ASRock Steel Slot ASRock Full Coverage M.2 Heatsink ASRock Hyper M.2 (PCIe Gen4x4) ASRock Ultra USB Power ASRock POST Status Checker (PSC) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update and APP Shop CPU - Supports 12th Gen Intel Core Processors (LGA1700) - Digi Power design - 13 Power Phase design - Supports Intel Hybrid Technology - Supports Intel Turbo Boost Max 3.0 Technology Chipset - Intel Z690 Memory - Dual Channel DDR4 Memory Technology - 4 x DDR4 DIMM Slots - Supports DDR4 non-ECC, un-buffered memory up to 5333+(OC) - Supports ECC UDIMM memory modules (operate in non-ECC mode) - Max. capacity of system memory: 128GB - Supports Intel Extreme Memory Profile (XMP) 2.0 - 15mu Gold Contact in DIMM Slots Supports DDR4 3200 natively. BIOS - 256Mb AMI UEFI Legal BIOS with multilingual GUI support - ACPI 6.0 Compliant wake up events - SMBIOS 2.7 Support - CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V PROC, +1.8V PROC, +0.82V PCH, +1.05V PCH Voltage Multi-adjustment Graphics - Intel Xe Graphics Architecture (Gen 12) - Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers - Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) at 60Hz / 5K (5120x3200) at 120Hz - Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. Audio - 7.1 CH HD Audio (Realtek ALC897 Audio Codec) - Supports Surge Protection - Gold Audio Jacks - 15mu Gold Audio Connector - Nahimic Audio LAN - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s - Dragon RTL8125BG - Supports Dragon 2.5G LAN Software - Smart Auto Adjust Bandwidth Control - Visual User Friendly UI - Visual Network Usage Statistics - Optimized Default Setting for Game, Browser, and Streaming Modes - User Customized Priority Control - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Slots - 3 x PCIe x16 Slots (PCIE2/PCIE3/PCIE5: single at Gen5x16 (PCIE2) dual at Gen5x16 (PCIE2) / Gen4x4 (PCIE3) triple at Gen5x16 (PCIE2) / Gen4x4 (PCIE3) / Gen3x4 (PCIE5)) - 2 x PCIe Gen3x1 Slots - Supports AMD CrossFire - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVi (Integrated WiFi/BT) - 15mu Gold Contact in VGA PCIe Slot (PCIE2) Supports NVMe SSD as boot disks Storage - 8 x SATA3 6.0 Gb/s Connectors - 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode - 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2230/2242/2260/2280 SATA3 6.0 Gb/s and PCIe Gen3x4 (32 Gb/s) modes - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2242/2260/2280/22110 PCIe Gen4x4 (64 Gb/s) mode If M2_2 is occupied by a SATA-type M.2 device, SATA3_7 will be disabled. Supports Intel Optane Technology Supports Intel Volume Management Device (VMD) Supports NVMe SSD as boot disks Supports ASRock U.2 Kit RAID - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices - Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices Connector - 1 x SPI TPM Header - 1 x Power LED and Speaker Header - 1 x RGB LED Header - 3 x Addressable LED Headers - 1 x CPU Fan Connector (4-pin) - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 5 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) - 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) - 1 x Front Panel Audio Connector (15mu Gold Audio Connector) - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card) - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (ASMedia ASM1074 hub) (Supports ESD Protection) - 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) (Supports ESD Protection) Supports in total up to 12V/3A, 36W LED Strip Support in total up to 5V/3A, 15W LED Strip The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. The CPU/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CPU_FAN2/WP and CHA_FAN15/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O - 2 x Antenna Ports - 1 x PS/2 Mouse/Keyboard Port - 1 x HDMI Port - 1 x DisplayPort 1.4 - 1 x Optical SPDIF Out Port - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver) (Supports ESD Protection) - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver) (Supports ESD Protection) - 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - 1 x BIOS Flashback Button - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks) Ultra USB Power is supported on USB3_1_2 ports. ACPI wake-up function is not supported on USB3_1_2 ports. Software and UEFI Software - ASRock Motherboard Utility (A-Tuning) - ASRock Dragon 2.5G LAN Software - ASRock Polychrome SYNC UEFI - ASRock EZ Mode - ASRock Full HD UEFI - ASRock My Favorites in UEFI - ASRock Auto Driver Installer - ASRock Instant Flash - ASRock Internet Flash - ASRock Easy RAID Installer These utilities can be downloaded from ASRock Live Update and APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version) Accessories - Quick Installation Guide, Support CD - 2 x SATA Data Cables - 3 x Screws for M.2 Sockets - 2 x Standoffs for M.2 Sockets - 1 x Graphics Card Holder Hardware Monitor - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans - Voltage monitoring: CPU Vcore, PCH, DRAM, VCCIN AUX, +1.05V PROC, VCCSA, +1.8V PROC, +0.82V PCH, +12V, +5V, +3.3V Form Factor - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm - 2oz Copper PCB OS - Microsoft Windows 10 64-bit / 11 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) - CEC Tier II ready

MPN B550M-ITX/AC Unique Feature ASRock Super Alloy - Premium 60A Power Choke - 50A Dr.MOS - Sapphire Black PCB - High Density Glass Fabric PCB Intel 802.11ac WiFi ASRock Full Coverage M.2 Heatsink ASRock Hyper M.2 (PCIe Gen4x4) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update and APP Shop CPU - Supports 3 rd Gen AMD AM4 Ryzen TM / future AMD Ryzen TM Processors note1 - Digi Power design - 8 Power Phase design Note1: Not compatible with AMD Ryzen TM 5 3400G and Ryzen TM 3 3200G. Chipset - AMD B550 Memory - Dual Channel DDR4 Memory Technology - 2 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC and non-ECC, un-buffered memory - AMD Ryzen series APUs support DDR4 4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC and non-ECC, un-buffered memory - Max. capacity of system memory: 64GB note2 - Supports Extreme Memory Profile (XMP) memory modules - 15Mu Gold Contact in DIMM Slots SR: Single rank DIMM, 1Rx4 or 1Rx8 on DIMM module label DR: Dual rank DIMM, 2Rx4 or 2Rx8 on DIMM module label Note2: Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS - 256Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, CPU VDDCR_SOC, DRAM, VPPM, +1.8VSB, VDDP Voltage Multi-adjustment Graphics - Integrated AMD Radeon TM Vega Series Graphics in Ryzen Series APU note1 - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. note2 - Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers - Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports DisplayPort 1.4 Input with max. resolution up to 5K (5120x2880) at 120Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.1 - Supports HDCP 2.3 with HDMI 2.1 and DisplayPort 1.4 Ports - Supports 4K Ultra HD (UHD) playback with HDMI 2.1 and DisplayPort 1.4 Ports - Supports Microsoft PlayReady Note1: Actual support may vary by CPU Note2: The Max shared memory 16GB requires 32GB system memory installed. Audio - 7.1 CH HD Audio (Realtek ALC887 Audio Codec) - Supports Surge Protection LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s - Realtek RTL8111H - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Wireless LAN - Intel 802.11ac WiFi Module - Supports IEEE 802.11a/b/g/n/ac - Supports Dual-Band (2.4/5 GHz) - Supports high speed wireless connections up to 433Mbps - Supports Bluetooth 4.2 + High speed class II Slots AMD Ryzen series CPUs (Matisse) - 1 x PCI Express 4.0 x16 Slot (PCIE1: x16 mode) note1 AMD Ryzen series APUs - 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode) note1 - 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ac module (on the rear I/O) Note1: Supports PCIe riser cards to extend x8/x8 slots Supports NVMe SSD as boot disks Storage - 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) note2 Note1: Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x RGB LED Header note1 - 1 x Addressable LED Header note2 - 1 x CPU Fan Connector (4-pin) note3 - 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) note4 - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x Front Panel Audio Connector - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) Note1: Supports in total up to 12V/3A, 36W LED Strip Note2: Supports in total up to 5V/3A, 15W LED Strip Note3: The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. Note4: The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP and CHA_FAN2/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O - 2 x Antenna Ports - 1 x PS/2 Mouse/Keyboard Port - 1 x HDMI Port - 1 x DisplayPort 1.4 - 2 x USB 2.0 Ports (Supports ESD Protection) - 3 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection) - 1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software - ASRock Motherboard Utility (A-Tuning) - ASRock Polychrome SYNC - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash Note: These utilities can be downloaded from ASRock Live Update and APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 2 x ASRock WiFi 2.4/5 GHz Antennas Hardware Monitor - Temperature Sensing: CPU, Chassis/Water Pump Fans - Fan Tachometer: CPU, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm - Solid Capacitor design OS - Microsoft Windows 10 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)

MPN MBD-X11SCM-LN8F-O Physical Stats Form Factor microATX Processor/Cache CPU 8th/9th Generation Intel Corei3/Pentium/Celeron Processor, Intel Xeon E-2100 Processor, Intel Xeon E-2200 Processor. Single Socket LGA-1151 (Socket H4) supported, CPU TDP support Up to 95W TDP Cores / Cache 8 cores, 16 threads Note BIOS version 1.0b or above is required to support Intel Xeon E-2200 and 9th Generation Intel Core i3/Pentium/Celeron Processors System Memory Memory Capacity Up to 128GB Unbuffered ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots Memory Type 2666/2400/2133MHz ECC DDR4 SDRAM 72-bit DIMM Sizes 4GB, 8GB, 16GB, 32GB Memory Voltage 1.2V Error Detection Corrects single-bit errors On-Board Devices Chipset Intel C246 SATA Intel C246 controller for 6 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2500 Network Controllers 8 LAN with Intel Ethernet Controller I210-AT Graphics Aspeed AST2500 BMC Input / Output SATA 6 SATA3 (6Gbps) port LAN 8 RJ45 Gigabit Ethernet LAN ports USB 4 USB 2.0 ports (2 rear + 2 via headers) 5 USB 3.1 Gen1 ports(2 rears, 2 via headers, 1 Type A) Video Output 1 VGA port Serial Port / Header 1 COM Port (1 header) TPM 1 TPM Header Expansion Slots PCI-E 1 PCI-E 3.0 x16 M.2 M.2 Interface: 1 SATA/PCI-E 3.0 x4 and 1 PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key Double Height Connector System BIOS BIOS Type UEFI 256Mb BIOS Features ACPI 6.0 SMBIOS 2.7 Plug and Play (PnP) RTC (Real Time Clock) Wakeup UEFI 2.7 USB Keyboard support PCI 3.0 Management Software Intel Node Manager, IPMI2.0, NMI, SPM, SSM, SUM, SuperDoctor 5, Watchdog System Mangement Software IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support Power Configurations ACPI Power Management PC Health Monitoring Voltage +12V, +3.3V, +5V, +5V standby, 6 -fan status, Chassis intrusion header, Chipset Voltage, Memory Voltages, Monitors CPU voltages, Supports system management utility, System level control, VBAT FAN 6x 4-pin fan headers (up to 6 fans), 6 fans with tachometer status monitoring, Fan speed control, Overheat LED indication, Thermal control tachometer fan connectors Temperature Monitoring for CPU and chassis environment, CPU thermal trip support, Thermal Monitor 2 (TM2) support, PECI LED UID/Remote UID, CPU / System Overheat LED Other Features ACPI power management, Chassis intrusion detection, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, Dual Cooling Zones, M.2 NGFF connector, Node Manager Support, UID, WOL Operating Environment Operating Temperature Range 0 o C 50 o C (32 o F 122 o F) Non-Operating Temperature Range -40 o C 70 o C (-40 o F 158 o F) Operating Relative Humidity Range 8% - 90% (non-condensing) Non-Operating Relative Humidity Range 5% - 95% (non-condensing)

MPN MBD-X11SPA-TF-O Physical Stats Form Factor E-ATX Processor/Cache CPU Intel Xeon Scalable Processors. Single Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 205W TDP Cores / Cache Up to 28 cores System Memory Memory Capacity Up to 3TB 3DS ECC RDIMM, DDR4-2933MHz Up to 3TB 3DS ECC LRDIMM, DDR4-2933MHz Or 3TB DCPMM, DDR4-2666MHz, in 12 DIMM slots Memory Type N/A DIMM Sizes 4GB, 8GB, 16GB, 32GB, 64GB, 128GB Memory Voltage 1.2V On-Board Devices Chipset Intel C621 SATA Intel C621 controller for 8 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2500 Network Controllers Single LAN with Intel Ethernet Controller I210-AT Single LAN with Aquantia AQC107 10G Ethernet Controller Single LAN with Realtek RTL8211E PHY (dedicated IPMI) Graphics Aspeed AST2500 BMC VGA connector is dedicated for IPMI. Input / Output LAN 1 RJ45 Gigabit Ethernet LAN ports 1 RJ45 10GBase-T ports 1 RJ45 Dedicated IPMI LAN port USB 2 USB 2.0 ports (2 headers, Type A)) 6 USB 3.1 Gen1 ports (4 Rears Type A, 2 headers) 4 USB 3.1 Gen2 ports (1 Rear Type A + 1 Rear Type C, 1 Type A + 1 Type C) Video Output 1 VGA port, VGA connector is dedicated for IPMI. Serial Port / Header 2 COM Ports (1 rear, 1 header) TPM 1 TPM Header Expansion Slots PCI-E 4 PCI-E 3.0 x16, 3 PCI-E 3.0 x8 (in x16 slot), PCI-Ex16 Slot number 1 shares with M.2, Slot number 2 shares with Slot number 3(NA/16,8/8), Slot number 4 shares with Slot number 5(NA/16,8/8), Slot number 6 shares with Slot number 7(NA/16,8/8) M.2 M.2 Interface: 4 PCI-E 3.0 x4, RAID 0 1 Form Factor: 2242/2260/2280/22110 Key: M-Key M.2 support RAID 0,1(up to RAID 5, 10). M.2 shares PCI-E lanes with PCI-Ex16 slot number 1, VROC key is required for Raid. PCI-Ex16 Slot number 1 shares with M.2, Slot number 2 shares with Slot number 3(NA/16,8/8), Slot number 4 shares with Slot number 5(NA/16,8/8), Slot number 6 shares with Slot number 7(NA/16,8/8) System BIOS BIOS Type 256Mb SPI Flash with AMI BIOS BIOS Features ACPI 3.0 / 4.0 SMBIOS 2.7 PCI FW 3.0 RTC (Real Time Clock) Wakeup Management Software IPMI (Intelligent Platform Management Interface) v2.0 with KVM support, SPM, SUM, SuperDoctor 5, Watchdog System Mangement Software IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support SuperDoctor 5 Power Configurations ACPI Power Management Main Switch Override Mechanism Power-on mode for AC power recovery CPU thermal trip support for processor protection PC Health Monitoring Voltage +1.8V, +12V, +3.3V, +5V, +5V standby, 10 -fan status, 3.3V standby, HT, Memory, VBAT FAN 10x 4-pin fan headers (up to 10 fans), 10x fans with tachometer monitoring, Dual Cooling Zone, Fan speed control, Overheat LED indication, PWM fan speed control, Status monitoring for speed control 2 CPU Fan + 1 Water Cooler Radiator power connector + 8 System Fans. Temperature CPU thermal trip support, Monitoring for CPU and chassis environment, PECI LED CPU / System Overheat LED, Suspend static indicator LED Other Features Chassis intrusion header, CPU thermal trip support for processor protection, Dual Cooling Zones, Intel Smart Response Technology, RoHS, UID, WOL Operating Environment Operating Temperature Range 0 o C to 50 o C (32 o F to 122 o F) Non-Operating Temperature Range -40 o C - 70 o C (-40 o F - 158 o F) Operating Relative Humidity Range 8% - 90% (non-condensing) Non-Operating Relative Humidity Range 10% to 95% (non-condensing)

MPN MBD-X11SCZ-F-O Physical Stats Form Factor uATX Processor/Cache CPU 8th Generation Intel Core i3 Processors, Intel Celeron, Intel Pentium, Intel Xeon E processor (Coffee Lake-S) Workstation. Single Socket H4 (LGA 1151) supported, CPU TDP support Up to 95W TDP A graphic integrated CPU is required to have onboard video from the DVI and DP ports System Memory Memory Capacity Up to 64GB Unbuffered ECC/non-ECC UDIMM,DDR4-2666MHz, in 4 DIMM slots Memory Type 2666/2400/2133/1866/1600MHz ECC/Non-ECC DDR4 SDRAM 72-bit 288-pin UDIMM DIMM Sizes 4GB, 8GB, 16GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) On-Board Devices Chipset Intel C246 SATA Intel C246 controller for 5 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2500 Network Controllers Single LAN with Intel Ethernet Controller I210-AT Single LAN with Intel PHY I219LM LAN controller Audio ALC 888S HD Audio Graphics Aspeed AST2500 BMC, Intel HD Graphics 3 Independent Displays Input / Output LAN 2 RJ45 Gigabit Ethernet LAN ports USB 7 USB 2.0 ports (6 headers + 1 Type A), 2 USB 3.0 ports (2 headers), 6 USB 3.1 ports (4 rears (3 Type A + 1 Type C) + 2 headers) Video Output 1 VGA D-Sub Connector port, 1 DVI - I port, 2 DP (DisplayPort) ports, 3 Independent Displays Serial Port / Header 4 COM Ports (4 headers) TPM TPM Header Chip both Expansion Slots PCI-E 1 PCI-E 3.0 x16, 2 PCI-E 3.0 x4 (in x8 slot) M.2 M.2 Interface: 1 SATA/PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI Management Software IPMI (Intelligent Platform Management Interface) v2.0 with KVM support, SuperDoctor 5, Watchdog System Mangement Software IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support Power Configurations +12V DC Power Input ATX Power connector ACPI Power Management PC Health Monitoring Voltage +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 1.2V (VDIMM), 3.3V standby, 6 -fan status, Chassis intrusion header, Memory Voltages, Monitors CPU voltages, System temperature, VBAT FAN 6x 4-pin fan headers (up to 6 fans), 6 fans with tachometer status monitoring, Dual Cooling Zone, Fan speed control Temperature Thermal Control for 6 Fan Connectors LED UID/Remote UID Other Features 12V DC or ATX Power Source, 8-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion header, Dual Cooling Zones, M.2 NGFF connector, RoHS, UID Operating Environment Operating Temperature Range 0 o C - 60 o C (32 o F - 140 o F) Non-Operating Temperature Range -40 o C - 85 o C (-40 o F - 185 o F) Operating Relative Humidity Range 10% - 85% (non-condensing) Non-Operating Relative Humidity Range 5% - 95% (non-condensing) Item Dimension ( L inchxW inchxH inch) NA Weight 3lb

MPN MBD-X11SCZ-F-B Physical Stats Form Factor uATX Processor/Cache CPU 8th Generation Intel Core i3 Processors, Intel Celeron, Intel Pentium, Intel Xeon E processor (Coffee Lake-S) Workstation. Single Socket H4 (LGA 1151) supported, CPU TDP support Up to 95W TDP A graphic integrated CPU is required to have onboard video from the DVI and DP ports System Memory Memory Capacity Up to 64GB Unbuffered ECC/non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots Memory Type 2666/2400/2133/1866/1600MHz ECC/Non-ECC DDR4 SDRAM 72-bit 288-pin UDIMM DIMM Sizes 4GB, 8GB, 16GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) On-Board Devices Chipset Intel C246 SATA Intel C246 controller for 5 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2500 Network Controllers Single LAN with Intel Ethernet Controller I210-AT Single LAN with Intel PHY I219LM LAN controller Audio ALC 888S HD Audio Graphics Aspeed AST2500 BMC, Intel HD Graphics 3 Independent Displays Input / Output LAN 2 RJ45 Gigabit Ethernet LAN ports USB 7 USB 2.0 ports (6 headers + 1 Type A), 2 USB 3.0 ports (2 headers), 6 USB 3.1 ports (4 rears (3 Type A + 1 Type C) + 2 headers) Video Output 1 VGA D-Sub Connector port, 1 DVI - I port, 2 DP (DisplayPort) ports, 3 Independent Displays Serial Port / Header 4 COM Ports (4 headers) TPM TPM Header Chip both Expansion Slots PCI-E 1 PCI-E 3.0 x16, 2 PCI-E 3.0 x4 (in x8 slot) M.2 M.2 Interface: 1 SATA/PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI Management Software IPMI (Intelligent Platform Management Interface) v2.0 with KVM support, SuperDoctor 5, Watchdog System Mangement Software IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support Power Configurations +12V DC Power Input ATX Power connector ACPI Power Management PC Health Monitoring Voltage +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 1.2V (VDIMM), 3.3V standby, 6 -fan status, Chassis intrusion header, Memory Voltages, Monitors CPU voltages, System temperature, VBAT FAN 6x 4-pin fan headers (up to 6 fans), 6 fans with tachometer status monitoring, Dual Cooling Zone, Fan speed control Temperature Thermal Control for 6 Fan Connectors LED UID/Remote UID Other Features 12V DC or ATX Power Source, 8-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion header, Dual Cooling Zones, M.2 NGFF connector, RoHS, UID Operating Environment Operating Temperature Range 0 o C - 60 o C (32 o F - 140 o F) Non-Operating Temperature Range -40 o C - 85 o C (-40 o F - 185 o F) Operating Relative Humidity Range 10% - 85% (non-condensing) Non-Operating Relative Humidity Range 5% - 95% (non-condensing) Item Dimension ( L inchxW inchxH inch) NA Weight 3 lb

MPN MBD-X11SPW-TF-O Form Factor Proprietary WIO CPU Intel Xeon Processor Scalable Family. Single Socket P (LGA 3647) supported, CPU TDP support 205W Cores / Cache Up to 28 cores Memory Capacity 6x 288-pin DDR4 DIMM slots Up to 768GB ECC 3DS LRDIMM Up to 384GB ECC LRDIMM Up to 192GB ECC RDIMM Memory Type 2666/2400/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit 288-pin RDIMM/LRDIMM DIMM Sizes RDIMM: 4GB, 8GB, 16GB, 32GB LRDIMM: 32GB, 64GB 3DS LRDIMM: 64GB, 128GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Chipset Intel C622 SATA Intel C622 controller for 10 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2500 Network Controllers Dual LAN with 10GBase-T with Intel X722 + X557 Graphics Aspeed AST2500 BMC USB 7 USB 2.0 ports (2 rear + 5 via header(s)), 5 USB 3.0 ports (2 rear + 2 via header(s) + 1 Type A) Video Output 1 VGA port(s) Serial Port / Header 2 COM Ports (1 rear, 1 header(s)) TPM TPM Header PCI-E 1 PCI-E 3.0 x8 (in x16 slot), M.2 Interface: PCIe 3.0 x4 and SATA Form Factor: 2280, 22110 BIOS Type AMI UEFI BIOS Features ACPI 6.0 RTC (Real Time Clock) Wakeup SMBIOS 3.0 or late Software Intel Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SPM, SUM, SuperDoctor 5, Watchdog Power Configurations ACPI Power Management Power-on mode for AC power recovery Voltage +1.8V, +12V, +3.3V, +5V, +5V standby, 3.3V standby, 7-fan status, Chassis intrusion header, HT, Monitors CPU voltages, Supports system management utility, VBAT FAN 7x 4-pin fan headers (up to 7 fans), Fan speed control, Overheat LED indication, PWM fan speed control, System level control Temperature CPU thermal trip support PECI LED CPU / System Overheat LED UID/Remote UID Suspend static indicator LED Other Features ACPI power management, Control of power-on for recovery from AC power loss, RoHS, UID, WOL Item Dimension (L inchxW inchxH inch) 14 x 11 x 3 Weight 3.00lb

MPN MBD-X11SPI-TF-O Form Factor E-ATX CPU Intel Xeon Scalable Processors. Dual Socket P (LGA 3647) supported, CPU TDP support 205W, 2 UPI up to 10.4 GT/s Memory Capacity Up to 2TB 3DS ECC RDIMM and DDR4-2666MHz, Up to 2TB 3DS ECC LRDIMM, in 16 DIMM slots Memory Type 2666/2400/2133MHz ECC DDR4 RDIMM, LRDIMM DIMM Sizes RDIMM: 64GB LRDIMM: 64GB 3DS LRDIMM: 128GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) Chipset Intel C621 SATA Intel C621 controller for 10 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2500 Network Controllers Dual LAN with GbE from C621 Audio 7.1 HD Audio Graphics Aspeed AST2500 BMC USB 4 USB 3.0 ports (4 rear via header(s)), 2 USB 3.1 ports (2 rear) Video Output 1 VGA port(s) Serial Port / Header 1 COM Port (1 header(s)) TPM 1 TPM Header Others Thunderbolt header for Thunderbolt 3.0 AOC support PCI-E 4 PCI-E 3.0 x16, 2 PCI-E 3.0 x8 M.2 Interface: PCIe 3.0 x4 Form Factor: M-Key 2260, 2280, 22110 BIOS Type UEFI 128M Software Intel Node Manager, IPMI2.0, SPM, SSM, SUM, SuperDoctor 5, Watchdog Voltage +1.8V, +12V, +3.3V, +5V, +5V standby FAN 8x 4-pin fan headers (up to 8 fans), 8x fans with tachometer monitoring , Fan speed control, Overheat LED indication, Pulse Width Modulated (PWM) fan connectors Temperature N/A LED N/A Other Features Chassis intrusion detection, CPU thermal trip support for processor protection, Node Manager Support, RoHS Item Dimension (L inchxW inchxH inch) 14 x 11 x 3 Weight 3.00lb

MPN FAN-0124L4 Rated Current: 0.13A Fan Speed: 1850RPM Air Flow: 58.8CFM Static Pressure: 0.09 Noise: 24.0dBA Application: SC732

MPN BX806956234 Essentials Product Collection 2nd Generation Intel Xeon Scalable Processors Code Name Intel Xeon Gold 6234 Processor (24.75M Cache, 3.30 GHz) Vertical Segment Server Processor Number 6234 Status Launched Lithography 14 nm Recommended Customer Price 2214.00 - 2220.00 dollars Performance Number of Cores 8 Number of Threads 16 Processor Base Frequency 3.30 GHz Max Turbo Frequency 4.00 GHz Cache 24.75 MB Number of UPI Links 3 TDP 130 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 1 TB Memory Types DDR4-2933 Maximum Memory Speed 2933 MHz Max number of Memory Channels 6 ECC Memory Supported Yes Intel Optane TM DC Persistent Memory Supported Yes Expansion Options Scalability 4S PCI Express Revision 3.0 Max number of PCI Express Lanes 48 Package Specifications Sockets Supported FCLGA3647 T CASE 79 o C Advanced Technologies Intel Deep Learning Boost (Intel DL Boost) Yes Intel Speed Select Technology - Performance Profile No Intel Speed Select Technology - Base Frequency No Intel Resource Director Technology (Intel RDT) Yes Intel Speed Shift Technology Yes Intel Turbo Boost Max Technology 3.0 No Intel Turbo Boost Technology 2.0 Intel vPro TM Platform Eligibility Yes Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions Yes Intel 64 Yes Instruction Set Extensions Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512 Number of AVX-512 FMA Units 2 Enhanced Intel SpeedStep Technology Yes Intel Volume Management Device (VMD) Yes Security and Reliability Intel AES New Instructions Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Run Sure Technology Yes Mode-based Execute Control (MBE) Yes

MPN X570 STEEL LEGEND Unique Feature ASRock USB 3.2 Gen2 - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s) - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s) ASRock Super Alloy - XXL Aluminum Alloy Heatsink - Premium 60A Power Choke - 50A Dr.MOS - Premium Memory Alloy Choke (Reduces 70% core loss compared to iron powder choke) - Combo Caps (Nichicon 12K Black Caps) - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) - I/O Armor - Matte Black PCB - High Density Glass Fabric PCB - 2oz Copper PCB ASRock Steel Slot Gen4 ASRock Full Coverage M.2 Heatsink ASRock Hyper M.2 (PCIe Gen4x4 SATA3) ASRock Ultra USB Power ASRock POST Status Checker (PSC) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update APP Shop CPU - Supports AMD AM4 socket Ryzen 2000 and 3000 series processors - Intersil Digital PWM - 10 Power Phase design Chipset - AMD X570 Memory - Dual Channel DDR4 Memory Technology - 4 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4666+(OC) / 4400(OC) / 4300(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200/2933/2667/2400/2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3600+(OC) / 3466(OC) / 3200(OC) / 2933/2667/2400/2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 non-ECC, un-buffered memory - Max. capacity of system memory: 128GB - 15 Gold Contact in DIMM Slots BIOS - 256Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP Voltage Multi-adjustment Graphics - Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. - Dual graphics output: support HDMI and DisplayPort 1.2 ports by independent display controllers - Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) at 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.0 - Supports HDCP 2.2 with HDMI 2.0 and DisplayPort 1.2 Ports - Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and DisplayPort 1.2 Ports - Supports Microsoft PlayReady Audio - 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec) - Premium Blu-ray Audio support - Supports Surge Protection - Supports Purity Sound 4 - Nichicon Fine Gold Series Audio Caps - NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets) - Pure Power-In - Direct Drive Technology - PCB isolate shielding - Impedance Sensing on Rear Out port - Individual PCB Layers for R/L Audio Channel - Gold Audio Jacks - 15 Gold Audio Connector LAN - Gigabit LAN 10/100/1000 Mb/s - GigaLAN Intel I211AT - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Slots AMD Ryzen series CPUs (Matisse) - 2 x PCI Express 4.0 x16 Slots (single at x16 (PCIE1) dual at x16 (PCIE1) / x4 (PCIE4)) AMD Ryzen series CPUs (Pinnacle Ridge) - 2 x PCI Express 3.0 x16 Slots (single at x16 (PCIE1) dual at x16 (PCIE1) / x4 (PCIE4)) AMD Ryzen series CPUs (Picasso) - 2 x PCI Express 3.0 x16 Slots (single at x8 (PCIE1) dual at x8 (PCIE1) / x4 (PCIE4)) - 3 x PCI Express 4.0 x1 Slots - Supports AMD Quad CrossFireX and CrossFireX - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module - 15 Gold Contact in VGA PCIe Slot (PCIE1) Storage - 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso) - 1 x Hyper M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) Connector - 1 x SPI TPM Header - 1 x Power LED and Speaker Header - 1 x AMD Fan LED Header - 1 x RGB LED Header - 1 x Addressable LED Header - 1 x CPU Fan Connector (4-pin) - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x 4 pin 12V Power Connector - 1 x Front Panel Audio Connector (15 Gold Audio Connector) - 1 x AMD LED Fan USB Header - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 3 AIC Card R2.0 only) - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) Rear Panel I/O - 2 x Antenna Ports (on I/O Panel Shield) - 1 x PS/2 Mouse/Keyboard Port - 1 x HDMI Port - 1 x DisplayPort 1.2 - 1 x Optical SPDIF Out Port - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection) - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection) - 6 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks) Ultra USB Power is supported on USB3_56 ports. ACPI wake-up function is not supported on USB3_56 ports. Software and UEFI Software - ASRock Polychrome SYNC - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash These utilities can be downloaded from ASRock Live Update APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD - 4 x SATA Data Cables - 3 x Screws for M.2 Sockets - 2 x Standoffs for M.2 Sockets Hardware Monitor - Temperature Sensing: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Tachometer: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, VPPM, PREM VDDCR_SOC, +1.8V, VDDP Form Factor - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm - 2oz Copper PCB OS - Microsoft Windows 10 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)

MPN X570 PHANTOM GAMING 4 Gaming Armor Memory - 15 Gold Contact in DIMM Slots VGA Card - 15 Gold Contact in VGA PCIe Slot (PCIE1) Internet - Intel LAN Cooling - XXL Aluminum Alloy Heatsink Unique Feature ASRock USB 3.2 Gen2 - ASRock USB 3.2 Gen2 Type-A Ports (10 Gb/s) ASRock Super Alloy - XXL Aluminum Alloy Heatsink - Premium 50A Power Choke - Sapphire Black PCB - High Density Glass Fabric PCB - 2oz Copper PCB ASRock Steel Slot Gen4 ASRock Hyper M.2 (PCIe Gen4x4 SATA3) ASRock POST Status Checker (PSC) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update APP Shop CPU - Supports AMD AM4 socket Ryzen 2000 and 3000 series processors - Digi Power design - 10 Power Phase design Chipset - AMD X570 Memory - Dual Channel DDR4 Memory Technology - 4 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4066+(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200/2933/2667/2400/2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 non-ECC, un-buffered memory - Max. capacity of system memory: 128GB - 15 Gold Contact in DIMM Slots BIOS - 256Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP, VDDG, CPU Load-Line Calibration, CPU VDDCR_SOC Load-Line Calibration Voltage Multi-adjustment Graphics - Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. - Dual graphics output: support HDMI and DisplayPort 1.2 ports by independent display controllers - Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) 60Hz - Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.0 - Supports HDCP 2.2 with HDMI 2.0 and DisplayPort 1.2 Ports - Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and DisplayPort 1.2 Ports - Supports Microsoft PlayReady Actual support may vary by CPU The Max shared memory 16GB requires 32GB system memory installed. Audio - 7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio Codec) - Premium Blu-ray Audio support - Supports Surge Protection - ELNA Audio Caps - PCB Isolate Shieldingv - Individual PCB Layers for R/L Audio Channel LAN - Gigabit LAN 10/100/1000 Mb/s - Giga PHY Intel I211AT - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Slots AMD Ryzen series CPUs (Matisse) - 2 x PCI Express 4.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1) dual at x16 (PCIE1) / x4 (PCIE3)) AMD Ryzen series CPUs (Pinnacle Ridge) - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x16 (PCIE1) dual at x16 (PCIE1) / x4 (PCIE3)) AMD Ryzen series CPUs (Picasso) - 2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x8 (PCIE1) dual at x8 (PCIE1) / x4 (PCIE3)) - 2 x PCI Express 4.0 x1 Slots - Supports AMD Quad CrossFireX and CrossFireX - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module - 15 Gold Contact in VGA PCIe Slot (PCIE1) Supports NVMe SSD as boot disks Storage - 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280/22110 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso) - 1 x Hyper M.2 Socket (M2_3), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso) Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x COM Port Header - 1 x SPI TPM Header - 1 x Power LED and Speaker Header - 2 x RGB LED Headers - 1 x Addressable LED Header - 1 x CPU Fan Connector (4-pin) - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector - 1 x Front Panel Audio Connector - 1 x AMD LED Fan USB Header - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 3 AIC Card R2.0 only) - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection) Rear Panel I/O - 3 x Antenna Ports (on I/O Panel Shield) - 1 x PS/2 Mouse/Keyboard Port - 1 x HDMI Port - 1 x DisplayPort 1.2 - 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (Supports ESD Protection) - 6 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software - ASRock Polychrome SYNC - ASRock Key Master - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash These utilities can be downloaded from ASRock Live Update APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 3 x Screws for M.2 Sockets Hardware Monitor - Temperature Sensing: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Tachometer: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VDDCR_SOC, DRAM, PREM VDDCR_SOC, +1.8V, VDDP Form Factor - ATX Form Factor: 12.0-in x 9.0-in, 30.5 cm x 22.9 cm - Solid Capacitor design - 2oz Copper PCB OS - Microsoft Windows 10 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)

MPN X570 TAICHI Unique Feature ASRock USB 3.2 Gen2 - ASRock Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s) - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s) - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s) ASRock Super Alloy - XXL Aluminum Alloy Heatsink - Premium 60A Power Choke - 50A Dr.MOS - Premium Memory Alloy Choke (Reduces 70% core loss compared to iron powder choke) - Combo Caps (Nichicon 12K Black Caps) - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) - I/O Armor - Matte Black PCB - High Density Glass Fabric PCB - 2oz Copper PCB Intel 802.11ax WiFi ASRock Steel Slots ASRock Full Coverage M.2 Heatsink ASRock Hyper M.2 (PCIe Gen4x4 SATA3) ASRock Ultra USB Power ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update APP Shop CPU - Supports AMD AM4 socket Ryzen 2000 and 3000 series processors - Intersil Digital PWM - 14 Power Phase design - Capable of providing extra 300W for CPU - Supports ASRock Hyper BCLK Engine II Chipset - AMD Premium X570 Memory - Dual Channel DDR4 Memory Technology - 4 x DDR4 DIMM Slots - AMD Ryzen series CPUs (Matisse) support DDR4 4666+(OC) / 4400(OC) / 4300(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3600+(OC) / 3466(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 ECC non-ECC, un-buffered memory - AMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 non-ECC, un-buffered memory - Max. capacity of system memory: 128GB - 15 Gold Contact in DIMM Slots BIOS - 256Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, VCORE_NB, DRAM, VPPM, PCH 1.05V, +1.8V, VDDP, Voltage Multi-adjustment Graphics - Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU - DirectX 12, Pixel Shader 5.0 - Shared memory default 2GB. Max Shared memory supports up to 16GB. - Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant HDMI monitor is required) - Supports HDR (High Dynamic Range) with HDMI 2.0 - Supports HDCP 2.2 with HDMI 2.0 Port - Supports 4K Ultra HD (UHD) playback with HDMI 2.0 Port - Supports Microsoft PlayReady Actual support may vary by CPU The Max shared memory 16GB requires 32GB system memory installed. Audio - 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec) - Premium Blu-ray Audio support - Supports Surge Protection - Supports Purity Sound 4 - Nichicon Fine Gold Series Audio Caps - NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets) - Pure Power-In - Direct Drive Technology - PCB isolate shielding - Impedance Sensing on Rear Out port - Individual PCB Layers for R/L Audio Channel - Gold Audio Jacks - 15 Gold Audio Connector - Supports DTS Connect LAN - Gigabit LAN 10/100/1000 Mb/s - GigaLAN Intel I211AT - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE Wireless LAN - Intel 802.11ax WiFi Module - Supports IEEE 802.11a/b/g/n/ax - Supports Dual-Band (2.4/5 GHz) - Supports high speed wireless connections up to 2.4Gbps - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology - Supports Bluetooth 5.0 + High speed class II - Supports MU-MIMO Slots AMD Ryzen series CPUs (Matisse) - 3 x PCI Express 4.0 x16 Slots (PCIE1/PCIE3/PCIE5: single at x16 (PCIE1) dual at x8 (PCIE1) / x8 (PCIE3) triple at x8 (PCIE1) / x8 (PCIE3) / x4 (PCIE5)) AMD Ryzen series CPUs (Pinnacle Ridge) - 3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE5: single at Gen3x16 (PCIE1) dual at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) / Gen4x4 (PCIE5)) AMD Ryzen series CPUs (Picasso) - 1 x PCI Express 3.0 x16 Slot (single at x8 (PCIE1)) - 1 x PCI Express 4.0 x16 Slot (single at x4 (PCIE5)) - 2 x PCI Express 4.0 x1 Slots - Supports AMD Quad CrossFireX, 3-Way CrossFireX and CrossFireX - Supports NVIDIA Quad SLI and SLI - Supports NVIDIA NVLink with dual NVIDIA GeForce RTX series graphics cards - 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ax module (on the rear I/O) - 15 Gold Contact in VGA PCIe Slot (PCIE1) Supports NVMe SSD as boot disks 3-Way CrossFireX is only supported with Ryzen Series CPUs (Matisse and Pinnacle Ridge). NVIDIA NVLink Bridge does not come with the package. Please purchase it from NVIDIA if necessary. This feature is only supported with Ryzen Series CPUs (Matisse and Pinnacle Ridge). Storage - 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse) or Gen3x4 (32 Gb/s) (with Pinnacle Ridge and Picasso) - 1 x Hyper M.2 Socket (M2_2), supports M Key type 2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) - 1 x Hyper M.2 Socket (M2_3), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) If M2_3 is occupied, PCIE5 slot will be disabled Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector - 1 x SPI TPM Header - 1 x Power LED and Speaker Header - 1 x AMD Fan LED Header - 1 x RGB LED Header - 1 x Addressable LED Header - 1 x CPU Fan Connector (4-pin) - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) - 1 x 4 pin 12V Power Connector (Hi-Density Power Connector) - 1 x Front Panel Audio Connector (15 Gold Audio Connector) - 1 x AMD LED Fan USB Header - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 3 AIC Card R2.0 only) - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) - 1 x Front Panel Type C USB 3.2 Gen2 Header (Supports ESD Protection) - 1 x Dr. Debug with LED - 1 x Power Button with LED - 1 x Reset Button with LED - 1 x Clear CMOS Button Rear Panel I/O - 2 x Antenna Ports - 1 x PS/2 Mouse/Keyboard Port - 1 x HDMI Port - 1 x Optical SPDIF Out Port - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection) - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection) - 6 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - 1 x Clear CMOS Button - 1 x BIOS Flashback Button - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks) Ultra USB Power is supported on USB3_5_6 ports. ACPI wake-up function is not supported on USB3_5_6 ports. Software and UEFI Software - ASRock Polychrome SYNC - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash These utilities can be downloaded from ASRock Live Update APP Shop. Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar Accessories - Quick Installation Guide, Support CD - 4 x SATA Data Cables - 1 x ASRock SLI_HB_Bridge_2S Card - 1 x ASRock WiFi 2.4/5 GHz Antenna - 1 x ASRock Screwdriver - 3 x Screws for M.2 Sockets - 3 x Standoffs for M.2 Sockets Hardware Monitor - Temperature Sensing: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Tachometer: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis, Chassis/Water Pump Fans - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, VCORE_NB, DRAM, PCH 1.05V, +1.8V, VDDP Form Factor - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm - 2oz Copper PCB OS - Microsoft Windows 10 64-bit Certifications - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)

MPN X470D4U MB Physical Status Form Factor mATX Processor System CPU AMD AM4 Socket Ryzen Series CPUs (Raven Ridge and Pinnacle Ridge) and Ryzen 7nm CPUs Socket AM4 PGA 1331 Chipset AMD Promontory X470 System Memory Capacity 4 x 288-pin DDR4 DIMM slots - Support up to 64GB DDR4 ECC/UDIMM - One DIMM: 1R DIMM at 2667MT/s 2R/2DR DIMM at 2400MT/s - Two DIMMs: (1) 1R DIMM at 2133 MT/s (2) 2R/2DR DIMM at 1866MT/s 1R and 2R/2DR DIMM each at 1866MT/s Type Dual Channel DDR4 memory technology - Support DDR4 ECC/UDIMM DIMM Size Per DIMM ECC/UDIMM: 64GB, 32GB, 16GB, 8GB DIMM Frequency ECC/UDIMM: 2666/2400/2133 MHz Voltage 1.2V Expansion Slot PCIe 3.0 x 16 PCIE6: Gen3 x16 link (splittable in x4/4/4/4) auto switch to x8 link when PCIE4 is occupied. - SLOT4: Gen3 x8 link PCIe 3.0 x 8 SLOT5: Gen3 x4 link Storage SATA Controller 6 x SATA3 6.0 Gb/s (1x SATA DOM port) Additional Storage Controller Asmedia 1061: 2x SATA3 6.0Gb/s M.2 slot 2 (2242/2260/2280/22110, supports SATA3 6.0Gb/s or PCIe 3.0 x2(M.2_2) and supports PCIe 2.0 x4 only(M.2_1)) Ethernet Interface 1000 /100 /10 Mbps by Intel i210 LAN Controller 2 x RJ45 GLAN by Intel i210 1 x RJ45 Dedicated IPMI LAN port Supports Wake-On-LAN Supports Energy Efficient Ethernet 802.3az Supports Dual LAN with Teaming function Supports PXE LAN1 supports NCSI Management BMC Controller ASPEED AST2500 IPMI Dedicated GLAN 1 x Realtek RTL8211E for dedicated management GLAN Features Watch Dog Graphics Controller ASPEED AST2500 VRAM DDR4 256MB Rear Panel I/O VGA Port 1 x D-Sub USB 3.1 Gen1 Port 2 Lan Port 2 x RJ45 Gigabit Ethernet LAN ports 1 x RJ45 Dedicated IPMI LAN port LAN Ports with LED (ACT/LINK LED and SPEED LED) Serial Port 1 UID Button/UID LED 1 Internal Connector COM Header N/A SATA DOM 1 M.2 2(M2_1: 2242/2260/2280/22110, PCIE(X4) M2_2:2242/2260/2280/22110, SATA/PCIE(X2)) Auxiliary Panel Header 1 (include C_CASEOPENSYSTEM_FAULT_LEDLAN1 LAN2 LED, location button LED,BMC alert ) TPM Header 1 IPMB Header 1 Buzzer 1 Fan Header 6 Fans x 4-pin (FAN1(CPU)/FAN2FAN6(5Front)) ATX Power 1x (24-pin) + 1x (8-pin) USB 3.1 (Gen1) Header 1 (supports 2 USB 3.1 Gen1 ports) USB 2.0 Header N/A Speaker Header N/A BMC_SMB Header 1 ME/SPS Recovery N/A Clear CMOS 1 (short pad) PSU SMB Header 1 Onboard LED 80 Debug Port LED 1 Fan Fail LED 6 (only Fan Fail LED) System BIOS BIOS Type 16MB AMI UEFI Legal BIOS BIOS Features Plug and Play (PnP) ACPI 2.0 Compliance Wake Up Events SMBIOS 2.8.0 Support ASRock Rack Instant Flash Hardware Monitor Temperature CPU/DDR temperature sensing MB/Card side temperature sensing Fan Fan Tachometer Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) Fan Multi-Speed Control Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,1.05V_PCH, +BAT, 3VSB, 5VSB Support OS OS Microsoft Windows: Windows 10 (64 bit) Linux: UBuntu 16.04.4 (64 bit) RedHat Enterprise Linux Server 7.3 (64bit) / 7.4 (64bit) Please refer to our website for the latest OS support list. On Linux system doesnt support Raid mode Support UEFI BOOT only Environment Temperature Operation temperature: 10 o C - 35 o C / Non operation temperature: -40 o C - 70 o C

MPN MBD-X12DPI-NT6-B Physical Stats Form Factor E-ATX Processor CPU 3rd Gen Intel Xeon Scalable processors Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s Core Up to 40 cores System Memory Memory Capacity 18 DIMM slots Up to 4TB Intel Optane Persistent Memory 200 Series, DDR4-3200MHz Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz Up to 4TB ECC RDIMM, DDR4-3200MHz P1-DIMMB2 and P2-DIMMB2 are reserved for Intel Optane Persistent Memory 200 Series only. Memory Type 3200/2933/2666MHz ECC 3DS DDR4 LRDIMM, RDIMM DIMM Sizes LRDIMM: 256GB RDIMM: 256GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) On-Board Devices Chipset Intel C621A SATA Intel C621A controller for 14 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2600 BMC Network Controllers Dual LAN with 10GBase-T with Intel X550 Input / Output SATA 14 SATA3 (6Gbps) port(s) LAN 2 RJ45 10 Gigabit Ethernet LAN ports USB 7 USB 3.2 Gen1 port(s) (2 via header 4 rear 1 type A) 2 USB 2.0 port(s) (2 via header) Video Output 2 VGA (1 rear bezel, 1 front panel) port(s) Serial Port 2 COM Port(s) (1 header 1 rear) TPM 1 TPM Header Expansion Slots PCI-E 4 PCI-E 4.0 x16, 2 PCI-E 4.0 x8 M.2 M.2 Interface: 1 PCI-E 4.0 x4 Form Factor: 2280/22110 Key: M-Key System BIOS BIOS Type AMI UEFI Management Software SuperDoctor 5, SUM, KVM with dedicated LAN, SPM, Intel Node Manager, SSM, IPMI2.0, Watchdog System Management Software IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support PC Health Monitoring Voltage VBAT, System temperature, PCH temperature, Monitors CPU voltages, Memory temperature, CPU temperature, Chassis intrusion header, 3.3V standby, +5V standby, +5V, +3.3V, +12V, VRM temperature, Memory Voltages, LAN temperature, 8 -fan status LED UID/Remote UID Power LED BMC/IPMI Heartbeat LED FAN 8x 4-pin fan headers (up to 8 fans) PWM fan speed control Other Features WOL, UID, RoHS, Node Manager Support, Dual Cooling Zones, CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, Chassis intrusion header, ATX Power connector, ACPI power management, SDDC, RoT, NCSI header Operating Environment Operating Temperature Range 10 o C - 35 o C (50 o F - 95 o F) Non-Operating Temperature Range -40 o C - 70 o C (-40 o F - 158 o F) Operating Relative Humidity Range 8% - 90% (non-condensing) Non Operating Relative Humidity Range 5% - 95% (non-condensing)

MPN HF-2812C-TW Key Specs Material(s) Plastic, rubber, PCB Fan Rated Voltage 12V DC, 0.18A, 2.16W LED Quantity 8 Bearing Fluid Dynamic Bearing (FDB) Fan Connector 4-pin PWM Mounting Magnet, Velcro Connector 12V DC / 2.6A Cooling Speed 500 - 1,500 +/- 300RPM Airflow 17.48 - 52.44 CFM Static Pressure 0.15 - 1.35 mm-H2O Noise 22 - 33 dBA Fan Life Hours 60,000 Years 6 Output Channel Voltage 5V DC RGB Lighting Channels 2 Fan Channels 3 LED Color RGB

MPN HF-2812C-TB Key Specs Material(s) Plastic, rubber, PCB Fan Rated Voltage 12V DC, 0.18A, 2.16W LED Quantity 8 Bearing Fluid Dynamic Bearing (FDB) Fan Connector 4-pin PWM Mounting Magnet, Velcro Connector 12V DC / 2.6A Cooling Speed 500 - 1,500 +/- 300RPM Airflow 17.48 - 52.44 CFM Static Pressure 0.15 - 1.35 mm-H2O Noise 22 - 33 dBA Fan Life Hours 60,000 Years 6 Output Channel Voltage 5V DC RGB Lighting Channels 2 Fan Channels 3 LED Color RGB

MPN BX80708E2324G Essentials Product Collection Intel Xeon E Processor Code Name Products formerly Rocket Lake Vertical Segment Server Processor Number E-2324G Lithography 14 nm Use Conditions Server/Enterprise CPU Specifications Total Cores 4 Total Threads 4 Max Turbo Frequency 4.60 GHz Intel Turbo Boost Technology 2.0 Frequency 4.60 GHz Processor Base Frequency 3.10 GHz Cache 8 MB Intel Smart Cache Bus Speed 8 GT/s TDP 65 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types DDR4-3200 Max Number of Memory Channels 2 ECC Memory Supported Yes Intel Optane TM Persistent Memory Supported No Processor Graphics Processor Graphics Intel UHD Graphics P750 Graphics Base Frequency 350 MHz Graphics Max Dynamic Frequency 1.30 GHz Graphics Video Max Memory 64 GB Execution Units 32 4K Support Yes, at 60Hz Max Resolution (HDMI) 4096 x 2160 at60 Hz Max Resolution (DP) 5120 x 3200 at 60 Hz Max Resolution (eDP - Integrated Flat Panel) 5120 x 3200 at 60 Hz DirectX Support 12.1 OpenGL Support 4.5 Intel Quick Sync Video Yes Intel InTru TM 3D Technology Yes Intel Clear Video HD Technology Yes Intel Clear Video Technology Yes Number of Displays Supported 1 Device ID 0x4C9A Expansion Options Scalability 1S Only PCI Express Revision 4.0 Microprocessor PCIe Revision Gen 4 PCI Express Configurations 0Up to 1x16+1x4, 2x8+1x4, 1x8+3x4 Max Number of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1200 Max CPU Configuration 1 TJUNCTION 100 o C Advanced Technologies Intel Turbo Boost Technology 2.0 Intel vPro Platform Eligibility Yes Intel Hyper-Threading Technology No Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions No Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2, Intel AVX-512 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Security and Reliability Intel AES New Instructions Yes Secure Key Yes Intel Software Guard Extensions (Intel SGX) Yes with Intel SPS Intel Memory Protection Extensions (Intel MPX) Yes Intel OS Guard Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Boot Guard Yes Maximum Enclave Page Cache (EPC) Size for Intel SGX 0.5 GB

MPN BX80708E2336 Essentials Product Collection Intel Xeon E Processor Code Name Products formerly Rocket Lake Vertical Segment Server Processor Number E-2336 Lithography 14 nm Use Conditions Server/Enterprise CPU Specifications Total Cores 6 Total Threads 12 Max Turbo Frequency 4.80 GHz Intel Turbo Boost Technology 2.0 Frequency 4.80 GHz Processor Base Frequency 2.90 GHz Cache 12 MB Intel Smart Cache Bus Speed 8 GT/s TDP 65 W Supplemental Information Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types DDR4-3200 Max Number of Memory Channels 2 ECC Memory Supported Yes Intel Optane TM Persistent Memory Supported No Expansion Options Scalability 1S Only PCI Express Revision 4 Microprocessor PCIe Revision Gen 4 PCI Express Configurations Up to 1x16+1x4 , 2x8+1x4 , 1x8+3x4 Max Number of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1200 Max CPU Configuration 1 TJUNCTION 100 o C Advanced Technologies Intel Turbo Boost Technology 2 Intel vPro Platform Eligibility Yes Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel Transactional Synchronization Extensions No Intel 64 Yes Instruction Set 64-bit Instruction Set Extensions Intel SSE4.1 , Intel SSE4.2 , Intel AVX2 , Intel AVX-512 Idle States Yes Enhanced Intel SpeedStep Technology Yes Thermal Monitoring Technologies Yes Security and Reliability Intel AES New Instructions Yes Secure Key Yes Intel Software Guard Extensions (Intel SGX) Yes with Intel SPS Intel Memory Protection Extensions (Intel MPX) Yes Intel OS Guard Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Boot Guard Yes Maximum Enclave Page Cache (EPC) Size for Intel SGX 0.5 GB
